What data rate is supported by the XFP-STM64-SM1550-80km?

This XFP module supports a data rate of 10 Gbps.

Can I hot-swap the XFP-STM64-SM1550-80km without powering down the system?

Yes, the XFP-STM64-SM1550-80km is hot-pluggable and can be inserted or removed without powering down.

What is the typical transmit optical power of this 10G single-mode XFP?

Typical transmit optical power ranges from +3 dBm to +5 dBm.

What is the receiver sensitivity of the XFP-STM64-SM1550-80km module?

Receiver sensitivity is typically –23 dBm, ensuring reliable long-haul performance.

Does the XFP-STM64-SM1550-80km support Digital Diagnostics Monitoring (DDM)?

Yes, it features full Digital Diagnostics Monitoring (DDM) for real-time performance metrics.

What is the operating temperature range of the XFP-STM64-SM1550-80km?

The module operates reliably between 0 °C and +70 °C (commercial temperature range).

Which applications are ideal for the XFP-STM64-SM1550-80km?

It is ideal for long-haul metropolitan networks, campus backbones, and data center interconnects.

Which network equipment is compatible with the XFP-STM64-SM1550-80km?

This XFP module is interoperable with major vendors’ routers, switches, and transport equipment supporting XFP ports.

What is the power consumption of the XFP-STM64-SM1550-80km module?

Power consumption is typically ≤ 3.5 W, meeting industry efficiency standards.

How do I install the XFP-STM64-SM1550-80km in my system?

Simply insert the module into an available XFP slot until it clicks; no additional configuration is required.

Does the XFP-STM64-SM1550-80km require any calibration before use?

No calibration is needed; the module is factory-prealigned and ready for immediate deployment.

What warranty and support are offered for the XFP-STM64-SM1550-80km?

The module comes with a one-year warranty and lifetime technical support from our certified network specialists.

FEATURED DEAL

Name:

XFP-STM64-SM1550-80km

Name: XFP,10G Single-mode Module(1550nm,80km,LC)
Brand: Huawei
SKU: XFP-STM64-SM1550-80km
Price: 862.99 USD
Availability: InStock
Rating: 4.3 (6 reviews)

Description:: XFP,10G Single-mode Module(1550nm,80km,LC)
Rating:: 4.3(6)
Added to cart 28 times recently
Availability:: In stock - Ready to Ship
Brand:: Huawei
GTIN:: 6920702795667
Condition:
Warranty:: 3
List Price:: $5,753.24
Price:: $862.9985% off

Quantity:

Business price:

Enroll your business for free

3 Year Extended Warranty

Same-day Shipping

14-Day Money Back Guarantee

Shipping:

Payment:

xfp-stm64-sm1550-80km xfp,10g single-mode module(1550nm,80km,lc)

3 Year Extended Warranty

Same-day Shipping

14-Day Money Back Guarantee

Need Additional Discount on Product?

Request a quote below - Get Exclusive Pricing and Support.

Shipping:

Payment:

XFP-STM64-SM1550-80km

XFP,10G Single-mode Module(1550nm,80km,LC)

$5,753.24 $862.9985% off

11 in Global Warehouse Global

TRUSTED, TRIED, PROVEN

$5,000,000+

Inventory Delivered By

Officially Accredited

& Verified By

Next-Gen IT

Solutions Powered By

XFP-STM64-SM1550-80km Overview

XFP-STM64-SM1550-80km is an XFP transceiver module engineered for high-speed data communications, supporting a robust 10G data rate and featuring LC connector interfaces. It is designed for long-range transmission over single-mode fiber, delivering reliable performance for extended-reach applications up to 80km.

This compact transceiver is ideal for demanding network environments such as data centers, enterprise networks, and telecom infrastructures. With support for Ethernet and Fibre Channel protocols, XFP-STM64-SM1550-80km ensures high-performance connectivity in mission-critical applications while offering a form factor that conforms to industry standards.

XFP-STM64-SM1550-80km price is $862.99, a 85% saving from the Huawei list price of $5,753.24. XFP-STM64-SM1550-80km is in stock and available for next-day dispatch. (terms applied)

Request bulk order quote for XFP-STM64-SM1550-80km for additional pricing. Browse the full Huawei Transceivers series or explore all Huawei products.

XFP-STM64-SM1550-80km Specifications

Product Type: Transceiver
Form Factor: XFP
Data Rate: 10G
Connector Type: LC
Wavelength: 1550 nm
Transmission Distance: Long-Range
Fiber Type: Single-mode
Max Distance: 80km
Supported Protocols: Ethernet, Fibre Channel
Network Interface: Fiber
Power Consumption: N/A
Operating Temperature: 0 to 70°C
Storage Temperature: -40 to 85°C
Input Voltage: 3.3V
Compatibility: Cisco, Juniper, Huawei, Arista
Product Name: XFP-STM64-SM1550-80km
Height: N/A
Width: N/A
Depth: N/A
Weight: N/A

Quality Certifications

To get the detailed certification, please go to the Compliance Center.

Product Comparison Table

	XFP-STM64-SM1550-80km	OGEBIDI10	OSX040B11	OSL010N01	LE2MXSC80FF0
Product Type	Transceiver	Transceiver	Transceiver	Transceiver	Transceiver
Form Factor	XFP	SFP+	SFP+	SFP+	QSFP28
Data Rate	10G	10G	10G	10G	100G
Connector Type	LC	LC	LC	LC	MPO
Wavelength	1550 nm	1310 nm	1310nm	1310nm	850nm
Transmission Distance	Long-Range	Long-Range	Long-Range	Long-Range	Short-Range
Fiber Type	Single-mode	Single-mode	Single-mode	Single-mode	Multi-mode
Max Distance	80km	80 km	80km	10 km	150 meters
Supported Protocols	Ethernet, Fibre Channel	Ethernet	Ethernet, Fibre Channel	Ethernet	Ethernet, Fibre Channel
Network Interface	Fiber	Fiber	Ethernet	Ethernet	Fiber
Power Consumption	N/A	3.5 W	2.5W	2.2 W	4.5W
Operating Temperature	0 to 70°C	0 to 70°C	0 to 70°C	0 to 70°C	0 to 70°C
Storage Temperature	-40 to 85°C	-40 to 85°C	-40 to 85°C	-40 to 85°C	-40 to 85°C
Input Voltage	3.3V	3.3V	3.3V	3.3V	3.3V
Compatibility	Cisco, Juniper, Huawei, Arista	Cisco / Juniper / Huawei / Arista	Cisco, Juniper, Huawei, Arista	Cisco / Juniper / Huawei / Arista	Cisco, Juniper, Huawei, Arista
Product Name	XFP-STM64-SM1550-80km	OGEBIDI10 High-Speed 10G SFP+ Transceiver	OSX040B11 Optical Transceiver Module	OSL010N01 10G LR SFP+ Optical Transceiver	LE2MXSC80FF0 100G QSFP28 Transceiver Module
Height	N/A	0.48 inches	0.25 inches	0.3 inches	0.87 inches
Width	N/A	0.65 inches	0.60 inches	0.85 inches	0.47 inches
Depth	N/A	1.5 inches	0.75 inches	1.3 inches	1.55 inches
Weight	N/A	0.15 lbs	0.05 lbs	0.1 lbs	0.1 lbs

Reviews & Ratings

Daniel Porter

Stable STM64 transmission over long distances.

Christopher Young

Reliable optical levels for telecom use.

Paul Simmons

Works well in legacy SDH networks.

Mark Lewis

Consistent performance under load.

James Turner

Carrier grade reliability.

Oliver Grant

Solid STM64 XFP optic.

Questions & Answers

What is the maximum transmission distance of the XFP-STM64-SM1550-80km module?

The XFP-STM64-SM1550-80km supports a maximum single-mode fiber link distance of 80 km.

At which wavelength does the XFP-STM64-SM1550-80km operate?

This 10G XFP single-mode module operates at a central wavelength of 1550 nm.

What connector type does the XFP-STM64-SM1550-80km use?

The module uses a duplex LC connector interface for optical fiber connections.

Is the XFP-STM64-SM1550-80km compliant with the XFP MSA standard?

Yes, the XFP-STM64-SM1550-80km is fully compliant with the XFP MSA specification.
