What is the Dell PowerEdge R620 Server?
A
The Dell PowerEdge R620 is a 1U rack-mount server engineered for high performance, density and efficiency in enterprise data centers.
Q
Which Intel Xeon processors are supported by the R620?
A
The R620 supports dual Intel Xeon E5-2600 series processors, including up to two 12-core CPUs for heavy-compute workloads.
Q
What is the maximum memory capacity of the PowerEdge R620?
A
It supports up to 24 DDR3 RDIMM or LRDIMM slots for a total of 768 GB of system memory.
Q
What storage configurations are available on the R620?
A
The server offers up to ten 2.5\
Q
Which RAID controllers are compatible with the R620?
A
It supports Dell PERC H710 and H710P RAID controllers (RAID 0/1/5/6/10/50/60) as well as the basic S130 software RAID.
Q
What networking and expansion options does the R620 include?
A
Integrated dual Broadcom 5716 gigabit NICs with optional 10 GbE add-in cards, plus four PCIe 3.0 slots for expansion.
Q
How many PCIe slots are available in the PowerEdge R620?
A
The R620 features three PCIe 3.0 slots: two x8 slots and one x16 slot for add-in cards.
Q
What are the form factor and dimensions of the R620?
A
It is a 1U rack server measuring 42.8 cm in depth, designed to fit standard 19-inch server racks.
Q
What power supply options and efficiency ratings are offered?
A
The R620 supports dual hot-swappable 495 W, 750 W or 1100 W PSUs with 80 PLUS Platinum efficiency.
Q
What cooling and thermal management features does the R620 have?
A
Front-to-back variable-speed fans, optional dust filters and intelligent airflow control maintain optimal operating temperatures.
Q
Is the PowerEdge R620 suitable for virtualization workloads?
A
Yes. It is optimized for virtualization with Intel VT-x/VT-d support, high memory capacity and low-latency networking options.
Q
What remote management tools are included with the R620?
A
Integrated iDRAC7 with Lifecycle Controller provides agent-free monitoring, configuration, firmware updates and automated alerts.
Q
Which operating systems and hypervisors are supported?
A
The R620 is certified for Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware ESXi and Citrix XenServer.
Q
How do I configure RAID arrays on the R620?
A
Enter the PERC BIOS Configuration Utility (CTRL+R during POST) or use Dell OpenManage Server Administrator to create and manage RAID volumes.
Q
How can I update firmware and drivers on the PowerEdge R620?
A
Use the iDRAC7 Lifecycle Controller for inband updates or Dell Repository Manager to deploy firmware and driver packages for Windows and Linux.
Q
What warranty and support options are available?
A
Dell ProSupport offers a 3-year limited hardware warranty with next-business-day on-site service; upgrades to 4-hour or 24×7 coverage are available.
Q
What are the typical use cases for the Dell PowerEdge R620?
A
The R620 excels in virtualization consolidation, database servers, HPC clusters, web hosting and scalable enterprise applications.
