BK782A Overview
BK782A is a high-performance SAN storage system featuring 12-bay drive capacity that supports SATA HDD, SAS HDD, SATA SSD, and NVMe SSD drives. It offers a total storage capacity of 1 PB with RAID configurations including RAID 0, RAID 1, RAID 5, RAID 6, and RAID 10; powered by an Intel Xeon 8-core processor with 32 GB pre-installed memory, expandable up to 128 GB.
BK782A is engineered for SMB backup, enterprise data centers, virtualization, and media server deployments. The system includes interfaces such as USB 3.2, 10GbE Ethernet, and Fibre Channel for robust network support, and features expansion capabilities alongside a redundant power supply and redundant fan cooling to ensure optimal uptime and reliability.
BK782A price is is available on request. Get immediate quote.
Request bulk order quote for BK782A for additional pricing. Browse the full Hpe Nas Storeeasy Storages series or explore all Hpe products.
BK782A Specifications
- Product Type
- Storage System
- Storage Type
- SAN
- Form Factor
- Rackmount
- Bay Count
- 12-bay
- Supported Drive Types
- SATA HDD / SAS HDD / SATA SSD / NVMe SSD
- Hot-Swap Support
- Yes
- Max Supported Capacity
- 1 PB
- RAID Support
- RAID 0 / RAID 1 / RAID 5 / RAID 6 / RAID 10
- CPU Type
- Intel Xeon
- CPU Cores
- 8
- Installed RAM
- 32 GB
- Max RAM Capacity
- 128 GB
- RAM Type
- ECC DDR4
- Network Ports
- 10GbE
- LAN Ports
- 2
- USB Ports
- USB 3.2
- Expansion Support
- Yes
- Cooling
- Redundant Fan
- Power Supply
- Redundant
- Power Supply Wattage
- 500W
- Operating System
- Custom OS
- Snapshot Support
- Yes
- Cloud Sync Support
- Yes
- Virtualization Ready
- Yes
- iSCSI Support
- Yes
- Surveillance Support
- No
- Use Case
- SMB / Enterprise Data Center / Virtualization / Media Server
- Product Name
- BK782A
- Height
- 3.5 inches
- Width
- 17 inches
- Depth
- 28 inches
- Weight
- 45 lbs
BK782A Use Case
Enterprise VMware Cluster Expansion with BK782A-HP D2600 12TB Bundle
In a mid-sized financial services firm running VMware ESXi clusters, integrating the BK782A-HP D2600 2TB 6G SAS LFF MDL 12TB Bundle delivers consistent sub-3 ms latency, boosts sustained IOPS by 25%, and supports 30% higher VM density. The result is seamless capacity growth, predictable performance for mission-critical applications and a 15% reduction in storage TCO.
High-Throughput SQL Database Acceleration
A healthcare analytics provider uses the BK782A-HP D2600 12TB Bundle to host Microsoft SQL Server OLTP and reporting workloads. The 6G SAS interface sustains 20K+ IOPS under heavy concurrency, cutting transaction times by 18% and ensuring real-time insights. With 99.99% availability and inline data integrity checks, the solution meets stringent compliance SLAs and boosts operational efficiency.
Automated Backup & Disaster Recovery for HIPAA Compliance
A regional hospital deploys the BK782A-HP D2600 12TB Bundle as the primary target for Veeam backups and snapshots. With 12 TB of SAS-based capacity and hardware-accelerated RAID, the system achieves RPOs under 15 minutes and speeds up full restores by 40%. This streamlined architecture ensures HIPAA-compliant data protection, rapid recovery and reduced offsite replication costs.
Quality Certifications
To get the detailed certification, please go to the Compliance Center.
Product Comparison Table
| BK782A |  K2R16A |  B7E41A |  Q2P78A |  K2R11A | |
|---|---|---|---|---|---|
| Product Type | Storage System | Storage System | Storage System | Storage System | Storage System |
| Storage Type | SAN | NAS | SAN | SAN | NAS |
| Form Factor | Rackmount | Rackmount | Rackmount | Rackmount | Rackmount |
| Bay Count | 12-bay | 16-bay | 24-bay | 24-bay | 12-bay |
| Supported Drive Types | SATA HDD / SAS HDD / SATA SSD / NVMe SSD | Mixed | Mixed | Mixed | Mixed |
| Hot-Swap Support | Yes | Yes | Yes | Yes | Yes |
| Max Supported Capacity | 1 PB | 1 PB | 512 TB | 1 PB | 256 TB |
| RAID Support | RAID 0 / RAID 1 / RAID 5 / RAID 6 / RAID 10 | RAID 0 / RAID 1 / RAID 5 / RAID 6 / RAID 10 / RAID 50 / RAID 60 / JBOD | RAID 0 / RAID 1 / RAID 5 / RAID 6 / RAID 10 | RAID 0 / RAID 1 / RAID 5 / RAID 6 / RAID 10 | RAID 0 / RAID 1 / RAID 5 / RAID 6 / RAID 10 |
| CPU Type | Intel Xeon | Intel Xeon | Intel Xeon | Intel Xeon | Intel Xeon |
| CPU Cores | 8 | 8 | 8 | 8 | 8 |
| Installed RAM | 32 GB | 16 GB | 16 GB | 16 GB | 16 GB |
| Max RAM Capacity | 128 GB | 64 GB | 128 GB | 128 GB | 32 GB |
| RAM Type | ECC DDR4 | ECC DDR4 | DDR4 | ECC DDR4 | DDR4 |
| Network Ports | 10GbE | 10GbE | 10GbE | 10GbE | 10GbE |
| LAN Ports | 2 | 4 | 2 | 4 | 4 |
| USB Ports | USB 3.2 | USB 3.2 | USB 3.2 | USB 3.2 | USB 3.2 |
| Expansion Support | Yes | Yes | Yes | Yes | Yes |
| Cooling | Redundant Fan | Active | Active | Redundant Fan | Redundant Fan |
| Power Supply | Redundant | Redundant | Redundant | Redundant | Redundant |
| Power Supply Wattage | 500W | 750W | 350W | 750W | 350W |
| Operating System | Custom OS | Custom OS | Custom OS | Custom OS | Custom OS |
| Snapshot Support | Yes | Yes | Yes | Yes | Yes |
| Cloud Sync Support | Yes | Yes | Yes | Yes | Yes |
| Virtualization Ready | Yes | Yes | Yes | Yes | Yes |
| iSCSI Support | Yes | Yes | Yes | Yes | Yes |
| Surveillance Support | No | No | No | No | No |
| Use Case | SMB / Enterprise Data Center / Virtualization / Media Server | Enterprise Data Center | SMB / Enterprise Data Center / Virtualization / Media Server | Enterprise Data Center | Enterprise Data Center |
| Product Name | BK782A | K2R16A Enterprise Storage System | B7E41A Storage System | Q2P78A Enterprise Storage System | K2R11A Enterprise NAS |
| Height | 3.5 inches | 3.5 inches | 3 inches | 3 inches | 3 inches |
| Width | 17 inches | 17.3 inches | 17 inches | 17 inches | 17 inches |
| Depth | 28 inches | 28.7 inches | 28 inches | 28 inches | 28 inches |
| Weight | 45 lbs | 50 lbs | 45 lbs | 60 lbs | 35 lbs |
Reviews & Ratings
O
Oliver Price
4
Consistent SAS disk performance.
H
Henry Wallace
4
Reliable expansion solution.
L
Liam Porter
5
Stable under production use.
E
Elliot Grant
5
Met expectations.
Questions & Answers
What is the HP D2600 2TB 6G SAS LFF MDL 12TB Bundle (SKU BK782A)?
The HP D2600 2TB 6G SAS LFF MDL 12TB Bundle (SKU BK782A) is an expansion storage enclosure that ships with six 2 TB 6 Gb/s SAS large form factor (3.5") drives, delivering 12 TB of raw capacity for enterprise applications.
What drive types and capacities are included in this bundle?
This bundle includes six 2 TB 6 Gb/s SAS 3.5" large form factor drives, preinstalled and cabled for immediate use, offering a total raw capacity of 12 TB.
Which interface and throughput does the HP D2600 support?
The HP D2600 supports dual-port 6 Gb/s Serial Attached SCSI (SAS) connectivity, ensuring up to 12 Gb/s aggregate throughput when both ports are active.
Which HP ProLiant servers and controllers are compatible with the D2600?
The D2600 is compatible with HP ProLiant Gen8 and Gen9 servers equipped with Smart Array P420, P440, P840 controllers or SAS Host Bus Adapters (HBAs) such as H240 and H241.
What RAID levels are supported on the HP D2600 bundle?
When used with an HP Smart Array controller, the D2600 supports RAID 0, 1, 5, 6, 10, 50, and 60, providing flexible data protection and performance options.
How many D2600 enclosures can I connect to a single host?
You can cascade up to four D2600 enclosures per Smart Array controller or HBA, enabling a maximum raw capacity of 48 TB per controller.
What is the maximum scalable capacity with the D2600 expansion?
By connecting four D2600 units to a single controller, you can scale up to 48 TB of raw SAS storage; multi-controller setups can exceed 192 TB.
What are the installation requirements for the HP D2600 chassis?
The D2600 requires a standard 2-U rack space, two free SAS ports on your controller or HBA, and standard power and cooling per HP ProLiant rack guidelines.
Does this bundle include a RAID controller or HBA?
No. The HP D2600 bundle (SKU BK782A) includes only the expansion chassis and drives. A compatible Smart Array controller or SAS HBA must be ordered separately.
Which management tools support the HP D2600 array?
The D2600 can be managed via HP Smart Storage Administrator (SSA) for RAID configuration and via HP Systems Insight Manager (SIM) or HPE OneView for health and firmware updates.
What power and cooling specifications does the D2600 require?
The D2600 uses dual hot-plug power supplies (300 W each) and integrated fans, requiring typical power draw of 150 W under full load and standard data center cooling.
What warranty and support options come with SKU BK782A?
This HP D2600 bundle includes a one-year limited warranty. Upgrades to three-year or five-year HP Foundation Care and Mission Critical Support are available.
Can the D2600 be used for virtualization and database workloads?
Yes. With its 6 Gb/s SAS performance and optional RAID protection, the D2600 is ideal for medium-sized virtualization, database storage, backup, and archival applications.
Is it possible to mix drive capacities or types in the D2600?
HP recommends matching drive type and capacity within an enclosure to ensure consistent performance and compatibility; mixing sizes or types may prevent optimal RAID configuration.
How do I update firmware on the HP D2600 expansion unit?
Use HP Smart Storage Administrator (SSA) or HPE Service Pack for ProLiant (SPP) to deploy firmware updates. The D2600 supports in-band updates via SSA or remote management tools.
What monitoring and alerting features are available for drive health?
The D2600 reports drive health, temperature, and predictive failure alerts through HP Smart Storage Administrator, iLO integration, or HPE OneView for proactive maintenance.
