Name: Inspur-TianSuo-TS860G3
Brand: Inspur
Availability: InStock

Inspur-TianSuo-TS860G3

Inspur TianSuo TS860G3, Rack/8U, 8 Intel®Xeon® E7-4800 v3/v4, E7-8800 v3/v4 Processors, supports 192 DIMM memory sticks and expansion to 24TB memory at the maximum, 8 super-platinum power source and can realize N+M/N+N redundancy

Inspur TianSuo TS860G3 System Specification

Inspur TS860G3 Specification
Profile/height	Rack/8U
Processor	Support 8 Intel®Xeon® E7-4800 v3/v4, E7-8800 v3/v4 Processors
Cache	20MB-60MB, variable with different models of processor
Bus speed	6.4GT/s-9.6GT/s, variable with different models of processor
Memory	Support 192 DIMM memory sticks and expansion to 24TB memory at the maximum
Hard disk controller	Support 8-channel high-performance SAS Raid card; optional protected battery
RAID	Support Raid 1/0/10/5/50/6/60
Quantity of hard disks	Support 16 2.5€ hot-plug SAS/SATA/SSD hard disks
IO expansion slot	26 standard PCI-E3.0 slots
Integrated IO port	Front installation: 2 USB interfaces and 1 serial port Back installation: four 1G RJ45 network interfaces, two USB interfaces, one 1G management network interface and one VGA
Network controller	Integrated with 4 high-performance 1G network interfaces; support I/O AT2 advanced network acceleration; support VMDQ network virtualization technology; support network awakening, network redundancy, load balancing and other advanced features; integrated with one 1G management network interface
Power supply	8 super-platinum power source and can realize N+M/N+N redundancy
Display controller	Motherboard integrated with a display controller
Floppy disk drive	Virtual floppy disk drive with an USB interface as a standard configuration
Management features	Support remote control, IPMI2.0ï¼ŒKVM over IPï¼ŒSOLï¼ŒSNMP, etc Provide Ethernet management interface Support Inspur Ruijie management set Support virtual media Support management system redundancy Provided with optical passage status display for management and monitoring; optional HD smart management system
Operating system supported	Windows server 2008 R2 (dat acente version) Windows server 2012 R2 64bit Redhat enterprise linux server 6.x/7.x CentOS 6.x/7.x SUSE linux ent erprise server 12 VMware ESXi server 6.0 Incloud sphere V4
Working environment temperature	5°C-40°C
Power input	100VAC-240VAC, 240VDC
Case	830mm (L), 444mm (W), 352mm (H)
