Is the CWDM-XFP10G-1571 hot-pluggable?

Yes. The XFP form factor is hot-pluggable, allowing insertion and removal without powering down the host system.

Which data rate does the CWDM-XFP10G-1571 support?

It supports line rates of up to 10.7 Gbps, fully compliant with 10G Ethernet and SONET OC-192/STM-64 standards.

What protocols are compatible with this module?

The transceiver is compatible with 10G Ethernet (IEEE 802.3ae), SONET OC-192, SDH STM-64 and Fiber Channel up to 10 Gbps.

What is the operating temperature range of the CWDM-XFP10G-1571?

The module operates in a commercial temperature range of 0 °C to +70 °C; extended and industrial options are available upon request.

How much power does the CWDM-XFP10G-1571 consume?

Typical power consumption is ≤3.5 W, meeting XFP MSA power budget requirements.

Is the CWDM-XFP10G-1571 vendor-agnostic?

Yes. It is fully interoperable with all major brands supporting XFP CWDM slots, including Cisco, Juniper, Huawei, and Arista.

How do I install the CWDM-XFP10G-1571 in my switch or router?

Ensure the host port is XFP-compatible, power on the device, insert until the module clicks, then connect LC fiber patch cables.

What diagnostic features does this XFP module offer?

It supports Digital Diagnostic Monitoring (DDM) for real-time monitoring of optical power, temperature, voltage, and bias current.

Does the CWDM-XFP10G-1571 come with a warranty?

Standard warranty is one year, covering manufacturing defects; extended and multi-year plans are available.

Can the CWDM-XFP10G-1571 be used in DWDM networks?

No. This module is designed exclusively for CWDM applications. For DWDM, choose a dedicated DWDM transceiver.

What applications are ideal for the CWDM-XFP10G-1571?

Ideal for metro, campus and data-center interconnects, high-speed LANs/WANs, and storage networks requiring 10 Gbps links up to 70 km.

How should I clean and maintain the LC connectors?

Use lint-free wipes and isopropyl alcohol or specialized fiber-optic cleaning tools before each connection to ensure optimal signal quality.

FEATURED DEAL

Name:

CWDM-XFP10G-1571

Name: CWDM Optical Transceiver,XFP,10G,Single-mode Module(1571nm,70km,LC)
Brand: Huawei
SKU: CWDM-XFP10G-1571
Rating: 4.3 (6 reviews)

Description:: CWDM Optical Transceiver,XFP,10G,Single-mode Module(1571nm,70km,LC)
Rating:: 4.3(6)
Added to cart 28 times recently
Availability:: In stock - Ready to Ship
Brand:: Huawei
GTIN:: 886598026543
Condition:

Get a Quote

3 Year Extended Warranty

Same-day Shipping

14-Day Money Back Guarantee

Shipping:

Payment:

cwdm-xfp10g-1571 cwdm optical transceiver,xfp,10g,single-mode module(1571nm,70km,lc)

3 Year Extended Warranty

Same-day Shipping

14-Day Money Back Guarantee

Need Additional Discount on Product?

Request a quote below - Get Exclusive Pricing and Support.

Shipping:

Payment:

CWDM-XFP10G-1571

CWDM Optical Transceiver,XFP,10G,Single-mode Module(1571nm,7...

TRUSTED, TRIED, PROVEN

$5,000,000+

Inventory Delivered By

Officially Accredited

& Verified By

Next-Gen IT

Solutions Powered By

CWDM-XFP10G-1571 Overview

CWDM-XFP10G-1571 is a CWDM optical transceiver designed in the XFP form factor that reliably delivers a 10G data rate for high-speed network applications. It comes equipped with LC connectors for single-mode fiber and is engineered for long-range transmission, making it ideal for Ethernet-based data centers, telecom networks, and enterprise environments.

CWDM-XFP10G-1571 operates at a transmission wavelength of 1571 nm and is optimized to communicate over distances of up to 80 km. Its compact design meets standard physical dimensions and performance criteria, ensuring robust operation in environments such as service provider backbones and mission-critical networking applications.

CWDM-XFP10G-1571 price is is available on request. Get immediate quote.

Request bulk order quote for CWDM-XFP10G-1571 for additional pricing. Browse the full Huawei Transceivers series or explore all Huawei products.

CWDM-XFP10G-1571 Specifications

Product Type: Transceiver
Form Factor: XFP
Data Rate: 10G
Connector Type: LC
Wavelength: 1571 nm
Transmission Distance: Long-Range
Fiber Type: Single-mode
Max Distance: 80 km
Supported Protocols: Ethernet
Network Interface: Fiber
Power Consumption: 3.5W
Operating Temperature: 0 to 70°C
Storage Temperature: -40 to 85°C
Input Voltage: 3.3V
Compatibility: Cisco / Juniper / Huawei / Arista
Product Name: CWDM-XFP10G-1571
Height: 0.81 inches
Width: 1.10 inches
Depth: 2.13 inches
Weight: 0.15 lbs

Quality Certifications

To get the detailed certification, please go to the Compliance Center.

Product Comparison Table

	CWDM-XFP10G-1571	QSFP-40G-ER4	SFP-10G-ZCW1571	OSM040N01	Huawei CFP-40G-LR4
Product Type	Transceiver	Transceiver	Transceiver	Transceiver	Transceiver
Form Factor	XFP	QSFP	SFP+	QSFP+	CFP
Data Rate	10G	40G	10G	40G	40G
Connector Type	LC	LC	LC	MPO	LC
Wavelength	1571 nm	1310 nm	850 nm	850 nm	1271/1293/1311/1331 nm
Transmission Distance	Long-Range	Extended-Range	Short-Range	Short-Range	Long-Range
Fiber Type	Single-mode	Single-mode	Multi-mode	Multi-mode	Single-mode
Max Distance	80 km	40 km	300 m	300 meters	10 km
Supported Protocols	Ethernet	Ethernet	Ethernet	Ethernet	Ethernet
Network Interface	Fiber	Ethernet	Fiber	Ethernet	Ethernet
Power Consumption	3.5W	3.5 W	1.5W	5.0W	N/A
Operating Temperature	0 to 70°C	0 to 70°C	0 to 70°C	0 to 70°C	0 to 70°C
Storage Temperature	-40 to 85°C	-40 to 85°C	-40 to 85°C	-40 to 85°C	-40 to 85°C
Input Voltage	3.3V	3.3V	3.3V	3.3V	3.3V
Compatibility	Cisco / Juniper / Huawei / Arista	Cisco / Juniper / Huawei / Arista	Cisco, Juniper, Huawei, Arista	Cisco / Juniper / Huawei / Arista	Huawei
Product Name	CWDM-XFP10G-1571	QSFP-40G-ER4	SFP-10G-ZCW1571 10GBase-SR SFP+ Transceiver	OSM040N01 QSFP+ Optical Transceiver	Huawei CFP-40G-LR4
Height	0.81 inches	0.38 inches	8.5 mm (0.33 in)	0.27 inches	N/A
Width	1.10 inches	0.83 inches	13.4 mm (0.53 in)	0.78 inches	N/A
Depth	2.13 inches	3.4 inches	56.5 mm (2.22 in)	1.97 inches	N/A
Weight	0.15 lbs	0.22 lbs	8 g (0.02 lbs)	0.15 lbs	N/A

Reviews & Ratings

Nathan Scott

Stable 10G CWDM XFP for metro links.

Ali Raza

Reliable long reach performance.

George Whitman

Easy integration with DWDM systems.

Ammar Khan

Consistent signal levels.

Samuel Wright

Good quality Huawei optic.

Oliver Grant

Dependable CWDM XFP module.

Questions & Answers

What is the CWDM-XFP10G-1571 optical transceiver?

The CWDM-XFP10G-1571 is a hot-pluggable XFP module delivering 10 Gbps over single-mode fiber at 1571 nm, designed for CWDM networks up to 70 km with an LC connector.

What transmission distance does the CWDM-XFP10G-1571 support?

This CWDM XFP transceiver reliably supports single-mode fiber links up to 70 km at 10 Gbps.

Which wavelength does the CWDM-XFP10G-1571 operate on?

The module operates at a CWDM wavelength of 1571 nm, optimized for minimized channel crosstalk and standardized grid compliance.

What fiber connector type is required for this transceiver?

The CWDM-XFP10G-1571 uses an LC duplex connector for both transmit and receive links.
