What data rate does the SFP28-25G-850nm-0.1km-MM support?

It supports a single-lane data rate of 25 Gb/s (25.78125 Gb/s maximum) compliant with IEEE 802.3by.

What type of connector does this transceiver use?

The module features an LC duplex connector for easy plug-and-play integration with standard multimode fiber patch cables.

What are the transmit and receive power specifications?

Transmit optical power ranges from –8.4 dBm to 2.4 dBm, and receiver sensitivity is specified down to –10.3 dBm for 25 Gb/s links.

Is the SFP28-25G-850nm-0.1km-MM MSA compliant?

Yes, it fully complies with the SFF-8665 and IEEE 802.3by standards, ensuring interoperability with any MSA-compliant SFP28 host.

Which network devices are compatible with this transceiver?

It’s compatible with Huawei S-series switches, routers and any third-party 25 GbE ports supporting MSA-compliant SFP28 modules.

Can I use it in Cisco, Juniper or Arista equipment?

Yes, as long as the host ports accept MSA-compliant SFP28 modules, this Huawei transceiver works interchangeably with Cisco, Juniper, Arista and other brands.

How do I install the Huawei SFP28-25G-850nm-0.1km-MM?

Simply hot-plug the module into an empty SFP28 port, latch the connector, and verify link status via the switch CLI or LED indicators.

Does this transceiver support hot swapping?

Yes, the SFP28-25G-850nm-0.1km-MM is hot-pluggable, allowing module insertion or removal without powering down the host device.

What is the operating temperature range?

It operates reliably from 0 °C to 70 °C (commercial range) and from –40 °C to 85 °C (extended range) for harsh environments.

How much power does the module consume?

The typical power consumption is ≤1 W, making it energy-efficient for high-density 25 GbE deployments.

How do I calculate the link budget for this transceiver?

Subtract the receiver sensitivity (–10.3 dBm) from the minimum transmit power (–8.4 dBm) and account for fiber attenuation (OM4 ~1 dB/km) to verify margin.

What warranty and support does Huawei offer?

Huawei provides a standard 1-year warranty with technical support, optional extended coverage and advance-replacement services.

FEATURED DEAL

Name:

SFP28-25G-850nm-0.1km-MM

Name: Huawei High Speed Transceiver,SFP28,850nm,25G,-8.4dBm,2.4dBm,-10.3dBm,LC,MMF,0.1km
Brand: Huawei
SKU: SFP28-25G-850nm-0.1km-MM
Price: 1871.48 USD
Availability: InStock
Rating: 4.3 (6 reviews)

Description:: Huawei High Speed Transceiver,SFP28,850nm,25G,-8.4dBm,2.4dBm,-10.3dBm,LC,MMF,0.1km
Rating:: 4.3(6)
Added to cart 28 times recently
Availability:: In stock - Ready to Ship
Brand:: Huawei
GTIN:: 886598026543
Condition:
Warranty:: 3
List Price:: $1,990.92
Price:: $1,871.486% off

Quantity:

Business price:

Enroll your business for free

3 Year Extended Warranty

Same-day Shipping

14-Day Money Back Guarantee

Shipping:

Payment:

sfp28-25g-850nm-0.1km-mm huawei high speed transceiver,sfp28,850nm,25g,-8.4dbm,2.4dbm,-10.3dbm,lc,mmf,0.1km

3 Year Extended Warranty

Same-day Shipping

14-Day Money Back Guarantee

Need Additional Discount on Product?

Request a quote below - Get Exclusive Pricing and Support.

Shipping:

Payment:

SFP28-25G-850nm-0.1km-MM

Huawei High Speed Transceiver,SFP28,850nm,25G,-8.4dBm,2.4dBm...

$1,990.92 $1,871.486% off

11 in Global Warehouse Global

TRUSTED, TRIED, PROVEN

$5,000,000+

Inventory Delivered By

Officially Accredited

& Verified By

Next-Gen IT

Solutions Powered By

SFP28-25G-850nm-0.1km-MM Overview

SFP28-25G-850nm-0.1km-MM is a high-performance SFP transceiver module designed for short-range applications. It supports a data rate of 25G and features an LC connector, making it an ideal solution for efficient Ethernet connectivity in network infrastructures.

Built with multi-mode fiber compatibility and optimized for a transmission distance of 0.1km, this compact module fits standard SFP form factors and physical dimensions. It is well-suited for use in data centers, enterprise networks, and telecom environments where reliable, high-speed data transmission is critical.

SFP28-25G-850nm-0.1km-MM price is $1,871.48, a 6% saving from the Huawei list price of $1,990.92. SFP28-25G-850nm-0.1km-MM is in stock and available for next-day dispatch. (terms applied)

Request bulk order quote for SFP28-25G-850nm-0.1km-MM for additional pricing. Browse the full Huawei Transceivers series or explore all Huawei products.

SFP28-25G-850nm-0.1km-MM Specifications

Product Type: Transceiver
Form Factor: SFP
Data Rate: 25G
Connector Type: LC
Wavelength: 850nm
Transmission Distance: Short-Range
Fiber Type: Multi-mode
Max Distance: 0.1km
Supported Protocols: Ethernet
Network Interface: Ethernet
Power Consumption: N/A
Operating Temperature: 0 to 70°C
Storage Temperature: -40 to 85°C
Input Voltage: 3.3V
Compatibility: Cisco / Juniper / Huawei / Arista
Product Name: SFP28-25G-850nm-0.1km-MM
Height: N/A
Width: N/A
Depth: N/A
Weight: N/A

Quality Certifications

To get the detailed certification, please go to the Compliance Center.

Product Comparison Table

	SFP28-25G-850nm-0.1km-MM	DWDM-SFPGE-1558-17	DWDM-SFPGE-1531-90	CWDM-SFPGE-1611	DWDM-SFPGE-1558-98
Product Type	Transceiver	Transceiver	Transceiver	Transceiver	Transceiver
Form Factor	SFP	SFP	SFP	SFP	SFP
Data Rate	25G	1G	1G	1G	1G
Connector Type	LC	LC	LC	LC	LC
Wavelength	850nm	1558 nm	1531 nm	1611 nm	1558 nm
Transmission Distance	Short-Range	Extended-Range	Long-Range	Long-Range	Long-Range
Fiber Type	Multi-mode	Single-mode	Single-mode	Single-mode	Single-mode
Max Distance	0.1km	80 km	90 km	80 km	80 km
Supported Protocols	Ethernet	Ethernet	Ethernet	Ethernet	Gigabit Ethernet
Network Interface	Ethernet	Fiber	Fiber	Fiber	Ethernet
Power Consumption	N/A	3.5W	N/A	N/A	2.5W
Operating Temperature	0 to 70°C	0 to 70°C	0 to 70°C	0 to 70°C	0 to 70°C
Storage Temperature	-40 to 85°C	-40 to 85°C	-40 to 85°C	-40 to 85°C	-40 to 85°C
Input Voltage	3.3V	3.3V	3.3V	3.3V	3.3V
Compatibility	Cisco / Juniper / Huawei / Arista	Cisco, Juniper, Huawei, Arista	Cisco, Juniper, Huawei, Arista	Cisco / Juniper / Huawei / Arista	Cisco, Juniper, Huawei, Arista
Product Name	SFP28-25G-850nm-0.1km-MM	DWDM-SFPGE-1558-17	DWDM-SFPGE-1531-90	CWDM-SFPGE-1611	DWDM-SFPGE-1558-98
Height	N/A	0.24 inches	N/A	N/A	0.33 inches
Width	N/A	0.63 inches	N/A	N/A	0.53 inches
Depth	N/A	1.5 inches	N/A	N/A	2.22 inches
Weight	N/A	0.1 lbs	N/A	N/A	0.1 lbs

Reviews & Ratings

Ethan Caldwell

Reliable 25G multimode optic for short links.

Nathan Brooks

Stable performance inside data centers.

Adam Fletcher

Quick deployment with no tuning required.

Marcus Hill

Consistent throughput under load.

James Porter

Works well with 25G switches.

Oliver Grant

Dependable short range 25G optic.

Questions & Answers

What is the Huawei SFP28-25G-850nm-0.1km-MM transceiver?

The Huawei SFP28-25G-850nm-0.1km-MM is an MSA-compliant, hot-pluggable 25 Gb/s optical transceiver designed for multimode fiber links up to 100 m using an 850 nm VCSEL laser.

Which fiber type does the SFP28-25G-850nm-0.1km-MM support?

It supports 50/125 µm and 62.5/125 µm multimode fiber (MMF) in laser-optimized or OM3/OM4 grade for links up to 100 m.

What is the maximum transmission distance?

This transceiver delivers reliable data transmission over multimode fiber for distances up to 0.1 km (100 m).

What wavelength does this module operate on?

It operates at a nominal wavelength of 850 nm using a VCSEL light source optimized for multimode fiber.
