ICX7450-48P

Specification Of ICX7450-48P

Design
Rack mounting	Yes
Stackable	Yes
Form factor	1U
Product colour	Black
LED indicators	Yes
Management features
Switch type	Managed
Switch layer	L2/L3
Quality of Service (QoS) support	Yes
Web-based management	Yes
ARP inspection	Yes
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity	48
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
SFP+ module slots quantity	12
QSFP+ module slots quantity	2
Console port	USB
Power over Ethernet (PoE)
Power over Ethernet (PoE)	Yes
Power over Ethernet (PoE) type supported	PoE+
Power over Ethernet plus (PoE+) ports quantity	48
Data transmission
MAC address table	32768 entries
Switching capacity	336 Gbit/s
Forwarding rate	250 Mpps
Jumbo frames support	Yes
Jumbo frames	9216
Packet buffer memory	8 MB
Protocols
Management protocols	SNMPv1/v2c/v3, TFTP, TELNET, Bootp, HTTPS
Supported network protocols	IPv4 / IPv6
Network
Networking standards	IEEE 802.1D,IEEE 802.1Q,IEEE 802.1ab,IEEE 802.1p,IEEE 802.1s,IEEE 802.1w,IEEE 802.1x,IEEE 802.3,IEEE 802.3ab,IEEE 802.3ae,IEEE 802.3at,IEEE 802.3az,IEEE 802.3u,IEEE 802.3x,IEEE 802.3z
10G support	Yes
Port mirroring	Yes
Full duplex	Yes
Flow control support	Yes
Link aggregation	Yes
Broadcast storm control	Yes
Rate limiting	Yes
Auto MDI/MDI-X	Yes
Spanning tree protocol	Yes
VLAN support	Yes
Number of VLANs	4096
Power
Power supply included	No
Redundant power supply (RPS) support	Yes
AC input voltage	100 - 240 V
AC input frequency	50/60 Hz
Power consumption (max)	935 W
Performance
Physical stacking (units)	12
Internal memory	2048 MB
Flash memory	2048 MB
Noise level	49 dB
Mean time between failures (MTBF)	444360 h
Multicast features
Multicast support	Yes
Security
DHCP features	DHCP relay,DHCP server,DHCP snooping
Access Control List (ACL)	Yes
IGMP snooping	Yes
IGMP proxy	Yes
Security algorithms	802.1x RADIUS,AES,EAP
Operational conditions
Operating temperature (T-T)	-5 - 50 °C
Storage temperature (T-T)	-40 - 70 °C
Operating relative humidity (H-H)	10 - 90 %
Storage relative humidity (H-H)	5 - 95 %
Operating altitude	0 - 3000 m
Non-operating altitude	0 - 10000 m
Heat dissipation	386 BTU/h
Weight & dimensions
Width	440 mm
Depth	393.7 mm
Height	43.7 mm
Weight	7.2 kg
