Question 1

What is the Huawei S2300 Series Switch?

Accepted Answer

The Huawei S2300 Series is a family of fixed, unmanaged Layer 2 Ethernet switches designed for small to medium-sized enterprise access networks, offering high port density, reliability, and energy efficiency.

Question 2

What port types and densities are available on the S2300 Series?

Accepted Answer

The S2300 Series provides 8 to 52 Gigabit Ethernet RJ45 ports, with optional SFP uplink slots on selected models to accommodate fiber connectivity and long-reach applications.

Question 3

Does the Huawei S2300 support Power over Ethernet (PoE)?

Accepted Answer

Yes, PoE/PoE+ models deliver up to 30 W per port and up to 370 W total budget, enabling direct power supply to IP phones, cameras, and wireless access points without external adapters.

Question 4

What is the switching capacity and forwarding performance of the S2300 Series?

Accepted Answer

Depending on the model, switching capacity ranges from 20 Gbps to 104 Gbps, with forwarding rates up to 77.4 Mpps for high-performance packet handling.

Question 5

Which Layer 2 features are supported by the S2300 switches?

Accepted Answer

They support VLAN (port-based, 802.1Q), link aggregation (LACP), Spanning Tree Protocol (RSTP/STP), IGMP snooping, and DHCP snooping for efficient and secure LAN segmentation.

Question 6

How can I manage and monitor the Huawei S2300 Series?

Accepted Answer

Management options include an intuitive web GUI, industry-standard CLI (SSH/Telnet), SNMP v1/v2c/v3, and RMON for flexible device configuration and real-time network monitoring.

Question 7

Does the S2300 Series support Quality of Service (QoS)?

Accepted Answer

Yes, it provides eight hardware queues per port, 802.1p/DSCP classification, traffic shaping, and rate limiting to ensure prioritized traffic handling and bandwidth control.

Question 8

What security features are built into the S2300 switches?

Accepted Answer

Security options include port security, MAC address binding, dynamic ARP inspection, DHCP snooping, IP source guard, and RADIUS/TACACS+ authentication to protect against unauthorized access and attacks.

Question 9

Are the Huawei S2300 switches energy-efficient?

Accepted Answer

Yes, they comply with IEEE 802.3az Energy-Efficient Ethernet, feature smart fans, and offer port shutdown and master/slave power management for reduced power consumption.

Question 10

Can I install the S2300 Series in a standard network rack?

Accepted Answer

All rack-mountable models are designed for 1U installation in 19-inch racks, with adjustable brackets for secure deployment in wiring closets or data centers.

Question 11

How many VLANs can the S2300 Series handle?

Accepted Answer

Each switch supports up to 4,094 VLANs, allowing extensive network segmentation and scalable multi-tenant deployments.

Question 12

Does the S2300 Series support IPv6?

Accepted Answer

Yes, the switches support IPv6 management, IPv6 neighbor discovery, and routing protocols like MLD snooping for next-generation network compatibility.

Question 13

Are the Huawei S2300 switches stackable?

Accepted Answer

No, the S2300 Series is fixed and unmanaged without stacking capabilities; for stacking, consider the Huawei S5700 or S6720 Series.

Question 14

What are the typical use cases for the S2300 Series?

Accepted Answer

Ideal for enterprise branch offices, campus edge access, SMB networks, IP surveillance aggregation, and VoIP deployments requiring reliable Ethernet connectivity.

Question 15

Who is the target audience for the Huawei S2300 switches?

Accepted Answer

They are designed for network administrators and SMB IT managers seeking cost-effective, energy-efficient, and easy-to-deploy Layer 2 access switches.

Question 16

What warranty and support options are available?

Accepted Answer

Huawei offers a limited lifetime hardware warranty, software maintenance upgrades, and optional 24/7 support packages for rapid issue resolution and firmware updates.

Networking Switches Huawei S2300 Series

S2350-28TP-EI-AC (S2350-28TP-EI-AC(24 Ethernet 10/100 ports,2 Gig SFP and 2 dual-purpose 10/100/1000 or SFP,AC 110/220V,front access))

LS-S2309TP-EI-AC (S2309TP-EI Mainframe(8 10/100 BASE-T ports and 1 Combo GE(10/100/1000 BASE-T+100/1000 Base-X) ports and AC 110/220V))

S2328P-EI-AC (S2328P-EI-AC Mainframe(24 FE RJ45,4 GE SFP,AC 110/220V))

S2350-28TP-EI-DC (S2350-28TP-EI-DC(24 Ethernet 10/100 ports,2 Gig SFP and 2 dual-purpose 10/100/1000 or SFP,DC-48V,front access))

S2350-20TP-PWR-EI-AC (S2350-20TP-PWR-EI-AC(16 Ethernet 10/100 PoE+ ports,2 Gig SFP and 2 dual-purpose 10/100/1000 or SFP,AC 110/220V))

S2350-28TP-PWR-EI-AC (S2350-28TP-PWR-EI-AC(24 Ethernet 10/100 PoE+ ports,2 Gig SFP and 2 dual-purpose 10/100/1000 or SFP,AC 110/220V))

LS-S2318TP-EI-AC (S2318TP-EI Mainframe(16 10/100 BASE-T ports and 2 Combo GE(10/100/1000 BASE-T+100/1000 Base-X) ports and AC 110/220V))

LS-S2318TP-EI-DC (S2318TP-EI Mainframe(16 10/100 BASE-T ports and 2 Combo GE(10/100/1000 BASE-T+100/1000 Base-X) ports and DC -48V))

LS-S2326TP-SI-AC (S2326TP-SI Mainframe(24 10/100 BASE-T ports and 2 Combo GE(10/100/1000 BASE-T+100/1000 Base-X) ports and AC 110/220V))

LS-S2318TP-SI-AC (S2318TP-SI Mainframe(16 10/100 BASE-T ports and 2 Combo GE(10/100/1000 BASE-T+100/1000 Base-X) ports and AC 110/220V))

LS-S2352P-EI-AC (S2352P-EI Mainframe(48 10/100 BASE-T ports and 2 100/1000 BASE-X ports and 2 SFP GE (1000 BASE-X) ports (SFP Req.) and AC 110/220V))

LS-S2326TP-PWR-EI (S2326TP-PWR-EI Mainframe(24 10/100 BASE-T ports and 2 Combo GE(10/100/1000 BASE-T+100/1000 Base-X) ports ,PoE,Chassis,Dual Slots of power,Without Power))

LS-S2326TP-EI-DC (S2326TP-EI Mainframe(24 10/100 BASE-T ports and 2 Combo GE(10/100/1000 BASE-T+100/1000 Base-X) ports and DC -48V))

LS-S2309TP-SI-AC (S2309TP-SI Mainframe(8 10/100 BASE-T ports and 1 Combo GE(10/100/1000 BASE-T+100/1000 Base-X) ports and AC 110/220V))

LS-S2309TP-PWR-EI (S2309TP-PWR-EI Mainframe(8 10/100 BASE-T ports and 1 Combo GE(10/100/1000 BASE-T+100/1000 Base-X) ports ,PoE and AC 110/220V))

LS-S2326TP-EI-AC (S2326TP-EI Mainframe(24 10/100 BASE-T ports and 2 Combo GE(10/100/1000 BASE-T+100/1000 Base-X) ports and AC 110/220V))

LS-S2309TP-EI-DC (S2309TP-EI Mainframe(8 10/100 BASE-T ports and 1 Combo GE(10/100/1000 BASE-T+100/1000 Base-X) ports and DC -48V))
