DS-2CD2423G0-IW

DS-2CD2423G0-IW Specification

Camera

Image Sensor

1/2.7€ Progressive Scan CMOS

Signal System

PAL/NTSC

Min. Illumination

Color: 0.01 Lux @ (F1.2, AGC ON), 0.028 lux @(F2.0, AGC ON), 0 lux with IR

Shutter time

1/3 s to 1/100,000 s

Slow shutter

Support

Lens

2.8 mm: horizontal FOV: 114°, vertical FOV: 62°, diagonal FOV: 135°

4 mm, horizontal FOV: 86°, vertical FOV: 46°, diagonal FOV: 102°

Lens Mount

M12

Adjustment Range

Pan: 0° to 360°, tilt: 0° to 90°, rotate: 0° to 360°

Day& Night

IR Cut Filter

Wide Dynamic Range

120 dB

Digital noise reduction

3D DNR

Focus

Fixed

Compression Standard

Video Compression

H.265+/H.265/H.264+/H.264/MJPEG

H.264 code profile

Main Profile/High Profile

Video bit rate

256Kbps~16Mbps

Audio Compression

G.711/G.722.1/G.726/MP2L2/PCM

Audio bit rate

64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-160Kbps(MP2L2)

Triple Streams

Yes


Max. Image Resolution

1920 x 1080

Frame Rate

50Hz: 25fps (1920 1080, 1280 960, 1280 720)

60Hz: 30fps (1920 1080, 1280 960, 1280 720)

Sub Stream

50Hz: 25fps (640 480, 640 360, 320 240)

60Hz: 30fps (640 480, 640 360, 320 240)

Third Stream

50Hz: 25fps (1920 1080, 1280 720, 640 360, 352 288)

60Hz: 30fps (1920 1080, 1280 720, 640 360, 352 240)

Image Enhancement

BLC/3D DNR/ROI/HLC

Image Settings

Rotate mode, saturation, brightness, contrast, sharpness and white balance adjustable by client software or web browser

ROI

Support 1 fixed region for main stream and sub-stream separately

Day/Night Switch

Day/Night/Auto/Schedule

Network

Network Storage

microSD/SDHC/SDXC card (128G), local storage and NAS (NFS,SMB/CIFS), ANR

Alarm Trigger

Motion detection, video tampering alarm, network disconnected, IP address conflict, illegal login, HDD full, HDD error

Protocols

TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP„¢, SMTP, SNMP, IGMP, QoS, IPv6

General Function

One-key reset, Anti-Flicker, heartbeat, mirror, password protection, privacy mask, Watermark, IP address filtering

System Compatibility

ONVIF (Profile S, Profile G), ISAPI

Interface

Audio

1 built-in mic, 1 built-in speaker, mono sound

Communication Interface

1 RJ45 10M / 100M Ethernet interface

On-board storage

Built-in Micro SD/SDHC/SDXC slot, up to 128 GB

Reset Button

Yes

Audio

Environment Noise Filtering

Support

Audio Sampling Rate

8 kHz/16 kHz/32 kHz/44.1 kHZ/48 kHz

Smart Feature-set

Behavior Analysis

Line crossing detection, intrusion detection

Line Crossing Detection

Cross a pre-defined virtual line

Intrusion Detection

Enter and loiter in a pre-defined virtual region

Recognition

Face Detection

Wi-Fi Specification (-W)

Wireless Standards

IEEE802.11b, 802.11g, 802.11n

Frequency Range

2.412 GHz to 2.4835 GHz

Channel Bandwidth

20/40MHz Support

Security

WPA, WPA2

Transmission Rate

11b: 11Mbps

11g: 54Mbps

11n: up to 150Mbps

Wireless Range

50m(depend on environment)

Protocols

802.11b: DQPSK, DBPSK, CCK

802.11g/n: OFDM/64-QAM, 16-QAM, QPSK, BPSK

General

Operating Conditions

-10 °C €“ 40°C (14 °F €“ 104 °F), Humidity 95% or less (non-condensing)

Power Supply

12 VDC ± 25%, PoE (802.3af Class3)

Power Consumption

12 VDC, 0.5A, max. 6W, Φ 5.5 mm coaxial plug power

PoE (802.3af, 36V to 57V), 0.2 A to 0.1 A, max. 7W

IR Range

Up to 10m

PIR

10m

Dimensions

102.8 mm 65.2 mm 32.6 mm (4.1" 2.6" 1.3")
