55V3-48G-AC2-16

55V3-48G-AC2-16 Specifications

Technical Specifications

Controller Enclosure Specifications

Storage Processors

Multi-core processors

System Cache (Expanded with the Number of Controllers)

48 GB to 512 GB

Max. Number of Controllers

8

Supported Storage Protocols

Fibre Channel, FCoE, iSCSI, InfiniBand, NFS, CIFS, HTTP, and FTP

Port Types

1 Gbit/s Ethernet, 10 Gbit/s FCoE, 10 Gbit/s TOE, 16 Gbit/s FC, and 56 Gbit/s InfiniBand, SAS 3.0 (back-end, 4 x 12 Gbit/s per port)

Max. Number of Disks Supported by Two Controllers

750

Max. Number of Front-end Ports per Controller

20

Max. Number of Hot Swappable I/O Modules per Controller

2

Disk Types and Supported RAID Levels

Disk types: SSD, SAS, and NL-SAS

RAID levels: 0, 1, 3, 5, 6, 10, or 50

Max. Raw Capacity (All-SSD, Dual-Controller Configuration)

2,700 TB

Maximum Number of Snapshots (LUN)

4,096

Maximum Number of LUNs

8,192

Maximum Number of

Snapshots per File System

2,048

Maximum Capacity of a Single File

256TB

Gateway Mode

Supported

Virtualization Features

·Heterogeneous virtualization: Consolidates storage resources of mainstream products to manage and allocate in a flexible and unified manner

·Block virtualization: Balanced data distribution, quick fault recovery

·Supports virtual machines: VMware, Citrix, and Hyper-V

·Value-added features related to virtual environments: Support for VMware VAAI and integration of VSphere and VCenter

Key Software Features

·HyperSnap (snapshot), HyperCopy (LUN copy), HyperClone (clone), HyperMirror (volume mirror), and HyperReplication (remote replication), HyperMetro (active-active storage arrays), and HyperVault (integrated backup)

·SmartQoS (intelligent QoS control), SmartPartition (intelligent partitioning), SmartCache (intelligent SSD caching), SmartTier (intelligent storage tiering), SmartThin (intelligent thin provisioning), SmartMotion (intelligent data migration), SmartMulti-Tenant (multi-tenant), SmartMigration (LUN migration), SmartCompression (online compression), SmartDedupe (online de-duplication), SmartQuota (quota management), HyperLock (WORM), and SmartErase (data destruction)

·UltraPath (multipathing management), Cloud Service (remote maintenance and management), BCManager (disaster recovery management software), DeviceManager (manage a single device), and eSight (manage multiple cross-field devices)

Physical Specifications

Power Supply

AC: 100 V to 240 V

DC: 192 V to 288 V or €“48 V to €“60 V

Dimensions (H x W x D)

2U controller enclosure: 86.1 mm x 447 mm x

750 mm (3.39 in. x 17.60 in. x 29.53 in.)

2U disk enclosure: 86.1 mm x 447 mm x 490 mm (3.39 in. x 17.60 in. x 19.29 in.)

4U disk enclosure: 175 mm x 447 mm x 490 mm (6.89 in. x 17.60 in. x 19.29 in.)

4U high-density disk enclosure: 176.5 mm x 446 mm x 790 mm (6.95 in. x 17.56 in. x 31.10 in.)

Weight

2U controller enclosure: ‰¤ 37 kg (81.59 lb)

2U disk enclosure: ‰¤ 20 kg (44.10 lb)

4U disk enclosure: ‰¤ 40 kg (88.20 lb)

4U high-density disk enclosure: ‰¤ 91 kg (200.66 lb)

Operating Temperature

5°C to 40°C at altitudes below 1,800 m (5,905.44 ft.)

5°C to 35°C at altitudes from 1,800 m (5,905.44 ft.) to 3,000 m (9,842.40 ft.)

Operating Humidity

5% RH to 90% RH
