1JS67AW

Specification Of 1JS67AW

Processor
Processor manufacturer	Intel
Processor family	7th gen Intel® Core™ i5
Processor model	i5-7500
Processor cores	4
Processor frequency	3.4 GHz
Processor boost frequency	3.8 GHz
Processor socket	LGA 1151 (Socket H4)
Processor cache	6 MB
Processor cache type	Smart Cache
Processor threads	4
System bus rate	8 GT/s
Bus type	DMI3
Processor lithography	14 nm
Processor operating modes	64-bit
Processor series	Intel Core i5-7500 Desktop Series
Processor codename	Kaby Lake
Thermal Design Power (TDP)	65 W
Tjunction	100 °C
PCI Express slots version	3.0
Maximum number of PCI Express lanes	16
PCI Express configurations	1x16,1x8+2x4,2x8
Number of processors installed	1
Stepping	B0
Maximum internal memory supported by processor	64 GB
Memory types supported by processor	DDR3L-SDRAM,DDR4-SDRAM
Memory clock speeds supported by processor	1333,1600,2133,2400 MHz
ECC supported by processor	No
Memory voltage supported by processor	1.35 V
Memory
Internal memory	8 GB
Internal memory type	DDR4-SDRAM
Maximum internal memory	64 GB
Memory layout (slots x size)	2 x 4 GB
Memory slots	4x DIMM
Memory clock speed	2400 MHz
Memory channels	Dual-channel
Storage
Total storage capacity	500 GB
Optical drive type	DVD-RW
Storage media	HDD
Number of storage drives installed	1
Total HDDs capacity	500 GB
Number of HDDs installed	1
HDD capacity	500 GB
HDD interface	Serial ATA
HDD speed	7200 RPM
Intel® Optane™ Memory module installed	No
Software
Operating system installed	Windows 10 Pro
Operating system architecture	64-bit
Design
Chassis type	SFF
Number of 3.5" bays	1
Number of 2.5" bays	1
Product colour	Black,Silver
Country of origin	China
Packaging content
Display included	No
Mouse included	No
Keyboard included	Yes
Graphics
Discrete graphics adapter	No
On-board graphics adapter	No
Discrete graphics adapter model	Not available
On-board graphics adapter model	Intel® HD Graphics 630
On-board graphics adapter base frequency	350 MHz
On-board graphics adapter dynamic frequency (max)	1100 MHz
Maximum on-board graphics adapter memory	64 GB
Number of displays supported (on-board graphics)	3
On-board graphics adapter DirectX version	12.0
On-board graphics adapter OpenGL version	4.4
On-board graphics adapter ID	5912
Performance
Product type	PC
Power
Power supply	180 W
Ports & interfaces
USB 2.0 ports quantity	6
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	4
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity	1
DVI port	No
DisplayPorts quantity	2
Ethernet LAN (RJ-45) ports	1
Microphone in	Yes
Headphone outputs	1
Line-out	Yes
Line-in	Yes
Brand-specific features
HP ePrint	Yes
HP Support Assistant	Yes
HP Management tools	HP Client Catalog; HP Driver Packs; HP SoftPaq Download Manager (SDM); HP System Software Manager (SSM); HP BIOS Config Utility (BCU); HP Image Assistant; HP MIK for Microsoft SCCM
HP Software provided	HP BIOSphere Gen3
Network
Ethernet LAN	Yes
Ethernet LAN data rates	10,100,1000 Mbit/s
Cabling technology	10/100/1000Base-T(X)
Expansion slots
PCI Express x16 slots	2
Weight & dimensions
Width	270 mm
Depth	95 mm
Height	29.6 mm
Weight	4.53 kg
Processor special features
Intel 64	Yes
Enhanced Intel SpeedStep Technology	Yes
Embedded options available	Yes
Intel® InTru™ 3D Technology	Yes
Intel® Clear Video HD Technology (Intel® CVT HD)	Yes
Intel Clear Video Technology	Yes
Intel VT-x with Extended Page Tables (EPT)	Yes
Intel TSX-NI	Yes
Idle States	Yes
Thermal Monitoring Technologies	Yes
Intel Stable Image Platform Program (SIPP)	Yes
Intel® AES New Instructions (Intel® AES-NI)	Yes
Intel® Secure Key	No
Intel® OS Guard	Yes
Intel Trusted Execution Technology	Yes
Execute Disable Bit	Yes
Intel Enhanced Halt State	Yes
Intel Software Guard Extensions (Intel SGX)	Yes
Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)	Yes
Processor package size	37.5 x 37.5 mm
Supported instruction sets	AVX 2.0,SSE4.1,SSE4.2
Processor code	SR335
Scalability	1S
CPU configuration (max)	1
Thermal solution specification	PCG 2015C
Intel Virtualization Technology for Directed I/O (VT-d)	Yes
Intel Identity Protection Technology version	1.00
Intel Stable Image Platform Program (SIPP) version	1.00
Intel Secure Key Technology version	1.00
Intel Virtualization Technology (VT-x)	Yes
Intel TSX-NI version	1.00
Processor ARK ID	97123
Intel® Optane™ Memory Ready	Yes
Intel® Turbo Boost Technology	2.0
Intel® Hyper Threading Technology (Intel® HT Technology)	No
Intel® Quick Sync Video Technology	Yes
Intel® Identity Protection Technology (Intel® IPT)	Yes
Conflict-Free processor	Yes
Technical details
Sustainability certificates	EPEAT Silver, ENERGY STAR
Other features
Intel segment tagging	Enterprise, Small Business
