Hikvision Panoramic Series Cameras

A

A Hikvision Panoramic Series Network Camera is a multi-sensor surveillance device that delivers seamless 360° or 180° coverage by stitching images from multiple high-resolution lenses. It eliminates blind spots and provides uninterrupted panoramic monitoring in a single device.

A

Key features include multi-sensor panoramic monitoring, up to 12 MP total resolution, H.265+ compression, built-in analytics, PoE support, and IP67/IK10-rated housing. These cameras offer advanced image stitching, day/night functionality, and edge storage for flexible deployment.

A

Multi-sensor technology integrates up to four synchronized lenses to capture overlapping fields of view and create a single panoramic image. This approach ensures uniform resolution across the scene, reduces blind spots, and enhances situational awareness.

A

Hikvision Panoramic Series cameras support up to 12 MP aggregated resolution at 15 fps and individual sensor streams at up to 4 MP at 30 fps. Users can adjust resolution and frame rates per channel to optimize bandwidth and storage.

A

They support H.264, H.264+, H.265, and H.265+ compression standards. H.265+ offers up to 70% bandwidth and storage savings without sacrificing image quality.

A

Yes, all models support IEEE 802.3af/at PoE for simplified installation and reduced cabling. PoE+ ensures sufficient power for multi-sensor operation, IR illuminators, and onboard analytics.

A

These cameras carry an IP67 weatherproof rating and IK10 vandal resistance certification. They are designed to operate reliably in harsh outdoor environments and resist impact attempts.

A

Use Hikvision’s iVMS-4200 or web-based interface to align sensor overlap, adjust ROI, and define stitching parameters. The wizard-driven setup automatically merges streams into a unified panoramic view.

A

Built-in analytics include motion detection, intrusion detection, line crossing, loitering detection, and object removal. AI-driven perimeter protection reduces false alarms and enhances event accuracy.

A

Remote access is available via Hik-Connect, iVMS-4200, or web browser with SSL encryption. Users can view live streams, play back recordings, configure settings, and receive real-time alerts on desktop or mobile.

A

Hik-Connect and Hik-View Pro apps support remote live view, playback, push notifications, and two-way audio. Both iOS and Android versions are optimized for panoramic display and event management.

A

These cameras offer onboard microSD/SDHC/SDXC slots up to 256 GB, plus NVR or NAS support via ONVIF. Scheduled, event-triggered, and continuous recording modes ensure reliable data retention.

A

They support ONVIF Profile S/G/T and SDK integration for seamless compatibility with most VMS platforms. Use RTSP or DirectIP protocols to ensure full feature access and reliable streaming.

A

A Gigabit Ethernet network is recommended, along with QoS settings to prioritize surveillance traffic. Proper VLAN segmentation and PoE switches help maintain stable bandwidth and power delivery.

A

AI-based perimeter protection uses deep learning algorithms to differentiate people and vehicles from background clutter. It triggers precise alerts for line crossing, intrusion, and region entry, minimizing false positives.

A

Models with dual-power inputs support PoE and DC-12 V simultaneously, enabling automatic failover. In case of PoE failure, the DC input ensures uninterrupted operation and recording.

A

Hikvision provides a standard 3-year warranty on Panoramic Series cameras, extendable through maintenance contracts. Technical support is available via certified partners, online resources, and Hikvision’s helpdesk.
