E1MG-CWDM80-1550 Overview
E1MG-CWDM80-1550 is an SFP+ optical transceiver engineered for CWDM applications, delivering a 10G data rate over single-mode fiber with LC connectors. It supports Ethernet protocols and is optimized for long-distance transmission, offering extended-range operation up to 80 km in demanding telecom, enterprise, and data center environments.
This compact module adheres to standard SFP+ form factor dimensions, ensuring seamless integration into modern networking equipment. Operating at a 1550 nm wavelength, the E1MG-CWDM80-1550 is ideal for high-speed, CWDM-based fiber optic communications where reliability and performance are paramount.
What is the price of E1MG-CWDM80-1550?
Pricing for E1MG-CWDM80-1550 is available on request. Get immediate quote or for exclusive discounts, opt for bulk quotation for E1MG-CWDM80-1550.
Explore more options from Transceivers or explore other Brocade products.
E1MG-CWDM80-1550 Specifications
| Product Type | Transceiver |
| Form Factor | SFP+ |
| Data Rate | 10G |
| Connector Type | LC |
| Wavelength | 1550 nm |
| Transmission Distance | Extended-Range |
| Fiber Type | Single-mode |
| Max Distance | 80 km |
| Supported Protocols | Ethernet |
| Network Interface | Fiber |
| Power Consumption | N/A |
| Operating Temperature | 0 to 70°C |
| Storage Temperature | -40 to 85°C |
| Input Voltage | 3.3V |
| Compatibility | Cisco, Juniper, Huawei, Arista |
| Product Name | E1MG-CWDM80-1550 |
| Height | N/A |
| Width | N/A |
| Depth | N/A |
| Weight | N/A |
Quality Certifications
To get the detailed certification, please go to the Compliance Center.
Product Comparison Table
|
|
|
|
|
|
|---|---|---|---|---|---|
| Compatibility | Cisco, Juniper, Huawei, Arista | Cisco, Juniper, Huawei, Arista | Cisco, Juniper, Huawei, Arista | Cisco / Juniper / Huawei / Arista | Cisco, Juniper, Huawei, Arista |
| Connector Type | LC | LC | LC | LC | LC |
| Data Rate | 1G | 100G | 10G | 10G | 10G |
| Depth | 1.8 inches | 2.00 inches | N/A | N/A | N/A |
| Fiber Type | Single-mode | Single-mode | Single-mode | Multi-mode | Single-mode |
| Form Factor | SFP | CFP | SFP+ | XFP | SFP+ |
| Height | 0.3 inches | 1.3 inches | N/A | N/A | N/A |
| Input Voltage | 3.3V | 3.3V | 3.3V | 3.3V | 3.3V |
| Max Distance | 80 km | 80 km | 40 km | 300 meters | 80 km |
| Network Interface | Fiber | Fiber | Ethernet | Ethernet | Fiber |
| Operating Temperature | 0 to 70°C | 0 to 70°C | 0 to 70°C | 0 to 70°C | 0 to 70°C |
| Power Consumption | 1.5W | 15W | 3.5 W | 3.5W | N/A |
| Product Name | DWDM-SFP-4772-120-C | 407-BBQV-C High-Performance CFP Transceiver | EX-SFP-10GE-ERD3661-C | 10G-XFP-SR-C | E1MG-CWDM80-1550 |
| Product Type | Transceiver | Transceiver | Transceiver | Transceiver | Transceiver |
| Storage Temperature | -40 to 85°C | -40 to 85°C | -40 to 85°C | -40 to 85°C | -40 to 85°C |
| Supported Protocols | Ethernet | Ethernet, Fibre Channel | Ethernet | Ethernet | Ethernet |
| Transmission Distance | Long-Range | Long-Range | Long-Range | Short-Range | Extended-Range |
| Wavelength | 1550 nm | 1550 nm | 1550 nm | 850 nm | 1550 nm |
| Weight | 0.1 lbs | 0.5 lbs | N/A | N/A | N/A |
| Width | 0.8 inches | 0.79 inches | N/A | N/A | N/A |
Showing - of 0 Results
Questions & Answers
Q
What is the E1MG-CWDM80-1550?
A
The E1MG-CWDM80-1550 is a 1U rack-mount CWDM Mux/Demux module optimized for 1550 nm transmission and up to 80 km reach over single-mode fiber.
Q
Which wavelengths does the E1MG-CWDM80-1550 support?
A
It supports eight standard ITU-T G.694.2 CWDM channels: 1470, 1490, 1510, 1530, 1550, 1570, 1590 and 1610 nm.
Q
How many channels are available on the E1MG-CWDM80-1550?
A
This unit provides 8 CWDM channels with 20 nm spacing, each mapped to a dedicated port plus common line interfaces.
Q
What is the maximum transmission distance for the E1MG-CWDM80-1550?
A
With standard single-mode fiber, the E1MG-CWDM80-1550 supports up to 80 km without additional amplification.
Q
What is the typical insertion loss per channel?
A
Typical insertion loss is ≤ 2.5 dB per channel, ensuring high optical budget for metro and access networks.
Q
What return loss does the E1MG-CWDM80-1550 achieve?
A
The module delivers a return loss of ≥ 45 dB on all channel and common ports to minimize reflections.
Q
What connector type is used on the E1MG-CWDM80-1550?
A
All ports use SC/UPC connectors, offering low back-reflection and reliable mechanical performance.
Q
Which fiber type is compatible with the E1MG-CWDM80-1550?
A
It is optimized for ITU-T G.652 single-mode fiber, ensuring low attenuation and broad vendor interoperability.
Q
What are the operating temperature ranges?
A
Rated for –40 °C to +85 °C, the E1MG-CWDM80-1550 is suitable for indoor and controlled-environment outdoor racks.
Q
What are the physical dimensions of the E1MG-CWDM80-1550?
A
The unit occupies 1U (19″) rack space, measures 440 × 200 × 44 mm (W×D×H) and weighs 3 kg.
Q
Which ITU-T standard does the device comply with?
A
It fully complies with ITU-T G.694.2 for CWDM channel definitions and industry-standard performance.
Q
What are the primary applications for the E1MG-CWDM80-1550?
A
Ideal for metro rings, FTTx aggregation, CATV distribution and campus backbones requiring cost-effective wavelength expansion.
Q
How do I install the E1MG-CWDM80-1550?
A
Mount the unit in a 19″ rack, secure with screws, connect SC/UPC fiber pigtails per channel labeling, and route common fibers to your OLT/ROADM.
Q
Is the E1MG-CWDM80-1550 compatible with other CWDM or DWDM equipment?
A
Yes. It interoperates with any G.694.2-compliant CWDM and can be cascaded with DWDM systems when using appropriate multiplexers.
Q
Does the E1MG-CWDM80-1550 require external power?
A
No. As a passive optical mux/demux, it operates without electrical power, reducing rack-space and power budget requirements.
Q
What warranty and support are provided?
A
The E1MG-CWDM80-1550 includes a 5-year factory warranty and lifetime technical support through our certified global service network.
