Name: S5710-28C-PWR-EI-AC(24 Ethernet 10/100/1000 PoE+ ports,4 of which are dual-purpose 10/100/1000 or SFP,4 10 Gig SFP+,with 580W AC power)
Brand: Huawei
SKU: S5710-28C-PWR-EI-AC
Rating: 4.5 (6 reviews)

Question 1

What is the Huawei S5710-28C-PWR-EI-AC?

Accepted Answer

The S5710-28C-PWR-EI-AC is a high-performance access switch featuring 24 Gigabit PoE+ ports, 4 dual-purpose 10/100/1000 or SFP ports, 4 10 Gbps SFP+ uplinks, and a 580 W AC power supply, delivering Layer 3 routing, QoS, and secure management for enterprise networks.

Question 2

How many PoE+ ports does the S5710-28C-PWR-EI-AC have?

Accepted Answer

It provides 24 10/100/1000 Mbps PoE+ ports, each capable of delivering up to 30 W of power to IP phones, wireless APs, and surveillance cameras.

Question 3

What is the total PoE power budget of this switch?

Accepted Answer

The S5710-28C-PWR-EI-AC delivers a total PoE power budget of 580 W to support simultaneous powering of multiple high-demand PoE devices.

Question 4

Which uplink ports are available on the S5710-28C-PWR-EI-AC?

Accepted Answer

It includes 4 dual-purpose 10/100/1000BASE-T or SFP ports plus 4 dedicated 10 Gbps SFP+ uplink ports for flexible fiber or copper connectivity and stacking.

Question 5

What are dual-purpose Ethernet/SFP ports?

Accepted Answer

Dual-purpose ports support both RJ45 Gigabit Ethernet modules and SFP fiber modules on the same interface, enabling seamless migration between copper and fiber links.

Question 6

What switching capacity and forwarding performance does it offer?

Accepted Answer

The switch delivers a switching capacity of 336 Gbps and a forwarding rate of up to 250 Mpps, ensuring low latency and high throughput for enterprise traffic.

Question 7

Does the S5710-28C-PWR-EI-AC support Layer 3 routing?

Accepted Answer

Yes, it supports static routing, RIP, OSPF, VRRP, and policy-based routing, providing advanced Layer 3 routing and redundancy for complex network topologies.

Question 8

What Quality of Service (QoS) features are supported?

Accepted Answer

It offers 8 priority queues, traffic classification, shaping, policing, and congestion avoidance mechanisms to ensure optimized handling of voice, video, and data services.

Question 9

Which network management options are available?

Accepted Answer

Management methods include web-based GUI, CLI via console/SSH, SNMP v1/v2c/v3, RMON, and Huawei eSight for centralized monitoring and configuration.

Question 10

What security features does this switch offer?

Accepted Answer

Security features include 802.1X authentication, MAC address filtering, port security, DHCP snooping, Dynamic ARP Inspection, and IP Source Guard to protect against unauthorized access.

Question 11

What are the power supply and redundancy options?

Accepted Answer

Equipped with a built-in 580 W AC power supply, it supports hot-swappable AC power modules (optional) for uninterrupted operation and high availability.

Question 12

What are the dimensions and weight of the S5710-28C-PWR-EI-AC?

Accepted Answer

The switch measures 440 × 280 × 43.6 mm and weighs approximately 3.9 kg, fitting standard 19-inch rack installations with 1U height.

Question 13

What is the operating temperature and humidity range?

Accepted Answer

It operates reliably between 0 °C to 45 °C with 5% to 95% non-condensing humidity, suitable for data center and enterprise wiring closets.

Question 14

What certifications does the S5710-28C-PWR-EI-AC hold?

Accepted Answer

The switch is RoHS compliant and certified to CE, FCC, UL, TUV, and CB standards, ensuring safety, electromagnetic compatibility, and environmental compliance.

Question 15

What warranty and support options are available?

Accepted Answer

Huawei offers a limited lifetime hardware warranty, free software updates, and optional software and onsite support packages for enhanced service levels.

Question 16

Which use cases are ideal for this switch?

Accepted Answer

The S5710-28C-PWR-EI-AC is ideal for campus access, small-to-medium enterprise networks, PoE-powered devices, wireless backhaul, and high-density VoIP deployments.

	S5710-28C-PWR-EI-AC	S5730-36C-HI-24S	S5735S-L32ST4X-A	S5720S-28P-LI-AC	S5730-44C-HI-24S
Depth	11.3 inches	20 inches	12 inches	10 inches	18 inches
Ethernet Technology	10/100/1000	10/100/1000	10/100/1000	10/100/1000	10/100/1000
Flash Memory	64 MB	64 MB	64 MB	64 MB	256 MB
Form Factor	Rack-mount	Rack-mount	Rack-mount	Rack-mount	Rack-mount
Height	1.73 inches	1.75 inches	1.75 inches	1.75 inches	1.75 inches
IOS	IP Lite	IP Services	LAN Base	LAN Lite	IP Services
Interface Ports	10/100/1000	10/100/1000	10/100/1000	10/100/1000	10/100/1000
Layer Supported	Layer 2	Layer 2 / Layer 3	Layer 2	Layer 2	Layer 3
Manageable	Managed	Managed	Managed	Managed	Managed
Manufacturer Part Number	S5710-28C-PWR-EI-AC	S5730-36C-HI-24S	S5735S-L32ST4X-A	S5720S-28P-LI-AC	S5730-44C-HI-24S
Media Type Supported	Twisted Pair/Fiber Combo	Combo	Twisted Pair / Fiber	Twisted Pair / Fiber	Combo
Memory	256 MB	256 MB	256 MB	256 MB	256 MB
Number of Downlink Ports	24 Ports	24 Ports	32 Ports	N/A	48 Ports
Number of Ethernet Ports	24–48 Ports	24–48 Ports	24–48 Ports	24–48 Ports	24–48 Ports
POE Support	POE	Non POE	Non POE	POE	Non POE
Port/Expansion Slot Details	24 fixed Ethernet ports with 4 SFP uplink ports	24 fixed SFP ports	32 x 10/100/1000 Ethernet ports, 4 x 10G SFP+ uplink ports	24 x 10/100/1000 RJ45 ports and 4 x 1G SFP uplink ports	44 copper Ethernet ports and 24 SFP ports
Power Consumption	40W	130 W	N/A	N/A	160W
Power Source	AC Power Supply	AC Power Supply	Redundant Power Supply / AC Power Supply	AC Power Supply	Redundant Power Supply / AC Power Supply
Product Name	H3C S5710-28C-PWR-EI-AC Switch	S5730-36C-HI-24S High-Performance Enterprise Switch	S5735S-L32ST4X-A Stackable Gigabit Switch	Huawei S5720S-28P-LI-AC Ethernet Switch	H3C S5730-44C-HI-24S Ethernet Switch
Product Type	Switch	Switch	Switch	Switch	Switch
Rack Units	1 RU	1 RU	1 RU	1 RU	1 RU
Redundant Power Supply Supported	No	No	Yes	No	Yes
SFP Ports	4 SFP Ports	24 SFP Ports	4 SFP Ports	4 SFP Ports	24 SFP Ports
Switching Capacity	128 Gbps	216 Gbps	128 Gbps	128 Gbps	320 Gbps
Switching Capacity with Stacking	256 Gbps	432 Gbps	256 Gbps	256 Gbps	640 Gbps
Uplink Configuration	1G	10G	10G	1G	10G
Weight	14 lbs	15 lbs	16 lbs	12 lbs	12 lbs
Width	17.2 inches	17.5 inches	19 inches	17.5 inches	17.5 inches
