MIC-9502-Z30GVF
Bosch MIC-9502-Z30GVF VGA Thermal/Visible PTZ IP Security Ca...
TRUSTED, TRIED, PROVEN
$5,000,000+
Inventory Delivered By
Officially Accredited
& Verified By
Next-Gen IT
Solutions Powered By
MIC-9502-Z30GVF is a high-definition IP security camera featuring a bullet design with a 4MP resolution and a varifocal lens offering a focal length of 2.7–13.5mm. It is equipped with a 1/2.8" CMOS sensor, supports H.265 video compression, provides 2-Way Audio, and features connectivity through PoE. The device delivers infrared night vision up to 30m, operates in true day/night mode using ICR technology, and is ONVIF compliant. Additionally, it offers local storage via a MicroSD slot with a maximum capacity of 128 GB and is built to withstand outdoor elements with an IP66 weather rating.
MIC-9502-Z30GVF is engineered for demanding surveillance applications, including indoor retail environments, perimeter defense, license plate recognition, and warehouse monitoring. It comes with smart features such as motion detection and ANPR, employs Starlight low light technology, and is designed for both indoor and outdoor use where reliable, high-performance security is essential.
MIC-9502-Z30GVF price is is available on request. Get immediate quote.
Request bulk order quote for MIC-9502-Z30GVF for additional pricing. Browse the full Thermal Security Cameras series or explore all Bosch products.
To get the detailed certification, please go to the Compliance Center.
| MIC-9502-Z30GVF |  MIC-9502-Z30WQS |  NHT-8001-F65VS |  NHT-8000-F07QF |  NHT-8000-F19QF | |
|---|---|---|---|---|---|
| Product Type | Security Camera | Security Camera | Security Camera | Security Camera | Security Camera |
| Camera Type | Bullet | Bullet | Bullet | Dome | Dome |
| Technology | IP Camera | IP Camera | IP Camera | IP Camera | IP Camera |
| Resolution | 4MP | 4K | 4MP | 1080p | 1080p |
| Lens Type | Varifocal | Fixed | Varifocal | Fixed | Fixed |
| Smart Features | Motion Detection / ANPR | Motion Detection | Motion Detection / ANPR | Motion Detection | N/A |
| Mounting Type | Wall | Wall | Wall | Ceiling | Ceiling |
| Color | Black | Black | Black | Black | Black |
| Use Case | Retail / Perimeter Protection / Warehouse | Retail | Indoor / Retail / Perimeter Protection / Warehouse | Retail | Retail |
| Focal Length | 2.7–13.5mm | 4mm | 2.7–13.5mm | 4mm | 2.8mm |
| Image Sensor | 1/2.8" CMOS | 1/2.8" CMOS | 1/2.8" CMOS | 1/3" CMOS | 1/2.8" CMOS |
| Frame Rate | 30 FPS | 30 FPS | 30 FPS | 30 FPS | 30 FPS |
| Infrared Night Vision | 30m | 30m | 50m | 30m | 30m |
| Low Light Technology | Starlight | Starlight | EXIR | EXIR | IR |
| Day/Night Mode | True Day/Night (ICR) | True Day/Night (ICR) | True Day/Night (ICR) | True Day/Night (ICR) | True Day/Night (ICR) |
| Video Compression | H.265 | H.265 | H.265+ | H.265+ | H.265 |
| Audio Support | 2-Way Audio | 2-Way Audio | 2-Way Audio | Built-in Mic | Built-in Mic |
| Storage Option | MicroSD Slot | MicroSD Slot | MicroSD Slot | MicroSD Slot | MicroSD Slot |
| Max Storage Capacity | 128 GB | 128 GB | 128 GB | 128 GB | 128 GB |
| Power Type | PoE | PoE | PoE | PoE | PoE |
| Weather Rating | IP66 | IP67 | IP66 | IP66 | IP67 |
| Vandal Resistance | IK10 | IK10 | None | None | N/A |
| ONVIF Compliant | Yes | Yes | Yes | Yes | Yes |
| Product Name | MIC-9502-Z30GVF High-Definition Network Bullet Camera | MIC-9502-Z30WQS | NHT-8001-F65VS | NHT-8000-F07QF IP Dome Camera | NHT-8000-F19QF |
| Height | 2.5 inches | 3 inches | 3.5 inches | 2.7 inches | 4.5 inches |
| Width | 3.5 inches | 2 inches | 5.0 inches | 3.7 inches | 3.2 inches |
| Depth | 2 inches | 2 inches | 2.5 inches | 3.7 inches | 3.2 inches |
| Weight | 1.2 lbs | 1.5 lbs | 1.2 lbs | 1.2 lbs | 1.2 lbs |
The thermal/visible dual output is essential for our perimeter. We can detect heat signatures and then zoom in with 30x optical clarity.
Exceptional performance in fog and total darkness. The thermal sensor is highly sensitive, and the PTZ tracking is professional grade.
A high-end security solution that delivers. The transition between thermal and visible light streams is smooth and incredibly useful for 24/7 monitoring.
Reliable ruggedized housing with advanced optics. This unit is the backbone of our site's early detection system.
The 30x optical zoom on the visible sensor is very sharp. Combined with thermal, it's the ultimate security tool.
The Bosch MIC-9502-Z30GVF is a dual-sensor PTZ network camera combining a VGA thermal imager and a high-resolution visible light camera with 30× optical zoom for 24/7 surveillance.
Key features include a 640×480 thermal sensor, 30× optical zoom visible sensor, IP66/IK10 housing, PoE+, built-in Intelligent Video Analytics, and remote PTZ control.
The camera delivers 640×480 pixel thermal imaging and up to 1920×1080 (Full HD) visible video for detailed scene analysis.
Yes. It features a cooled VGA thermal sensor that identifies heat signatures in total darkness, smoke or light fog.
The visible-light channel offers 30× optical zoom plus digital zoom, enabling clear identification at distances of up to 1,200 meters.
Yes. With an IP66 weatherproof and IK10 vandal-resistant enclosure, it operates in temperatures from –40 °C to +60 °C.
Yes. Its visible camera includes an automatic IR cut filter and built-in IR illumination for seamless day/night switching.
It supports standard TCP/IP, ONVIF Profile S and G, and can be configured via Bosch’s web interface or VMS systems for seamless network integration.
You can power it via PoE+ (IEEE 802.3at) or 24 VAC, offering flexibility for new or retrofit installations.
Yes. Remote PTZ control is available through the Bosch web client, third-party VMS, or joystick panels over IP.
It supports H.264, MJPEG, and optional H.265 for efficient bandwidth and storage management.
The visible channel offers a horizontal FOV from 59° (wide) to 2.3° (tele) and the thermal channel provides 25°.
Yes. It features Bosch Intelligent Video Analytics for tripwire, intrusion detection, loitering, and forensic search.
Mounting kits include wall, corner, pole, and pendant adapters, allowing flexible placement in any outdoor environment.
Ideal for perimeter security, critical infrastructure, ports, airports, and large outdoor facilities requiring long-range detection.
Comprehensive datasheets, installation guides, firmware updates, and Bosch technical support are available on the Bosch Security website.
