7PF25EA

Specification Of 7PF25EA

Memory
Internal memory	16 GB
Internal memory type	DDR4-SDRAM
Memory layout (slots x size)	1 x 16 GB
Memory slots	2x SO-DIMM
Memory clock speed	2666 MHz
ECC	No
Processor
Processor manufacturer	Intel
Processor family	9th gen Intel® Core™ i5
Processor model	i5-9500T
Processor cores	6
Processor frequency	2.2 GHz
Processor boost frequency	3.7 GHz
Processor socket	LGA 1151 (Socket H4)
Processor cache	9 MB
Processor cache type	L3
Processor threads	12
System bus rate	8 GT/s
Processor lithography	14 nm
Processor operating modes	64-bit
Thermal Design Power (TDP)	35 W
Configurable TDP-down	25 W
Configurable TDP-down frequency	1.6 GHz
Tjunction	100 °C
PCI Express slots version	3.0
Maximum number of PCI Express lanes	16
PCI Express configurations	1x8+2x4,1x16,2x8
Number of processors installed	1
Maximum internal memory supported by processor	128 GB
Memory types supported by processor	DDR4-SDRAM
Memory clock speeds supported by processor	2666 MHz
Memory bandwidth supported by processor (max)	41.6 GB/s
Storage
Card reader integrated	No
Total storage capacity	512 GB
Optical drive type	No
Storage media	SSD
Total SSDs capacity	512 GB
Number of SSDs installed	1
SSD capacity	512 GB
SSD memory type	TLC
SSD interface	PCI Express,NVMe
SSD form factor	M.2
Software
Operating system installed	Windows 10 Pro
Operating system architecture	64-bit
Design
Chassis type	mini PC
Product colour	Black
Country of origin	China
Packaging content
Display included	No
Keyboard included	Yes
Graphics
Discrete graphics adapter	No
On-board graphics adapter	Yes
Discrete graphics adapter model	Not available
On-board graphics adapter family	Intel® UHD Graphics
On-board graphics adapter model	Intel® UHD Graphics 630
On-board graphics adapter base frequency	350 MHz
On-board graphics adapter dynamic frequency (max)	1100 MHz
Maximum on-board graphics adapter memory	64 GB
Number of displays supported (on-board graphics)	3
On-board graphics adapter DirectX version	12.0
On-board graphics adapter OpenGL version	4.5
On-board graphics adapter ID	0x3E92
Performance
Product type	Mini PC
Market positioning	Business
Audio chip	Intel Q370
Audio chip	Conexant CX20632
Power
Power supply	65 W
Ports & interfaces
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	3
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	3
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity	1
VGA (D-Sub) ports quantity	1
DVI port	No
DisplayPorts quantity	2
DisplayPort version	1.2
Ethernet LAN (RJ-45) ports	1
Microphone in	No
Headphone outputs	1
Combo headphone/mic port	Yes
Network
Ethernet LAN	Yes
Ethernet LAN data rates	10,100,1000 Mbit/s
Wi-Fi	No
Wi-Fi standards	802.11a,802.11b,802.11g,Wi-Fi 4 (802.11n),Wi-Fi 5 (802.11ac)
WLAN controller manufacturer	Intel
WLAN controller model	Intel Dual Band Wireless-AC 9560
Antenna type	2x2
Bluetooth version	5.0
Weight & dimensions
Width	177 mm
Depth	175 mm
Height	34 mm
Weight	1.25 kg
Package width	497 mm
Package depth	128 mm
Package height	223 mm
Package weight	3.34 kg
Processor special features
Intel 64	Yes
Enhanced Intel SpeedStep Technology	Yes
Embedded options available	No
Intel® InTru™ 3D Technology	Yes
Intel® Clear Video HD Technology (Intel® CVT HD)	Yes
Intel Clear Video Technology	Yes
Intel VT-x with Extended Page Tables (EPT)	Yes
Intel TSX-NI	Yes
Idle States	Yes
Thermal Monitoring Technologies	Yes
Intel Stable Image Platform Program (SIPP)	Yes
Intel® AES New Instructions (Intel® AES-NI)	Yes
Intel® Secure Key	Yes
Intel® OS Guard	Yes
Intel Trusted Execution Technology	Yes
Execute Disable Bit	Yes
Intel Software Guard Extensions (Intel SGX)	Yes
Processor package size	37.5 x 37.5 mm
Supported instruction sets	AVX 2.0,SSE4.1,SSE4.2
Scalability	1S
CPU configuration (max)	1
Thermal solution specification	PCG 2015A
Intel Virtualization Technology for Directed I/O (VT-d)	Yes
Intel Virtualization Technology (VT-x)	Yes
Processor ARK ID	191052
Intel® Turbo Boost Technology	2.0
Intel® Hyper Threading Technology (Intel® HT Technology)	No
Intel® Quick Sync Video Technology	Yes
Intel® Identity Protection Technology (Intel® IPT)	Yes
Brand-specific features
HP segment	Business
