Name: Cisco 867 ADSL2/2+ Annex A Sec Router 802.11n FCC Comp
Brand: Cisco
SKU: CISCO867W-GN-A-K9
Price: 606.00 USD
Availability: InStock

Question 1

What is the Cisco 867W-GN-A-K9 router?

Accepted Answer

The Cisco 867W-GN-A-K9 is an integrated ADSL2/2+ Annex A security router featuring 802.11n wireless, built-in SPI firewall, and IPsec VPN for secure, high-speed broadband connectivity.

Question 2

Which ADSL standards does this Cisco router support?

Accepted Answer

It supports ADSL, ADSL2 and ADSL2+ Annex A, delivering download speeds up to 24 Mbps and upstream speeds up to 3.5 Mbps over standard phone lines.

Question 3

What wireless capabilities are included?

Accepted Answer

The router provides IEEE 802.11n Wi-Fi at 2.4 GHz with up to 150 Mbps data rates, 2×2 MIMO antennas, and WPA2-PSK encryption for robust wireless performance.

Question 4

How many Ethernet ports are available?

Accepted Answer

It includes four Gigabit LAN ports and one RJ-11 ADSL WAN port, enabling simultaneous wired device connectivity and broadband access.

Question 5

Does the Cisco 867W-GN-A-K9 support IPv6?

Accepted Answer

Yes, it offers full dual-stack IPv4/IPv6 support with DHCPv6 client, router advertisements, and static or dynamic IPv6 addressing.

Question 6

What VPN features are provided?

Accepted Answer

It delivers two IPsec VPN tunnels with DES, 3DES or AES encryption, IKE key exchange, and pre-shared key authentication for secure remote access.

Question 7

What security features are included?

Accepted Answer

Integrated security features include Stateful Packet Inspection (SPI) firewall, Network Address Translation (NAT), access control lists, and denial-of-service protection.

Question 8

Is the router FCC compliant?

Accepted Answer

Yes, the device meets FCC Part 15 Class B and Part 68 requirements, ensuring electromagnetic compatibility and telephone interface compliance in the U.S.

Question 9

How do I manage and configure the router?

Accepted Answer

You can configure via the intuitive web-based GUI, Cisco IOS CLI over SSH/Telnet, or SNMP v2c for centralized monitoring and management.

Question 10

Can I prioritize traffic with Quality of Service?

Accepted Answer

Yes, it supports QoS features such as traffic classification, weighted fair queuing, and priority queuing to optimize voice and data performance.

Question 11

Is this router suitable for small office/home office use?

Accepted Answer

Absolutely; its compact form factor, integrated DSL modem, secure VPN, and wireless performance make it ideal for SOHO environments.

Question 12

What authentication protocols are supported?

Accepted Answer

It supports PPPoE, PPPoA, IPoE, PAP, CHAP, MS-CHAP, and MS-CHAPv2 for versatile DSL ISP authentication.

Question 13

What are the power and environmental specifications?

Accepted Answer

Powered by a 12 V DC adapter (max 12 W) with operating temperatures from 0 °C to 40 °C and relative humidity up to 90% non-condensing.

Question 14

Does the router include built-in firewall protection?

Accepted Answer

Yes, the built-in SPI firewall inspects inbound and outbound packets, preventing unauthorized access and protecting against common network threats.

Question 15

What warranty and support options are available?

Accepted Answer

Cisco provides a one-year limited hardware warranty, access to online resources, and optional extended support contracts through Cisco SMARTnet.

	CISCO867W-GN-A-K9	CISCO876-SEC-K9	CISCO888W-GN-A-K9	CISCO886-K9	CISCO857-K9
5G Support	No	No	No	No	No
Architecture	Fixed	Fixed	Fixed	Fixed	Fixed
Broadband	DSL	N/A	N/A	DSL	N/A
Built-in Security Features	Firewall / Intrusion Prevention / Malware Protection	Firewall / Intrusion Prevention / Malware Protection	Firewall / Intrusion Prevention / Malware Protection	Firewall, Intrusion Prevention, Malware Protection	Firewall / Intrusion Prevention
Compliance Standards	FCC, CE	FCC / CE / RoHS	FCC / CE / RoHS	FCC, CE	FCC / CE / RoHS
Connectivity Type	Wired / Wireless / Ethernet	Wired / Wireless	Wired / Wireless / Ethernet	Wired	Wired
Depth	10.6 inches	N/A	N/A	N/A	N/A
Device Type	Router	Router	Router	Router	Router
EMC	N/A	N/A	N/A	N/A	N/A
Ethernet Technology	10/100	10/100	10/100/1000	10/100/1000	10/100
Expansion Slots	EHWIC	N/A	NIM	EHWIC	N/A
Features	VPN / VoIP / IPv6 Compatible / Firewall	VPN / Firewall / IPv6 Compatible	VPN / Firewall / POE / IPv6 Compatible	VPN, Firewall, IPv6 Compatible	VPN / Firewall
Firewall Features	Yes	Yes	Yes	Yes	Yes
Flash Memory	256 MB	128 MB	256 MB	256 MB	128 MB
Form Factor	Desktop	Desktop	Desktop	Desktop	Desktop
Height	1.4 inches	N/A	N/A	N/A	N/A
High Availability Support	Not Supported	Supported	Supported	Supported	Supported
Integrated Services	Voice	Voice / Video	Voice / Video / WAN Optimization	Voice / Video	Voice
Interface Ports	RJ-45	RJ-45 / Combo Ports	RJ-45	RJ-45	RJ-45
LAN Ports	4 LAN Ports	4 LAN Ports	4 LAN Ports	8 LAN Ports	4 LAN Ports
Management	Managed	Managed	Managed	Managed	Managed
Memory	512 MB	256 MB	512 MB	512 MB	256 MB
Modular Slots Available	N/A	N/A	1 Slot	1 Slot	N/A
Network Protocols	IPv4	IPv4 / IPv6	IPv4 / IPv6	TCP/IP, UDP, ICMP, ARP, RIP	IPv4 / IPv6 / PPP
Power	32W	17 W	65 Watt	65 Watt	N/A
Power Source	AC Power Supply	AC Power Supply	AC Power Supply	AC Power Supply / Redundant	AC Power Supply
Product Name	Cisco 867W Integrated Services Router	CISCO876-SEC-K9	Cisco 888 Wireless Branch Router	Cisco 886 Integrated Services Router	Cisco 857 Integrated Services Router
Product Type	Integrated Services Router	Router	Enterprise Router	Enterprise Router	Enterprise Router
QoS Features	Supported	Supported	Supported	Supported	Supported
Remote Management	CLI, HTTP/HTTPS, SNMP	CLI / SNMP / HTTP / HTTPS	SNMP / CLI / Web Interface	SSH, Telnet, SNMP	Telnet / SSH / SNMP / HTTP
Routing Protocols	OSPF / EIGRP / RIP / Static Routing	OSPF / EIGRP / RIP / Static Routing	OSPF / BGP / EIGRP / RIP / Static Routing	OSPF / BGP / EIGRP / RIP / Static Routing	OSPF / BGP / EIGRP / RIP / Static Routing
Safety	N/A	N/A	N/A	UL, cUL, CE, FCC	N/A
Speed/Capacity	N/A	N/A	Gigabit	Gigabit	N/A
Stacking Capability	No	No	No	No	No
Telecom	N/A	N/A	N/A	N/A	N/A
Throughput Capacity	0.012 Gbps	0.025 Gbps	0.15 Gbps	0.1 Gbps	0.035 Gbps
Use Case	Small Business	Small Business	Enterprise	Business	Enterprise
VPN Support	IPSec / SSL VPN	IPSec / SSL VPN / N/A	IPSec / SSL VPN / DMVPN / N/A	IPSec / SSL VPN	IPSec VPN / SSL VPN
WAN Configuration	WAN	WAN	Dual WAN	Dual WAN	WAN
WAN Ports	1 WAN	1 WAN	2 WAN	2 WAN	1 WAN
Weight	4.8 lbs	N/A	N/A	N/A	N/A
Wi-Fi Standard	WiFi 3	WiFi 2 / WiFi 3	WiFi 5	N/A	N/A
Width	7.1 inches	N/A	N/A	N/A	N/A
Wireless Support	Yes	Yes	Yes	No	No
