WS-C6509E-S32-10GE Overview
WS-C6509E-S32-10GE is a high-performance modular switch featuring a robust chassis architecture designed to accommodate a 32-slot configuration, which offers advanced scalability and flexibility for growing enterprise and data center networks. With powerful routing and switching capabilities, it supports both Layer 2 and Layer 3 operations, ensuring efficient traffic management and network segmentation.
WS-C6509E-S32-10GE provides versatile power options with redundant and AC power supplies, fortified by integrated 10GE uplink ports that deliver exceptional throughput and low latency. Its stacking and expansion slot features enhance system performance and resiliency, making it ideally suited for mission-critical applications in campuses, enterprise cores, and service provider environments.
WS-C6509E-S32-10GE price is is available on request. Get immediate quote.
Request bulk order quote for WS-C6509E-S32-10GE for additional pricing. Browse the full Cisco Catalyst 6500 Switches series or explore all Cisco products.
WS-C6509E-S32-10GE Specifications
- Product Type
- Switch
- Power Source
- Redundant Power Supply / AC Power Supply
- Layer Supported
- Layer 2 / Layer 3
- Form Factor
- Chassis
- Power Consumption
- N/A
- Number of Ethernet Ports
- Over 48 Ports
- Number of Downlink Ports
- 32 Ports
- Manageable
- Managed
- Ethernet Technology
- 10/100/1000
- Media Type Supported
- Fiber / Combo
- Redundant Power Supply Supported
- Yes
- Manufacturer Part Number
- WS-C6509E-S32-10GE
- Uplink Configuration
- 10G
- IOS
- IP Services
- POE Support
- Non POE
- SFP Ports
- 4 SFP Ports
- Memory
- 256 MB
- Rack Units
- 4 RU
- Interface Ports
- 10/100/1000
- Port/Expansion Slot Details
- 32-slot chassis with 10GE uplink options
- Flash Memory
- 256 MB
- Switching Capacity
- 480 Gbps
- Switching Capacity with Stacking
- N/A
- Product Name
- Cisco WS-C6509E-S32-10GE
- Height
- 4.5 inches
- Width
- 17.5 inches
- Depth
- 22 inches
- Weight
- 125 lbs
WS-C6509E-S32-10GE Use Case
Enterprise Data Center Core with High-Density 10G Aggregation
Scenario: A global enterprise data center deploys the WS-C6509E-S32-10GE Catalyst 6509E chassis populated with WS-SUP32-10GE-3B supervisor engines and redundant Fan Tray (req. P/S) modules to consolidate spine and leaf switching at 10 Gbps. Benefit/Outcome: Delivers 480 Gbps of non-blocking throughput, sub-10 ms supervisor failover and hot-swappable fan trays for 99.999% availability, enabling seamless VM mobility and application performance at scale.
Campus Network Aggregation with Modular 10G Uplinks
Scenario: A large university campus implements the Catalyst 6509E chassis (WS-C6509E-S32-10GE) with dual WS-SUP32-10GE-3B supervisors and Fan Tray (req. P/S) to aggregate building-level 1 Gbps access switches into a centralized 10 Gbps core. Benefit/Outcome: Achieves high-density 10G uplinks, centralized QoS policies and power redundancy for future growth, reducing network latency by 40% and simplifying tier-2 support.
Service Provider Edge Routing and Switching Platform
Scenario: A regional service provider uses the Catalyst 6509E chassis (WS-C6509E-S32-10GE) with WS-SUP32-10GE-3B and Fan Tray (req. P/S) at the edge POPs to terminate multiple 10 Gbps customer links and run advanced MPLS/segment routing. Benefit/Outcome: Offers carrier-grade resiliency with dual supervisors, 10G forwarding capacity of 320 Mpps and fan redundancy to ensure five-nines uptime, accelerating service turn-up and SLA compliance.
Quality Certifications
To get the detailed certification, please go to the Compliance Center.
Product Comparison Table
| WS-C6509E-S32-10GE |  WS-C6506-E-FWM-K9 |  WS-C6506-E |  WS-C6504E-S32P10GE |  VS-C6509E-S720-10G | |
|---|---|---|---|---|---|
| Depth | 22 inches | N/A | N/A | 30 inches | N/A |
| Ethernet Technology | 10/100/1000 | 10/100/1000 | 10/100/1000 | 10/100/1000 | 10/100/1000 |
| Flash Memory | 256 MB | 64 MB | 256 MB | 256 MB | 256 MB |
| Form Factor | Chassis | Chassis | Chassis | Chassis | Chassis |
| Height | 4.5 inches | N/A | N/A | 7 inches | N/A |
| IOS | IP Services | IP Services | IP Services | IP Services | IP Services |
| Interface Ports | 10/100/1000 | 10/100/1000 | 10/100/1000 | 10/100/1000 | 10/100/1000 |
| Layer Supported | Layer 2 / Layer 3 | Layer 2 / Layer 3 | Layer 2 / Layer 3 | Layer 2 / Layer 3 | Layer 2 / Layer 3 |
| Manageable | Managed | Managed | Managed | Managed | Managed |
| Manufacturer Part Number | WS-C6509E-S32-10GE | WS-C6506-E-FWM-K9 | WS-C6506-E | WS-C6504E-S32P10GE | VS-C6509E-S720-10G |
| Media Type Supported | Fiber / Combo | Twisted Pair | Twisted Pair / Fiber / Combo | Combo | Fiber / Combo |
| Memory | 256 MB | 256 MB | 256 MB | 256 MB | 256 MB |
| Number of Downlink Ports | 32 Ports | N/A | N/A | 32 Ports | 48 Ports |
| Number of Ethernet Ports | Over 48 Ports | Under 12 Ports | Over 48 Ports | 24–48 Ports | Over 48 Ports |
| POE Support | Non POE | Non POE | Non POE | POE | Non POE |
| Port/Expansion Slot Details | 32-slot chassis with 10GE uplink options | Integrated management interfaces and expansion slots for service modules | 6 modular slots for line cards | 4 expansion slots | 9 module slots with support for 10G uplinks |
| Power Consumption | N/A | 530 W | N/A | N/A | N/A |
| Power Source | Redundant Power Supply / AC Power Supply | Redundant Power Supply | Redundant Power Supply / AC Power Supply | Redundant Power Supply / AC Power Supply | Redundant Power Supply / AC Power Supply |
| Product Name | Cisco WS-C6509E-S32-10GE | Cisco Catalyst 6506-E Supervisor Engine with FWM | Cisco Catalyst 6506-E Chassis Switch | Cisco Catalyst 6504-E with 32-Port PoE and 10 Gigabit Ethernet Uplink | Cisco Catalyst VS-C6509E-S720-10G |
| Product Type | Switch | Supervisor Module | Switch | Switch | Switch |
| Rack Units | 4 RU | 1 RU | 4 RU | 4 RU | 4 RU |
| Redundant Power Supply Supported | Yes | Yes | Yes | Yes | Yes |
| SFP Ports | 4 SFP Ports | N/A | N/A | 4 SFP Ports | 4 SFP Ports |
| Switching Capacity | 480 Gbps | N/A | N/A | 320 Gbps | 720 Gbps |
| Switching Capacity with Stacking | N/A | N/A | N/A | N/A | N/A |
| Uplink Configuration | 10G | 10G | 1G / 10G | 10G | 10G |
| Weight | 125 lbs | N/A | N/A | 80 lbs | N/A |
| Width | 17.5 inches | N/A | N/A | 19 inches | N/A |
