What wavelengths are supported by the LR4 optics?

The LR4 optics split four 10 Gbps channels across four CWDM wavelengths (1295, 1300, 1305 and 1310 nm) for efficient 40 Gbps aggregation.

What data rates does the QSFP+ 4x10GBASE LR4 support?

This transceiver delivers four independent 10 Gbps channels (40 Gbps aggregate) at 1310 nm, fully compliant with IEEE 802.3ba 40GBASE-LR4 standards.

Is the QSFP+ LR4 module hot-pluggable?

Yes, the module supports hot-plug insertion and removal without powering down the host device, enabling seamless network upgrades and maintenance.

Does the module support Digital Diagnostics Monitoring (DDM)?

Yes, it features an I2C-based DDM interface that reports real-time optical output power, input power, temperature, laser bias current and supply voltage.

What is the operating temperature range?

The module operates reliably from 0 °C to 70 °C (32 °F to 158 °F), making it suitable for standard data-center and campus environments.

What is the power consumption of this QSFP+ transceiver?

Typical power consumption is under 3.5 Watts per module, ensuring energy-efficient high-speed links and minimal impact on system cooling.

Does the QSFP+ 4x10GBASE LR4 support Forward Error Correction (FEC)?

Yes, it supports RS-FEC to improve link budget and error performance on longer fiber runs, fully compatible with IEEE 802.3ba FEC standards.

How do I install the QSFP+ LR4 module in my Juniper switch?

Align the module with the QSFP+ port, slide it in until the latch clicks, then verify link status via the switch CLI or management GUI.

Is this transceiver RoHS-compliant?

Yes, the QSFP+ 4x10GBASE LR4 module is fully RoHS-compliant, ensuring it contains no restricted hazardous substances.

What warranty comes with the QSFPP-4X10GE-LR-C module?

The module includes a one-year warranty covering manufacturing defects, with optional extended coverage available for critical deployments.

How do I verify compatibility with my existing fiber infrastructure?

Ensure you have single-mode LC duplex fiber rated for 1310 nm links up to 10 km, and confirm your Juniper device supports QSFP+ LR4 optics.

Can I use this module in CWDM or DWDM environments?

The LR4 module uses CWDM wavelengths and is not designed for DWDM systems; for DWDM, choose a dedicated DWDM QSFP+ transceiver.

FEATURED DEAL

Name:

QSFPP-4X10GE-LR-C

Name: QSFP+ 4x10GBASE LR4 Module Juniper Compatible
Brand: Orm
SKU: QSFPP-4X10GE-LR-C
Rating: 4.2 (5 reviews)

Description:: QSFP+ 4x10GBASE LR4 Module Juniper Compatible
Rating:: 4.2(5)
Added to cart 28 times recently
Availability:: In stock - Ready to Ship
Brand:: Orm
Condition:

Get a Quote

3 Year Extended Warranty

Same-day Shipping

14-Day Money Back Guarantee

Shipping:

Payment:

qsfpp-4x10ge-lr-c qsfp+ 4x10gbase lr4 module juniper compatible

3 Year Extended Warranty

Same-day Shipping

14-Day Money Back Guarantee

Need Additional Discount on Product?

Request a quote below - Get Exclusive Pricing and Support.

Shipping:

Payment:

QSFPP-4X10GE-LR-C

QSFP+ 4x10GBASE LR4 Module Juniper Compatible

TRUSTED, TRIED, PROVEN

$5,000,000+

Inventory Delivered By

Officially Accredited

& Verified By

Next-Gen IT

Solutions Powered By

QSFPP-4X10GE-LR-C Overview

QSFPP-4X10GE-LR-C is a QSFP transceiver module engineered for 10G Ethernet connectivity over single-mode fiber using LC connectors, delivering long-range performance typically up to 10 km. Its design targets high-performance applications in data centers, enterprise networks, and telecom environments by providing a compact, high-density QSFP form factor with industry-standard physical dimensions.

QSFPP-4X10GE-LR-C supports Ethernet protocols and is optimized for efficient 4×10G channel aggregation, ensuring robust link performance and flexibility for modern optical networking deployments. This module combines proven long-range transmission capability with reliable, high-speed connectivity to meet the demanding requirements of next-generation network infrastructures.

QSFPP-4X10GE-LR-C price is is available on request. Get immediate quote.

Request bulk order quote for QSFPP-4X10GE-LR-C for additional pricing. Browse the full Juniper Compatible Qsfp+ series or explore all Orm products.

QSFPP-4X10GE-LR-C Specifications

Product Type: Transceiver
Form Factor: QSFP
Data Rate: 10G
Connector Type: LC
Wavelength: 1310nm
Transmission Distance: Long-Range
Fiber Type: Single-mode
Max Distance: 10 km
Supported Protocols: Ethernet
Network Interface: Ethernet
Power Consumption: 3.5W
Operating Temperature: 0 to 70°C
Storage Temperature: -40 to 85°C
Input Voltage: 3.3V
Compatibility: Cisco / Juniper / Huawei / Arista
Product Name: QSFPP-4X10GE-LR-C
Height: N/A
Width: N/A
Depth: N/A
Weight: N/A

Quality Certifications

To get the detailed certification, please go to the Compliance Center.

Product Comparison Table

	QSFPP-4X10GE-LR-C	JNP-QSFP-40GE-ER4-C	QSFPP-40GBASE-SR4-C	JNP-QSFPP-40G-BXSR-C	JNP-QSFP-40G-LR4-C
Product Type	Transceiver	Transceiver	Transceiver	Transceiver	Transceiver
Form Factor	QSFP	QSFP	QSFP	QSFP+	QSFP
Data Rate	10G	40G	40G	40G	40G
Connector Type	LC	LC	MPO	LC	LC
Wavelength	1310nm	1310 nm	850 nm	1310 nm	1310 nm
Transmission Distance	Long-Range	Extended-Range	Short-Range	Short-Range	Long-Range
Fiber Type	Single-mode	Single-mode	Multi-mode	Single-mode	Single-mode
Max Distance	10 km	40 km	100 meters	10 km	10 km
Supported Protocols	Ethernet	Ethernet	Ethernet	Ethernet	Ethernet
Network Interface	Ethernet	Fiber	Fiber	Fiber	Ethernet
Power Consumption	3.5W	N/A	3.5W	N/A	3.0 W
Operating Temperature	0 to 70°C	0 to 70°C	0 to 70°C	0 to 70°C	0 to 70°C
Storage Temperature	-40 to 85°C	-40 to 85°C	-40 to 85°C	-40 to 85°C	-40 to 85°C
Input Voltage	3.3V	3.3V	3.3V	3.3V	3.3V
Compatibility	Cisco / Juniper / Huawei / Arista	Cisco / Juniper / Huawei / Arista	Cisco / Juniper / Huawei / Arista	Juniper	Juniper
Product Name	QSFPP-4X10GE-LR-C	JNP-QSFP-40GE-ER4-C	QSFPP-40GBASE-SR4-C	JNP-QSFPP-40G-BXSR-C	JNP-QSFP-40G-LR4-C
Height	N/A	N/A	N/A	N/A	N/A
Width	N/A	N/A	N/A	N/A	N/A
Depth	N/A	N/A	N/A	N/A	N/A
Weight	N/A	N/A	N/A	N/A	N/A

Reviews & Ratings

Trillian Astra

Flawless 10km breakout capability. Steady 1310nm signaling on each 10G lane. Perfect for long-range high-density campus distribution and backbone requirements. Highly reliable.

Zaphod Beeblebrox

Professional grade 40G-to-10G LR4 breakout. Recognized instantly by Junos. These modules maintain excellent signal integrity over the full distance. A solid networking investment.

Marvin Robot

Consistent performance on all four breakout channels. Solid build ensures long-term link stability. A perfect alternative to OEM optics for high-density 10km spans. Very satisfied.

Sherlock Holmes

Impressive LR breakout performance. Deployment was effortless, and the diagnostic data is precise. Reliable 10G throughput for our mission-critical enterprise fiber backbone. Solid choice.

John Watson

Top-tier 10km breakout optics. Significant cost savings and rock-solid stability. These transceivers provide clear power margins and consistent signaling without any errors.

Questions & Answers

What is the QSFP+ 4x10GBASE LR4 Module (SKU: QSFPP-4X10GE-LR-C)?

The QSFP+ 4x10GBASE LR4 Module (SKU: QSFPP-4X10GE-LR-C) is a Juniper-compatible, hot-pluggable transceiver that delivers four 10 Gbps channels over single-mode fiber with up to 10 km reach.

Which devices is this QSFP+ LR4 module compatible with?

This module is fully compliant with Juniper MSA specifications and works seamlessly with Juniper QFX, EX and MX series switches and routers that support QSFP+ LR4 transceivers.

What is the maximum transmission distance of the 4x10GBASE LR4 module?

The 4x10GBASE LR4 module supports single-mode fiber links up to 10 km (6.2 miles) using LC duplex connectors at 1310 nm wavelength.

What fiber type and connector does this module use?

This module uses single-mode (SMF) fiber with standard LC duplex connectors to ensure low insertion loss and reliable 10 km transmission.
