7PF30EA

Specification Of 7PF30EA

Processor
Processor manufacturer	Intel
Processor family	9th gen Intel® Core™ i5
Processor model	i5-9500
Processor frequency	3 GHz
Processor boost frequency	4.4 GHz
Processor cores	6
Processor threads	6
Processor cache	9 MB
Processor cache type	L3
System bus rate	8 GT/s
Motherboard chipset	Intel Q370
Thermal Design Power (TDP)	65 W
PCI Express slots version	3.0
Processor socket	LGA 1151 (Socket H4)
Processor lithography	14 nm
Processor operating modes	64-bit
Maximum number of PCI Express lanes	16
PCI Express configurations	1x8+2x4,1x16,2x8
Tjunction	100 °C
Maximum internal memory supported by processor	128 GB
Memory types supported by processor	DDR4-SDRAM
Memory clock speeds supported by processor	2666 MHz
Memory bandwidth supported by processor (max)	41.6 GB/s
Display
Display diagonal	54.6 cm
Display resolution	1920 x 1080 pixels
Touchscreen	Yes
HD type	Full HD
LED backlight	Yes
Aspect ratio	16:9
Display brightness	250 cd/m²
Panel type	IPS
Screen shape	Flat
RGB colour space	NTSC
Anti-glare screen	Yes
Colour gamut	72 %
Memory
Internal memory	8 GB
Internal memory type	DDR4-SDRAM
Memory slots	1
Memory slots type	SO-DIMM
Memory clock speed	2666 MHz
Memory layout (slots x size)	1 x 8 GB
ECC	No
Memory form factor	DIMM/SO-DIMM
Storage
Total storage capacity	256 GB
Storage media	SSD
Total SSDs capacity	256 GB
Number of SSDs installed	1
SSD capacity	256 GB
SSD memory type	TLC
SSD interface	NVMe
SSD form factor	M.2
Optical drive type	No
Card reader integrated	Yes
Compatible memory cards	SD
Graphics
Discrete graphics adapter	No
Discrete graphics adapter model	Not available
On-board graphics adapter	Yes
On-board graphics adapter model	Intel® UHD Graphics 630
On-board graphics adapter base frequency	350 MHz
On-board graphics adapter dynamic frequency (max)	1100 MHz
Maximum on-board graphics adapter memory	64 GB
Number of displays supported (on-board graphics)	3
On-board graphics adapter DirectX version	12.0
On-board graphics adapter OpenGL version	4.5
On-board graphics adapter ID	0x3E92
Network
Wi-Fi	Yes
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
Wi-Fi standard	802.11a,802.11b,802.11g,Wi-Fi 4 (802.11n),Wi-Fi 5 (802.11ac)
WLAN controller manufacturer	Intel
WLAN controller model	Intel Dual Band Wireless-AC 9560
Antenna type	2x2
Ethernet LAN	Yes
Ethernet LAN data rates	10,100,1000 Mbit/s
Bluetooth	Yes
Bluetooth version	5.0
Software
Operating system installed	Windows 10 Pro
Operating system architecture	64-bit
Design
Product colour	Black
Country of origin	China
Packaging content
Mouse included	Yes
Keyboard included	Yes
Ports & interfaces
Ethernet LAN (RJ-45) ports	1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	4
USB 2.0 ports quantity	1
DisplayPorts quantity	1
DC-in jack	Yes
Microphone in	Yes
Combo headphone/mic port	Yes
Brand-specific features
HP segment	Business
HP Security tools	HP BIOSphere; HP Client Security Suite; HP Credential Manager; HP Password Manager; HP Power On Authentication; HP Spare Key; HP Sure Sense; HP Sure Start
HP Management tools	HP BIOS Config Utility (download); HP Client Catalog (download); HP Driver Packs (download); HP Image Assistant; HP System Software Manager (download); HP Management Integration Kit for Microsoft System Center Configuration Management Gen 2
Pen
Pen included	No
Other features
3D	No
Display diagonal (metric)	54.6 cm
Autonomy mode	No
Detachable display	No
Performance
Market positioning	Business
Product type	All-in-One PC
Trusted Platform Module (TPM)	Yes
Audio
Built-in speaker(s)	Yes
Built-in microphone	Yes
Camera
Built-in camera	Yes
Total megapixels	2 MP
Camera HD type	Full HD
Power
AC adapter power	120 W
Weight & dimensions
Width (with stand)	489.1 mm
Depth (with stand)	208.5 mm
Height (with stand)	363.7 mm
Weight (with stand)	5.78 kg
Package width	596 mm
Package depth	246 mm
Package height	468 mm
Package weight	9.37 kg
Processor special features
Intel® Turbo Boost Technology	2.0
Intel® Hyper Threading Technology (Intel® HT Technology)	No
Intel® Identity Protection Technology (Intel® IPT)	Yes
Enhanced Intel SpeedStep Technology	Yes
Intel® Quick Sync Video Technology	Yes
Intel® Clear Video HD Technology (Intel® CVT HD)	Yes
Intel Clear Video Technology	Yes
Intel® InTru™ 3D Technology	Yes
Intel® AES New Instructions (Intel® AES-NI)	Yes
Intel Trusted Execution Technology	Yes
Intel VT-x with Extended Page Tables (EPT)	Yes
Intel® Secure Key	Yes
Intel TSX-NI	Yes
Intel Stable Image Platform Program (SIPP)	Yes
Intel® OS Guard	Yes
Intel Software Guard Extensions (Intel SGX)	Yes
Intel 64	Yes
Execute Disable Bit	Yes
Idle States	Yes
Thermal Monitoring Technologies	Yes
Processor package size	37.5 x 37.5 mm
Supported instruction sets	AVX 2.0,SSE4.1,SSE4.2
Scalability	1S
CPU configuration (max)	1
Embedded options available	No
Thermal solution specification	PCG 2015C
Intel Virtualization Technology for Directed I/O (VT-d)	Yes
Intel Virtualization Technology (VT-x)	Yes
Processor ARK ID	134895
Intel® vPro™ Platform Eligibility	No
