BKNUC8CCHKRN2

Specification Of BKNUC8CCHKRN2

General
Type	PC barebone
Product Form Factor	Mini PC
Embedded Security	Trusted Platform Module (TPM 2.0) Security Chip
Localisation	Region: Europe

Processor / Chipset
CPU	Intel Celeron N3350
Clock Speed	1.1 GHz
Max Turbo Speed	2.4 GHz
Number of Cores	Dual-Core
CPU Qty	1
Max CPU Qty	1
CPU Upgradability	Not upgradable
Processor Main Features	Intel Virtualization Technology, Intel AES New Instructions, Intel Platform Trust Technology (PTT)

Cache Memory
Installed Size	2 MB
Cache Per Processor	2 MB

RAM
Installed Size	4 GB / 4 GB (max)
Technology	LPDDR3 SDRAM
Rated Memory Speed	1866 MHz
Slots	2 (Total)
Features	Dual channel memory architecture
Configuration Features	Provided memory is soldered

Hard Drive
Type	Flash - eMMC
Capacity	1 x 64 GB

Optical Storage
Type	No optical drive

Monitor
Monitor Type	None.

Graphics Controller
Graphics Processor	Intel HD Graphics 500
Video Interfaces	HDMI
Max Monitors Supported	2

Audio Output
Sound Output Mode	7.1 channel surround
Compliant Standards	High Definition Audio

Networking
Interface (Bus) Type	M.2 Card
Ethernet Controller	Intel I211-AT
Wireless LAN Supported	Yes
Wireless NIC	Intel Dual Band Wireless-AC 3168
Data Link Protocol	Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, Bluetooth 4.2
Compliant Standards	IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, Bluetooth 4.2

Expansion / Connectivity
Slots	1 (total) / 0 (free) x M.2 Card - 2230 (Key E) - 1 (total) / 1 (free) x M.2 Card - 2280 (Key M)
Interfaces	2 x USB 3.0 (1 front, 1 rear) - 2 x USB 2.0 (2 rear) - 2 x HDMI - 1 x LAN (Gigabit Ethernet) - RJ-45

Miscellaneous
Theft/Intrusion Protection	Security lock slot (cable lock sold separately)
Security Slot Type	Kensington security slot
Compliant Standards	ICES-003, EN55024, UL 60950-1, IEC 60950-1, EN 60950-1, AS/NZS 4268, BSMI CNS 13438, FCC CFR47 Part 15 C, FCC CFR47 Part 15 B, REACH, EN 62311, EN 300.440, China RoHS, EN 300 328, EN 301 489-1, KN32, KN35, EN 62368-1, IEC 62368-1, AS/NZS 2772.2, EN 301 893, FCC CFR47 Part 15 E, EN 55032, EU RoHS, UL 62368-1, ARPANSA, Taiwan BSMI RoHS, AS/NZS CISPR 32, VCCI 32

Power
Device Type	Power adapter
Voltage Required	DC 12 - 24 V
Power Provided	65 Watt

Manufacturer Warranty
Service & Support	Limited warranty - 3 years

Dimensions & Weight
Width	15.4 cm
Depth	10.8 cm
Height	3.2 cm

Environmental Parameters
Min Operating Temperature	0 °C
Max Operating Temperature	40 °C
