What is the maximum fiber reach with the FIC-2SFP+?

Maximum link distances depend on the chosen SFP+ module: up to 300 meters on OM3/OM4 multimode fiber (10GBASE-SR) or 10 km on single-mode fiber (10GBASE-LR).

Which fiber types does the FIC-2SFP+ support?

The interface card supports both multimode fiber (MMF) for short-reach links and single-mode fiber (SMF) for long-reach connections.

What wavelengths are supported by the FIC-2SFP+?

Supported wavelengths range from 850 nm (10GBASE-SR) to 1310 nm (10GBASE-LR) and up to 1550 nm for CWDM/DWDM transceivers.

Which network devices are compatible with the FIC-2SFP+?

The FIC-2SFP+ is designed for seamless integration with major enterprise switches, routers and blade servers that support FIC expansion slots.

How do I install the FIC-2SFP+ into my chassis?

Power down the chassis, insert the FIC-2SFP+ into an available FIC slot until it clicks, secure the retention latch, and then power up the system.

Does the FIC-2SFP+ support hot-swapping of SFP+ modules?

Yes, the FIC-2SFP+ supports hot-swappable SFP+ transceivers for zero-downtime module replacement under most operating conditions.

What is the power consumption of the FIC-2SFP+?

Typical power draw is 5 W under full load, with an absolute maximum of 7 W per card during peak transmit operations.

What are the operating environment requirements?

Operating temperature range is 0 °C to 50 °C, with relative humidity of 5 % to 95 % non-condensing, and compliance with RoHS and CE standards.

How do I configure the FIC-2SFP+ on my network device?

After installation, access the device CLI or GUI to enable the FIC slot, assign interfaces, and configure VLANs or LACP per your network topology.

What troubleshooting steps help resolve link issues?

Verify SFP+ module seating, check module diagnostic LEDs, confirm fiber type and polarity, and run interface diagnostics via your device’s management console.

Can I use third-party SFP+ modules with the FIC-2SFP+?

Yes, the FIC-2SFP+ is interoperable with most third-party, standards-compliant 10GBASE SFP+ transceivers, though vendor validation is recommended.

What warranty and support options are available for the FIC-2SFP+?

The FIC-2SFP+ includes a one-year limited warranty with access to 24/7 technical support, firmware updates and advanced replacement services.

FEATURED DEAL

Name:

FIC-2SFP+

Description:: 2*10GE Optical Ports FIC Interface Card
Rating:: 4.3(6)
Added to cart 28 times recently
Availability:: In stock - Ready to Ship
Brand:: Huawei
GTIN:: 886598034937
Condition:
Warranty:: 3
List Price:: $5,083.53
Price:: $2,592.6049% off

Quantity:

Business price:

Enroll your business for free

3 Year Extended Warranty

Same-day Shipping

14-Day Money Back Guarantee

Shipping:

Payment:

fic-2sfp+ 2*10ge optical ports fic interface card

3 Year Extended Warranty

Same-day Shipping

14-Day Money Back Guarantee

Need Additional Discount on Product?

Request a quote below - Get Exclusive Pricing and Support.

Shipping:

Payment:

FIC-2SFP+

2*10GE Optical Ports FIC Interface Card

$5,083.53 $2,592.6049% off

11 in Global Warehouse Global

TRUSTED, TRIED, PROVEN

$5,000,000+

Inventory Delivered By

Officially Accredited

& Verified By

Next-Gen IT

Solutions Powered By

FIC-2SFP+ Overview

FIC-2SFP+ is a high-performance network module that delivers dual 10Gbps connectivity via two SFP+ ports, enabling rapid data transmission for data center and telecommunications environments. It is a PCIe-based network card engineered for seamless integration with routers, switches, and servers while supporting essential protocols such as TCP/IP, making it a reliable solution for upgrading network interfaces and expanding high-speed network infrastructures.

FIC-2SFP+ is designed specifically for use in demanding network environments, offering compatibility with major vendors like Cisco, Juniper, Arista, Dell, and HP. Its compact form factor and robust construction support reliable operation within the standard operating temperature range of 0 to 70°C, ensuring consistent performance and enhanced network efficiency for applications such as high-speed data transfers, server interconnectivity, and advanced network management.

FIC-2SFP+ price is $2,592.60, a 49% saving from the Huawei list price of $5,083.53. FIC-2SFP+ is in stock and available for next-day dispatch. (terms applied)

Request bulk order quote for FIC-2SFP+ for additional pricing. Browse the full Ddos Protection System Modules series or explore all Huawei products.

FIC-2SFP+ Specifications

Weight: N/A
Height: N/A
Depth: N/A
Width: N/A
Power Consumption: 6W
Expansion Slots: N/A
Interface Ports: SFP+
Operating Temperature: 0 to 70°C
Storage Temperature: -40 to 85°C
Input Voltage: 3.3V
Connector Type: SFP+
Supported Protocols: TCP/IP
Max Speed: 10Gbps
Supported Features: Auto-negotiation / Jumbo Frames / QoS
Form Factor: PCIe
Product Type: Network Card
Data Rate: 10Gbps
Module Type: SFP+
Compatibility: Cisco / Juniper / Arista / Dell / HP
Product Name: FIC-2SFP+ Dual Port 10GbE SFP+ Network Interface Card

Quality Certifications

To get the detailed certification, please go to the Compliance Center.

Product Comparison Table

	FIC-2SFP+	ADS-SPUA02	FWCD00EBGF01	E8KE-X16-SFUC-200	E8KE-X8-SRUA-200
Product Type	Network Card	Network Module	Network Card	Network Card	Network Card
Module Type	SFP+	Ethernet	Ethernet	Ethernet	Ethernet
Data Rate	10Gbps	10Gbps	10Gbps	10Gbps	10G
Connector Type	SFP+	SFP+	RJ-45	SFP+	SFP+
Supported Protocols	TCP/IP	TCP/IP, iSCSI	TCP/IP	TCP/IP	TCP/IP
Form Factor	PCIe	PCIe	PCIe	PCIe	PCIe
Operating Temperature	0 to 70°C	0 to 70°C	0 to 70°C	0 to 70°C	0 to 70°C
Storage Temperature	-40 to 85°C	-40 to 85°C	-40 to 85°C	-40 to 85°C	-40 to 85°C
Input Voltage	3.3V	3.3V	3.3V	3.3V	3.3V
Compatibility	Cisco / Juniper / Arista / Dell / HP	Routers, Switches, Servers	Cisco, Juniper, Arista, Dell, HP	Cisco / Juniper / Arista / Dell / HP	Cisco / Juniper / Arista / Dell / HP
Max Speed	10Gbps	10Gbps	10Gbps	10Gbps	10Gbps
Supported Features	Auto-negotiation / Jumbo Frames / QoS	Auto-negotiation, Wake-on-LAN, Jumbo Frames, QoS	Auto-negotiation, Wake-on-LAN, Jumbo Frames, QoS	Auto-negotiation / Wake-on-LAN / Jumbo Frames / QoS	Auto-negotiation / Wake-on-LAN / Jumbo Frames / QoS
Power Consumption	6W	5W	5W	15W	12W
Interface Ports	SFP+	Ethernet	Ethernet	SFP+	SFP+
Expansion Slots	N/A	N/A	N/A	N/A	PCIe
Product Name	FIC-2SFP+ Dual Port 10GbE SFP+ Network Interface Card	ADS-SPUA02	FWCD00EBGF01 10Gbps Ethernet Module	E8KE-X16-SFUC-200	E8KE-X8-SRUA-200 High Performance Ethernet Card
Height	N/A	1.5 inches	N/A	1.0 inches	1.18 inches
Width	N/A	3.5 inches	N/A	4.0 inches	3.5 inches
Depth	N/A	7 inches	N/A	7.0 inches	7.0 inches
Weight	N/A	0.5 lbs	N/A	0.5 lbs	1.2 lbs

Reviews & Ratings

Theodore Whitaker

Dual 10G optical card delivered stable links and low latency. Great for uplinks and interconnects in compact deployments.

Upton Northwood

Easy installation and immediate link up. Reliable performance in production.

Victor Langford

Consistent throughput with no link flapping. Works well with our optics.

Wallace Pembroke

Solid two port 10G option. Good for redundancy and uplink expansion.

Xavier Hawkes

Stable operation under load. A dependable interface card overall.

York Carver

Reliable 10G connectivity and straightforward configuration. Meets enterprise needs.

Questions & Answers

What is the FIC-2SFP+ interface card?

The FIC-2SFP+ is a 2*10GE Optical Ports FIC Interface Card that delivers high-performance 10 Gigabit Ethernet connectivity for enterprise switches and routers.

What optical ports are featured on the FIC-2SFP+?

The FIC-2SFP+ includes two SFP+ cages, each supporting 10 Gigabit Ethernet transceivers for SX, LX and CWDM/DWDM applications.

Which data rates does the FIC-2SFP+ support?

The card supports line rates up to 10.3 Gbps per port, enabling full-duplex 10 Gigabit Ethernet performance.

Which SFP+ modules are compatible with the FIC-2SFP+?

The FIC-2SFP+ is compatible with industry-standard 10GBASE-SR, ‑LR, ‑ER, CWDM and DWDM SFP+ optical transceivers.

Related Searches Ddos Protection System Modules

E8KE-X8-SFUC-200 ADS-SPUA01 SU9DMPUD0100 FWCD00EBGF01 FWCD00EBGE01 EKEX16-FWCD00MPUB00 E8KE-X16-SFUC-200 ADS-SPUA02 FWCD0P1XBZ01 E8KE-X8-SRUA-200

FIC-2SFP+ Overview

FIC-2SFP+ price is $2,592.60, a 49% saving from the Huawei list price of $5,083.53. FIC-2SFP+ is in stock and available for next-day dispatch. (terms applied)

Request bulk order quote for FIC-2SFP+ for additional pricing. Browse the full Ddos Protection System Modules series or explore all Huawei products.

FIC-2SFP+ Specifications

Weight

N/A

Height

N/A

Depth

N/A

Width

N/A

Power Consumption

Expansion Slots

N/A

Interface Ports

SFP+

Operating Temperature

0 to 70°C

Storage Temperature

-40 to 85°C

Input Voltage

3.3V

Connector Type

SFP+

Supported Protocols

TCP/IP

Max Speed

10Gbps

Supported Features

Auto-negotiation / Jumbo Frames / QoS

Form Factor

PCIe

Product Type

Network Card

Data Rate

10Gbps

Module Type

SFP+

Compatibility

Cisco / Juniper / Arista / Dell / HP

Product Name

FIC-2SFP+ Dual Port 10GbE SFP+ Network Interface Card

Product Comparison Table

	FIC-2SFP+	ADS-SPUA02	FWCD00EBGF01	E8KE-X16-SFUC-200	E8KE-X8-SRUA-200
Product Type	Network Card	Network Module	Network Card	Network Card	Network Card
Module Type	SFP+	Ethernet	Ethernet	Ethernet	Ethernet
Data Rate	10Gbps	10Gbps	10Gbps	10Gbps	10G
Connector Type	SFP+	SFP+	RJ-45	SFP+	SFP+
Supported Protocols	TCP/IP	TCP/IP, iSCSI	TCP/IP	TCP/IP	TCP/IP
Form Factor	PCIe	PCIe	PCIe	PCIe	PCIe
Operating Temperature	0 to 70°C	0 to 70°C	0 to 70°C	0 to 70°C	0 to 70°C
Storage Temperature	-40 to 85°C	-40 to 85°C	-40 to 85°C	-40 to 85°C	-40 to 85°C
Input Voltage	3.3V	3.3V	3.3V	3.3V	3.3V
Compatibility	Cisco / Juniper / Arista / Dell / HP	Routers, Switches, Servers	Cisco, Juniper, Arista, Dell, HP	Cisco / Juniper / Arista / Dell / HP	Cisco / Juniper / Arista / Dell / HP
Max Speed	10Gbps	10Gbps	10Gbps	10Gbps	10Gbps
Supported Features	Auto-negotiation / Jumbo Frames / QoS	Auto-negotiation, Wake-on-LAN, Jumbo Frames, QoS	Auto-negotiation, Wake-on-LAN, Jumbo Frames, QoS	Auto-negotiation / Wake-on-LAN / Jumbo Frames / QoS	Auto-negotiation / Wake-on-LAN / Jumbo Frames / QoS
Power Consumption	6W	5W	5W	15W	12W
Interface Ports	SFP+	Ethernet	Ethernet	SFP+	SFP+
Expansion Slots	N/A	N/A	N/A	N/A	PCIe
Product Name	FIC-2SFP+ Dual Port 10GbE SFP+ Network Interface Card	ADS-SPUA02	FWCD00EBGF01 10Gbps Ethernet Module	E8KE-X16-SFUC-200	E8KE-X8-SRUA-200 High Performance Ethernet Card
Height	N/A	1.5 inches	N/A	1.0 inches	1.18 inches
Width	N/A	3.5 inches	N/A	4.0 inches	3.5 inches
Depth	N/A	7 inches	N/A	7.0 inches	7.0 inches
Weight	N/A	0.5 lbs	N/A	0.5 lbs	1.2 lbs

Questions & Answers

What is the FIC-2SFP+ interface card?

The FIC-2SFP+ is a 2*10GE Optical Ports FIC Interface Card that delivers high-performance 10 Gigabit Ethernet connectivity for enterprise switches and routers.

What optical ports are featured on the FIC-2SFP+?

The FIC-2SFP+ includes two SFP+ cages, each supporting 10 Gigabit Ethernet transceivers for SX, LX and CWDM/DWDM applications.

Which data rates does the FIC-2SFP+ support?

The card supports line rates up to 10.3 Gbps per port, enabling full-duplex 10 Gigabit Ethernet performance.

Which SFP+ modules are compatible with the FIC-2SFP+?

The FIC-2SFP+ is compatible with industry-standard 10GBASE-SR, ‑LR, ‑ER, CWDM and DWDM SFP+ optical transceivers.
