Q
What are Cisco 7200 series modules?
A
Cisco 7200 series modules are modular interface and service cards designed to add voice, data, security, and WAN connectivity options to Cisco 7200 routers.
Q
Which interface types do Cisco 7200 modules support?
A
Cisco 7200 modules support Ethernet (10/100/1000), Fast Ethernet, Serial (T1/E1/SONET), ATM, and POS interfaces for flexible WAN and LAN connectivity.
Q
How do I install a Cisco 7200 module?
A
To install a Cisco 7200 module, power down the router, align the module’s guide rails with the slot, slide it in until it clicks, and then power up the router.
Q
Can I hot-swap modules in Cisco 7200 routers?
A
Yes, most Cisco 7200 series modules are hot-swappable, allowing you to add or remove interface cards without powering down the router.
Q
What is the maximum throughput of Cisco 7200 modules?
A
Maximum throughput varies by module, ranging from 100 Mbps on Fast Ethernet cards up to 2.5 Gbps on high-density Gigabit Ethernet and POS modules.
Q
How much memory can Cisco 7200 modules support?
A
Cisco 7200 series routers support up to 1.5 GB of DRAM and up to 64 MB of Flash memory, depending on the route processor and module type.
Q
Which Cisco IOS images support 7200 series modules?
A
Cisco IOS Classic and IOS XE images with feature sets for Enterprise, Security, and Service Provider are compatible with Cisco 7200 series modules.
Q
What power requirements do Cisco 7200 modules have?
A
Cisco 7200 series routers require AC or DC power supplies rated between 100–240 VAC or –48 VDC, with module draw specified in the hardware installation guide.
Q
How do I troubleshoot Cisco 7200 module failures?
A
Use show diagnostic and show controller commands to check module status, verify IOS compatibility, reseat the module, and review logs for hardware errors.
Q
How do I upgrade firmware on Cisco 7200 modules?
A
Upgrade firmware by copying the new IOS or module firmware image to Flash and configuring boot variables, then reload the router to activate the update.
Q
What licensing is required for Cisco 7200 modules?
A
Most Cisco 7200 module features—like encryption and MPLS—require the appropriate Cisco IOS feature license, such as Security or Advanced IP Services.
Q
Are Cisco 7200 modules end-of-life?
A
Yes, Cisco announced end-of-life for the 7200 series; support and software updates are available under Cisco’s legacy product policy.
Q
How do I configure interfaces on Cisco 7200 modules?
A
Enter global configuration mode, use interface slot/port commands to assign IP addresses, enable encapsulation, and apply QoS or security policies.
Q
What are the port density options for Cisco 7200 modules?
A
Port density ranges from single-port T1/E1 modules up to 16-port Fast Ethernet and 8-port Gigabit Ethernet or POS modules.
Q
How can I optimize performance on Cisco 7200 modules?
A
Optimize performance by enabling hardware forwarding, allocating sufficient DRAM/Flash, applying QoS policies, and running the latest certified IOS image.
