C8R44B

Specification Of C8R44B

General
Device Type	Switch - 48 ports - managed
Enclosure Type	Rack-mountable 2U
Subtype	Fibre Channel
Ports	48 x 16Gb Fibre Channel SFP+
Fibre Channel	FC-AL-2, FC-DA, FC-GS-4, FC-Tape, FC-VI, FC-SP, FC-LS, FC-MI-2, FC-PI-4, FC-FS-3, FC-GS-6, FC-PI-3, FC-SW-5
Remote Management Protocol	SNMP, TFTP, SMI-S, SSH, CLI
Encryption Algorithm	SSL
Authentication Method	Secure Shell (SSH), RADIUS, DH-CHAP
Features	Full duplex capability, auto-sensing per device, Trivial File Transfer Protocol (TFTP) support, Non-Disruptive Code Load Activation (NDCLA) support, Registered State Change Notification (RSCN) support
Expansion / Connectivity
Interfaces	48 x 16Gb Fibre Channel SFP+ | 48 x 16Gb Fibre Channel SFP+ Ports on Demand | 1 x 100Base-TX RJ-45 management | 1 x console RJ-45 management | 1 x USB Type A management
Power
Power Device	Internal power supply
Voltage Required	AC 120/230 V (50/60 Hz)
Miscellaneous
Cables Included	1 x serial cable
Rack Mounting Kit	Included
Compliant Standards	UL, CISPR 22 Class A, cUL, DEMKO, EN 61000-3-2, GS, VCCI Class A ITE, EN 61000-3-3, CB, ICES-003 Class A, RoHS, UL 60950-1, IEC 60950-1, EN 60950-1, GOST-R, FCC Part 15 B Class A, AS/NZS, VCCI V-3 Class A ITE, EN 55022 Class A, CAN/CSA-C22.2 No. 60950-1
Localization	English / United States
Software / System Requirements
Software Included	HP Simple SAN Connection Manager
OS Required	Microsoft Windows Storage Server 2003, HP-UX 11.23, SuSE Linux Enterprise Server 10 SP2, Red Hat Enterprise Linux 5.2, SuSE Linux Enterprise Server 9 Service Pack 3, Microsoft Windows Server 2003 R2, Red Hat Enterprise Linux 5, Microsoft Windows Server 2008, SuSE Linux Enterprise Server 10 SP1, Microsoft Windows Server 2003 SP2, HP-UX 11.31, SuSE Linux Enterprise Server 9 Service Pack 4, VMware ESX 4.0, Red Hat Enterprise Linux 4.5, Red Hat Enterprise Linux 4.6, Red Hat Enterprise Linux 5.1, VMware ESX 3.5 update 1, VMware ESX 3.5 update 2
Dimensions & Weight
Width	17 in
Depth	1.7 in
Height	18.7 in
Weight	14.11 lbs
Manufacturer Warranty
Service & Support	Limited warranty - parts and labor - 1 year - on-site
Environmental Parameters
Min Operating Temperature	32 °F
Max Operating Temperature	113 °F
Humidity Range Operating	15 - 80% (non-condensing)
Min Storage Temperature	-40 °F
Max Storage Temperature	158 °F
Humidity Range Storage	5 - 90% (non-condensing)
