Q
What types of transceiver modules are compatible with HPE ProCurve switches?
A
HPE ProCurve switches support 1GbE SFP, 10GbE SFP+, 40GbE QSFP+ and 100GbE QSFP28 modules for both single-mode and multimode fiber.
Q
How do I select the correct HPE ProCurve transceiver for my network?
A
Identify your required data rate, fiber type (single-mode or multimode), transmission distance and matching switch port to choose the appropriate HPE ProCurve part number.
Q
What is the maximum data rate supported by HPE ProCurve transceivers?
A
HPE ProCurve transceivers support up to 100 GbE via QSFP28, with additional options for 1 GbE, 10 GbE and 40 GbE modules.
Q
What optical wavelengths are available in HPE ProCurve transceivers?
A
Modules are offered at 850 nm for SR, 1310 nm for LR and 1550 nm for ER to optimize multimode and single-mode fiber links.
Q
What is the maximum cable distance for HPE ProCurve SR, LR and ER transceivers?
A
SR modules support up to 300 m on multimode, LR modules up to 10 km on single-mode, and ER modules up to 40 km on single-mode fiber.
Q
Are HPE ProCurve transceivers hot-swappable?
A
Yes. All HPE ProCurve SFP, SFP+ and QSFP modules are hot-swappable, allowing installation or removal without powering down the switch.
Q
How do I install an HPE ProCurve transceiver module?
A
Align the transceiver with the port, insert until it clicks, ensure the latch is secure, then connect the appropriate fiber or copper cable.
Q
How do I verify if my HPE ProCurve switch detects the transceiver?
A
Use the CLI command “show interfaces transceiver” or check the switch’s Web GUI diagnostics to confirm module presence and operational status.
Q
What diagnostic features do HPE ProCurve transceivers support?
A
They offer Digital Diagnostics Monitoring (DDM) for real-time readings of temperature, voltage, optical transmit/receive power and laser bias current.
Q
Are HPE ProCurve transceivers MSA-compliant?
A
Yes. HPE ProCurve transceivers adhere to Multi-Source Agreement (MSA) standards to ensure interoperability across vendor equipment.
Q
Can I use third-party transceivers on HPE ProCurve switches?
A
While third-party modules may function, HPE recommends genuine transceivers to guarantee compatibility, support and warranty coverage.
Q
How do I update the firmware for HPE ProCurve transceivers?
A
Transceiver firmware updates are included with HPE switch OS upgrades. Download the latest switch image from HPE Support and apply via CLI or Web GUI.
Q
What warranty covers HPE ProCurve transceivers?
A
HPE ProCurve transceivers carry a limited lifetime warranty when used under normal conditions with HPE networking hardware.
Q
How do I troubleshoot HPE ProCurve transceiver connectivity issues?
A
Check fiber polarity, clean connectors, review DDM metrics, update switch firmware and confirm module compatibility with your switch model.
Q
How do I reset SFP port settings on an HPE ProCurve switch?
A
Enter “default interface <port>” in the CLI to restore factory settings, then save with “write memory” to clear custom port configurations.
Q
What power consumption should I expect from HPE ProCurve transceivers?
A
Power usage ranges from approximately 0.8 W for 1 GbE SFP modules to 3.5 W for 100 GbE QSFP28 modules; refer to the datasheet for precise values.
Q
How do I dispose of or recycle old HPE ProCurve transceivers?
A
Follow HPE’s environmental and recycling guidelines or use HPE’s Recycling Program; otherwise dispose of electronic waste per local regulations.
