Name: Cisco Catalyst 9120AX Series
Brand: Cisco
SKU: C9120AXE-Q
Price: 1165.00 USD
Availability: InStock
Rating: 4.3 (6 reviews)

Question 1

What is the Cisco Catalyst 9120AX Series (SKU: C9120AXE-Q)?

Accepted Answer

The Cisco Catalyst 9120AX Series access points deliver Wi-Fi 6 performance, advanced security, and AI-driven insights for enterprise and campus networks.

Question 2

Which wireless standards does the 9120AX support?

Accepted Answer

The 9120AX supports IEEE 802.11ax (Wi-Fi 6), 802.11ac Wave 2, 802.11n, 802.11a/b/g, ensuring backward compatibility.

Question 3

What maximum data rates can the 9120AX achieve?

Accepted Answer

It delivers dual-radio aggregate rates up to 5.4 Gbps: 4.8 Gbps on 5 GHz (8×8:8) and 1.2 Gbps on 2.4 GHz (4×4:4).

Question 4

How many client devices can one 9120AX support?

Accepted Answer

Each 9120AX access point can handle up to 400 concurrent clients with dynamic load balancing for optimized performance.

Question 5

What security features are built into the Catalyst 9120AX?

Accepted Answer

It includes Cisco Encrypted Traffic Analytics, WPA3, Secure Boot, MACsec, and rogue device detection to safeguard your network.

Question 6

How is the 9120AX managed?

Accepted Answer

Manage the 9120AX via Cisco DNA Center, Cisco Wireless LAN Controller (WLC), or Cisco Meraki Dashboard for centralized configuration and monitoring.

Question 7

Does the 9120AX support Power over Ethernet (PoE)?

Accepted Answer

Yes. It supports 802.3at PoE+ and Cisco Universal PoE, eliminating the need for separate power adapters.

Question 8

What mounting options are available for the 9120AX?

Accepted Answer

The access point includes flush-mount, ceiling-tile, and wall-mount kits for flexible installation in any environment.

Question 9

What is the typical power consumption of the 9120AX?

Accepted Answer

Maximum power draw is 21 W in normal operation and up to 38 W with PoE+ and external antennas.

Question 10

Which antenna configurations does the 9120AX offer?

Accepted Answer

It features integrated omnidirectional antennas (4×4:4 MIMO) and supports external downtilt and directional antenna options.

Question 11

What use cases are ideal for the Catalyst 9120AX?

Accepted Answer

Ideal for high-density enterprise, education, healthcare, retail, and manufacturing environments demanding high throughput and security.

Question 12

What licensing is required for the 9120AX?

Accepted Answer

It requires Cisco DNA Essentials or Advantage licenses for feature sets like automation, analytics, and assurance.

Question 13

What warranty and support options are available?

Accepted Answer

Cisco offers a limited lifetime hardware warranty plus optional SMARTnet for 24×7 technical support and software updates.

Question 14

Can the 9120AX operate in mesh mode?

Accepted Answer

Yes. The 9120AX supports Cisco Intelligent Mesh for rapid, flexible deployments without wired backhaul.

Question 15

What distinguishes the 9120AXE-Q model?

Accepted Answer

The 9120AXE-Q includes external antenna connectors, PoE+ support, and is optimized for high-density, high-performance enterprise Wi-Fi 6 networks.

	C9120AXE-Q	C9120AXE-EWC-S	C9120AXI-EWC-E	C9120AXE-T	C9120AXI-EWC-B
Antenna Gain	N/A	N/A	N/A	N/A	N/A
Antenna Type	Omnidirectional	Internal Omni-directional	Omnidirectional	Omnidirectional	Internal (Omnidirectional)
Beamforming	Yes	Yes	Yes	Yes	Yes
Compliance	FCC / CE / RoHS	FCC, CE, RoHS	FCC / CE / RoHS	FCC, CE, RoHS	FCC / CE / RoHS
Connector Type	RJ-45	RJ-45	RJ-45	RJ-45	RJ-45
Coverage Area	N/A	N/A	N/A	N/A	N/A
Data Rate	Up to 5Gbps	Up to 5Gbps	Up to 5Gbps	5Gbps	Up to 5Gbps
Depth	N/A	N/A	N/A	N/A	N/A
Ethernet Port	1x Gigabit	1x Gigabit	1x Gigabit	1x Gigabit	1x Gigabit
Frequency Bands	2.4GHz / 5GHz / 6GHz	2.4GHz, 5GHz, 6GHz	2.4GHz / 5GHz	Tri-Band (2.4GHz, 5GHz, 6GHz)	2.4GHz / 5GHz
Height	N/A	N/A	N/A	N/A	N/A
MIMO Technology	MU-MIMO	MU-MIMO	MU-MIMO	MU-MIMO	MU-MIMO
Management Features	Cloud Management / On-Premises	Cloud Management, On-Premises, SNMP	Cloud Management / On-Premises / SNMP	On-Premises, SNMP	Cloud Management / On-Premises / SNMP
Max Number of Devices Supported	N/A	N/A	N/A	N/A	N/A
Max Range	N/A	N/A	N/A	N/A	N/A
Memory	N/A	N/A	N/A	N/A	N/A
Mesh Networking	No	No	N/A	No	Yes
Mounting Options	Ceiling Mount / Wall Mount	Ceiling Mount, Wall Mount	Ceiling Mount / Wall Mount	Ceiling Mount, Wall Mount	Ceiling Mount / Wall Mount
Outdoor Use	No	No	No	No	No
Power Supply	PoE	PoE	PoE	PoE	PoE
Processor	N/A	N/A	N/A	N/A	N/A
Product Name	Cisco Catalyst C9120AXE-Q Wireless Access Point	Cisco Catalyst 9120AXE-EWC-S	Cisco Catalyst C9120AXI-EWC-E	Cisco Catalyst C9120AXE-T Wireless Access Point	C9120AXI-EWC-B
Product Type	Wireless Access Point	Wireless Product	Access Point	Wireless Access Point	Wireless Product
Protocols Supported	802.11a/b/g/n/ac/ax	802.11a/b/g/n/ac/ax	802.11a/b/g/n/ac/ax	802.11a/b/g/n/ac/ax	802.11ax; 802.11a/b/g/n/ac
Security Features	WPA2 / WPA3 / 802.1X	WPA2, WPA3, 802.1X	WPA2 / WPA3 / 802.1X	WPA2, WPA3, 802.1X	WPA2 / WPA3 / 802.1X
Weight	N/A	N/A	N/A	N/A	N/A
Wi-Fi Standard	Wi-Fi 6/6E	Wi-Fi 6 / Wi-Fi 6E	Wi-Fi 6	Wi-Fi 6E	Wi-Fi 6
Width	N/A	N/A	N/A	N/A	N/A
Wireless Type	Access Point	Access Point	Access Point	Access Point	Access Point
