MCB2224TAF3

Specification Of MCB2224TAF3

General
Type	PC barebone
Product Form Factor	Mini PC
Sensors	Infrared (IR) sensor
Localisation	Region: Europe

Processor / Chipset
CPU	Intel Core i3 (10th Gen) 10110U
Clock Speed	2.1 GHz
Max Turbo Speed	4.1 GHz
Number of Cores	Dual-Core
CPU Qty	1
Max CPU Qty	1
CPU Upgradability	Not upgradable
Processor Main Features	Intel Virtualization Technology, Intel AES New Instructions, Intel Platform Trust Technology (PTT)

Cache Memory
Installed Size	L3 Cache - 4 MB
Cache Per Processor	4 MB

RAM
Installed Size	0 GB / 64 GB (max)
Technology	DDR4 SDRAM
Form Factor	SO-DIMM 260-pin
Slots	2 (Total) / 2 (empty)
Features	Dual channel memory architecture

Hard Drive
Type	No HDD

Storage Controller
Type	SATA
Controller Interface Type	SATA 6Gb/s / PCIe 3.0 x4 (NVMe)
RAID Level	RAID 0, RAID 1

Optical Storage
Type	No optical drive

Card Reader
Type	Card reader
Supported Flash Memory Cards	SDXC UHS-II Memory Card

Monitor
Monitor Type	None.

Graphics Controller
Graphics Processor	Intel UHD Graphics
Video Interfaces	HDMI, USB-C
Max Monitors Supported	3

Audio Output
Sound Output Mode	7.1 channel surround
Compliant Standards	High Definition Audio

Networking
Ethernet Controller	Intel I219-V
Wireless LAN Supported	Yes
Wireless NIC	Intel Wireless-AX MAC
Data Link Protocol	Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, Bluetooth 5.0, IEEE 802.11ax (Wi-Fi 6)
Compliant Standards	IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, Bluetooth 5.0, IEEE 802.11ax, Wi-Fi CERTIFIED 6

Expansion / Connectivity
Bays	1 (total) / 1 (free) x internal 2.5"
Slots	1 (total) / 1 (free) x M.2 Card - 2242/2280 (Key M)
Interfaces	3 x USB 3.1 Gen 2 - Type A (1 front, 2 rear) - 2 x Thunderbolt 3/USB-C 3.1 Gen 2 - Type C (1 front, 1 rear) (one of them is fast-charging) - 1 x HDMI - 1 x LAN (Gigabit Ethernet) - RJ-45

Miscellaneous
Theft/Intrusion Protection	Security lock slot (cable lock sold separately)
Security Slot Type	Kensington security slot
Compliant Standards	CISPR 24, ICES-003, EN55024, FCC Part 15 B, FCC Part 15 C, AS/NZS 4268, FCC Part 15 E, BSMI CNS 13438, REACH, EN 62311, EN 300.440, China RoHS, EN 300 328, EN 301 489-1, CISPR32/EN55032, KN32, KN35, AS/NZS 2772.2, EN 301 893, IEC/EN/UL 60950-1, EN 301 489-3, EU RoHS, IEC/EN/UL 62368-1, EN 301 489-17, ARPANSA, Taiwan BSMI RoHS, AS/NZS CISPR 32, VCCI 32

Power
Device Type	Power adapter
Voltage Required	DC 19 V
Power Provided	90 Watt

Manufacturer Warranty
Service & Support	Limited warranty - 3 years

Dimensions & Weight
Width	11.7 cm
Depth	11.2 cm
Height	5.1 cm

Environmental Parameters
Min Operating Temperature	0 °C
Max Operating Temperature	35 °C
