Name: Huawei RH5885 V3 Server Bundle (Including Chassis, SM211 Onboard NIC, Intel Xeon 4*E7-4830 v4 Processor, SR120 and DDR4 RDIMM 4*16GB Memory)
Brand: Huawei
SKU: Huawei RH5885 V3 Server Chassis with E7-4830 v4 Processor
Rating: 4.8 (6 reviews)

Question 1

What is the Huawei RH5885 V3 Server Chassis with E7-4830 v4 Processor?

Accepted Answer

The Huawei RH5885 V3 is a 4U rack-mount server chassis bundled with four Intel Xeon E7-4830 v4 processors, SM211 onboard NIC, SR120 RAID card, and 4×16 GB DDR4 RDIMM memory modules for high-performance computing.

Question 2

How many CPU cores and threads does the RH5885 V3 bundle support?

Accepted Answer

Each Intel Xeon E7-4830 v4 processor provides 14 cores and 28 threads, delivering a total of 56 cores and 112 threads in the four-CPU configuration.

Question 3

What type and capacity of memory come with this server bundle?

Accepted Answer

The bundle includes four 16 GB DDR4 RDIMM modules, totaling 64 GB of ECC-protected memory, with support for up to 2 TB across sixteen DIMM slots.

Question 4

Which network interface is onboard the Huawei RH5885 V3?

Accepted Answer

The server features the SM211 onboard NIC, offering dual 10 GbE ports for high-throughput network connectivity out of the box.

Question 5

What are the primary storage expansion options?

Accepted Answer

The chassis supports up to eight 3.5″ SAS/SATA hot-swap drives or sixteen 2.5″ trays, expandable via the included SR120 RAID controller for RAID 0/1/5/6/10 configurations.

Question 6

How many PCIe expansion slots are available?

Accepted Answer

The RH5885 V3 chassis provides seven PCIe 3.0 slots (four x16 and three x8) for additional NICs, HBAs, GPUs, or NVMe adapters.

Question 7

What power supply configuration does this server use?

Accepted Answer

It includes two 2000 W hot-swap power modules in a redundant setup, ensuring 80 PLUS Platinum efficiency and continuous uptime during maintenance.

Question 8

What remote management features are available?

Accepted Answer

The server integrates Huawei’s iBMC management controller for remote KVM, virtual media, hardware health monitoring, and firmware updates via a web interface or command-line tool.

Question 9

Which operating systems are compatible with the RH5885 V3?

Accepted Answer

The server is certified for Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, CentOS, VMware vSphere, and most major Linux distributions.

Question 10

What virtualization platforms can it efficiently run?

Accepted Answer

With its multi-socket, large memory design, the RH5885 V3 excels on VMware vSphere, Microsoft Hyper-V, and KVM for dense virtual machine and container workloads.

Question 11

What are the physical dimensions and rack requirements?

Accepted Answer

The server occupies 4U in a standard 19″ rack, measuring 483×650×177 mm (W×D×H) and requires front and rear clearance for cooling airflow.

Question 12

How energy-efficient is the Huawei RH5885 V3?

Accepted Answer

With 80 PLUS Platinum power supplies, advanced fan controls, and dynamic processor C-states, the chassis maximizes performance per watt under varied workloads.

Question 13

What typical use cases suit this server bundle?

Accepted Answer

Ideal for large-scale databases, in-memory analytics, ERP systems, virtualization farms, and business-critical applications requiring high CPU and memory capacity.

Question 14

What warranty and support options are available?

Accepted Answer

Huawei offers a standard 3-year on-site warranty, optional 24/7 premium support, and customizable hardware maintenance service level agreements (SLAs).

Question 15

How do I install additional memory or drives?

Accepted Answer

After powering down and grounding, open the front bezel, unlock drive carriers for storage, or remove top cover to access DIMM slots; follow Huawei’s Quick Start Guide for safe upgrades.

Question 16

Can this server bundle handle GPU accelerators?

Accepted Answer

Yes, the RH5885 V3 chassis supports low-profile GPUs or accelerators in its PCIe slots, enabling AI, HPC, and graphics-intensive workloads when paired with suitable power modules.

	Huawei RH5885 V3 Server Chassis with E7-4830 v4 Processor	Huawei RH5885 V3 Server Chassis with E7-4850 v4 Processor	Huawei RH2288 V3 Server with E5-2620 V4 Processor, 16GB DDR4, 600GB 10K SAS, SR130 Raid Card, 460W PS	Huawei RH2288H V3 Server with E5-2620 V4 Processor, 16GB DDR4, 600GB 10K SAS, SR130 Raid Card, 460W PS	BC1M23EC07
CPU Socket	LGA 2011	LGA 4677	N/A	N/A	LGA 4189
Cooling	Active	Active	Active	Active	Active
Depth	28 inches	30 inches	28.3 inches	28.7 inches	28
Drive Bay Size	Mixed	3.5-inch	2.5-inch	2.5-inch	2.5-inch
Form Factor	Rackmount	Rackmount	Rackmount	Rackmount	Rackmount
GPU Support	Yes	Yes	No	No	Yes
Height	7 inches	7 inches	3.5 inches	3.5 inches	3.5
Hot-Swap Support	Yes	Yes	Yes	Yes	Yes
LAN Ports	2	4	2	2	2
Max Cores per CPU	12	24	8	8	32
Max RAM Capacity	2 TB	6 TB	1 TB	1 TB	1 TB
Max Threads per CPU	24	48	16	16	64
Network Interface	1GbE	10GbE	1GbE	1GbE	10GbE
Operating System	Windows Server / VMware ESXi / Ubuntu / RHEL / SUSE / CentOS	VMware ESXi	No OS	Windows Server	Windows Server
PCIe Slots	4	6	6	3	4
PCIe Version	PCIe 3.0	PCIe 3.0	PCIe 3.0	PCIe 3.0	PCIe 4.0
Power Supply	Redundant	Redundant	Single	Single	Redundant
Power Supply Wattage	750W	1600W	460W	460W	1200W
Processor Brand	Intel	Intel	Intel	Intel	Intel
Processor Generation	Xeon 4th Gen	Xeon 4th Gen	Xeon 4th Gen	Xeon 4th Gen	Xeon 3rd Gen
Processor Series	Intel Xeon E	Intel Xeon E	Intel Xeon E	Intel Xeon E	Intel Xeon Scalable
Product Name	Huawei RH5885 V3 Server Chassis with E7-4830 v4 Processor	Huawei RH5885 V3 Server Chassis with E7-4850 v4 Processor	Huawei RH2288 V3 Server with E5-2620 V4 Processor, 16GB DDR4, 600GB 10K SAS, SR130 Raid Card, 460W PS	Huawei RH2288H V3 Server with E5-2620 V4 Processor, 16GB DDR4, 600GB 10K SAS, SR130 Raid Card, 460W PS	BC1M23EC07
Product Type	Server	Server	Server	Server	Server
RAID Support	RAID 0 / RAID 1 / RAID 5 / RAID 10	RAID 10	RAID 0 / RAID 1 / RAID 10	RAID 0 / RAID 1 / RAID 10	RAID 10
RAM Slots	16	32	8	24	16
RAM Type	ECC DDR4	ECC DDR4	ECC DDR4	DDR4	ECC DDR4
Rack Units	4U	4U	2U	2U	2U
Rail Kit Included	Yes	Yes	Yes	Yes	Yes
Remote Management	IPMI	IPMI	IPMI	IPMI	iDRAC
Scalability	2P	1P	2P	2P	2P
Storage Bays	8	8	8	8	8
Storage Type	Mixed	SAS HDD	SAS HDD	SAS HDD	NVMe SSD
Use Case	Virtualization / File Server / Application Server	Virtualization	Virtualization	Virtualization / File Server / Application Server	Virtualization
Virtualization Ready	Yes	Yes	Yes	Yes	Yes
Weight	75 lbs	100 lbs	70 lbs	81 lbs	45
Width	19 inches	19 inches	17.5 inches	17.5 inches	17

Huawei RH5885 V3 Server Chassis with E7-4830 v4 Processor
