Name: AIRONET 1600 11AGN 54MB 2.4GHZ AND 5GHZ AES INTEGRATED ANT 4DBI
Brand: Cisco
SKU: AIR-CAP1602I-E-K9
Price: 730.00 USD
Availability: InStock

Question 1

What is the Cisco AIR-CAP1602I-E-K9 access point?

Accepted Answer

The Cisco Aironet 1600 Series AIR-CAP1602I-E-K9 is a dual-band 802.11a/g/n lightweight access point with integrated 4 dBi antennas, designed for indoor enterprise WLAN deployments with up to 54 Mbps data rates.

Question 2

What wireless standards does the AIR-CAP1602I-E-K9 support?

Accepted Answer

It supports IEEE 802.11a, 802.11b/g, and 802.11n standards in both 2.4 GHz and 5 GHz bands, ensuring backward compatibility with legacy Wi-Fi devices.

Question 3

What are the maximum data rates of the access point?

Accepted Answer

The AIR-CAP1602I-E-K9 delivers up to 54 Mbps per radio on both 2.4 GHz and 5 GHz bands, supporting single-stream 802.11n connectivity for stable enterprise throughput.

Question 4

Which frequency bands and channels are supported?

Accepted Answer

It operates on the 2.4 GHz band (channels 1–13) and the 5 GHz band (channels 36–165), with dynamic channel allocation for optimized RF performance.

Question 5

What are the specifications of the integrated antennas?

Accepted Answer

The module features dual integrated omnidirectional antennas with 4 dBi gain per band, providing broad indoor coverage without external antennas.

Question 6

Does the AIR-CAP1602I-E-K9 support Power over Ethernet?

Accepted Answer

Yes, it supports IEEE 802.3af Power over Ethernet, enabling flexible installation and simplified cabling in enterprise environments.

Question 7

What security protocols are supported?

Accepted Answer

The access point supports WPA2-Enterprise, 802.1X authentication, AES encryption, and TKIP, ensuring robust wireless security and compliance.

Question 8

Which management platforms are compatible?

Accepted Answer

It is managed by Cisco Wireless LAN Controllers running Cisco IOS Release 7.0 or later, and integrates with Cisco Prime Infrastructure for centralized WLAN management.

Question 9

What deployment modes are available?

Accepted Answer

Deployment modes include Lightweight Access Point (CAPWAP), FlexConnect, Rogue Detector, and Sniffer, allowing versatile network topologies and distributed deployments.

Question 10

What is the typical indoor coverage range?

Accepted Answer

The AIR-CAP1602I-E-K9 typically covers up to 100 meters indoors, subject to building materials and RF environment.

Question 11

What environmental operating conditions does it support?

Accepted Answer

It operates in temperatures from 0 °C to 40 °C (32 °F to 104 °F) and humidity from 10 % to 90 % non-condensing, compliant with standard enterprise environments.

Question 12

What firmware or software version is required?

Accepted Answer

It requires Cisco WLC software version 7.0 or later for full feature support and must run the matching AP image for the WLC code.

Question 13

How many client associations can it handle?

Accepted Answer

The access point supports up to 64 client associations per radio, allowing up to 128 simultaneous client connections across both bands.

Question 14

What mounting options and form factor are available?

Accepted Answer

It features a low-profile ceiling or wall mount bracket, designed for discreet indoor installations in offices or public venues.

Question 15

What are the dimensions and weight?

Accepted Answer

Dimensions are 165 mm x 165 mm x 31 mm, and it weighs approximately 0.6 kg (1.32 lb), facilitating easy handling and deployment.

Question 16

What warranty and support options are available?

Accepted Answer

Cisco provides a one-year limited hardware warranty with next-business-day replacement. Cisco Smart Net Total Care is available for extended support and software updates.

Question 17

How can I migrate from older Aironet models to the AIR-CAP1602I-E-K9?

Accepted Answer

Use a Cisco Wireless LAN Controller with a unified code base. Adopt the new AP via CAPWAP, ensure compatible WLC and AP firmware, and apply existing RF profiles and security policies.

	AIR-CAP1602I-E-K9	AIR-CAP1602I-RK910	AIR-SAP1602E-C-K9	AIR-CAP1602E-S-K9	AIR-SAP1602I-CK9-5
Product Type	Wireless Access Point	Wireless Access Point	Wireless Access Point	Wireless Product	Wireless Access Point
Wireless Type	Access Point	Access Point	Access Point	Access Point	Access Point
Wi-Fi Standard	802.11a/b/g/n/ac	Wi-Fi 6	Wi-Fi 5	Wi-Fi 5	Wi-Fi 6
Frequency Bands	Dual-Band (2.4GHz & 5GHz)	2.4GHz/5GHz	2.4GHz / 5GHz	2.4GHz / 5GHz	2.4GHz / 5GHz
Data Rate	1.2Gbps	2.5Gbps	Up to 1.8Gbps	1Gbps	2.5Gbps
Max Range	N/A	N/A	N/A	100 meters	100 meters
Coverage Area	N/A	N/A	N/A	2000 square feet	5000 square feet
Connector Type	RJ-45	RJ-45	N/A	RJ-45	RJ-45
Antenna Type	Internal Omnidirectional	Omnidirectional	Omnidirectional	Internal Omnidirectional	Omnidirectional
Antenna Gain	N/A	5dBi	N/A	N/A	5dBi
MIMO Technology	MU-MIMO	MU-MIMO	MU-MIMO	MU-MIMO	MU-MIMO
Beamforming	Yes	Yes	Yes	Yes	Yes
Mounting Options	Ceiling Mount, Wall Mount	Ceiling Mount / Wall Mount	Ceiling Mount	Ceiling Mount, Wall Mount	Ceiling Mount / Wall Mount
Power Supply	PoE	PoE	PoE	PoE	PoE
Mesh Networking	No	No	No	No	No
Ethernet Port	1x Gigabit	1x Gigabit	1x Gigabit	1x Gigabit	1x Gigabit
Max Number of Devices Supported	N/A	N/A	N/A	N/A	N/A
Protocols Supported	802.11a/b/g/n/ac	802.11a/b/g/n/ac/ax	802.11a/b/g/n/ac	802.11a/b/g/n/ac	802.11ax / 802.11a/b/g/n/ac
Management Features	On-Premises	Cloud Management	On-Premises / SNMP	Cloud Management, SNMP	Cloud Management / On-Premises / SNMP
Security Features	WPA2, WPA3, 802.1X	WPA2, WPA3, 802.1X	WPA2 / WPA3 / 802.1X	WPA2, WPA3, 802.1X	WPA2 / WPA3 / 802.1X / VPN
Compliance	FCC, CE, RoHS	FCC, CE, RoHS	FCC / CE / RoHS	FCC, CE, RoHS	FCC / CE / RoHS
Processor	N/A	N/A	N/A	N/A	N/A
Memory	N/A	N/A	N/A	N/A	N/A
Outdoor Use	No	No	No	No	No
Product Name	AIR-CAP1602I-E-K9	AIR-CAP1602I-RK910 Wireless Access Point	AIR-SAP1602E-C-K9	AIR-CAP1602E-S-K9 Wireless Access Point	AIR-SAP1602I-CK9-5
Height	N/A	N/A	N/A	N/A	N/A
Width	N/A	N/A	N/A	N/A	N/A
Depth	N/A	N/A	N/A	N/A	N/A
Weight	N/A	N/A	N/A	N/A	N/A
