Compact thermal solution for focused monitoring.
DS-2TD2166T-15
Thermographic Network Bullet Camera
Shipping to
United States
United States United StatesName:
Added to cart 28 times recently
In stock - Ready to Ship
3 Year Extended Warranty
Same-day Shipping
14-Day Money Back Guarantee
Shipping:
Payment:
3 Year Extended Warranty
Same-day Shipping
14-Day Money Back Guarantee
Need Additional Discount on Product?
Request a quote below - Get Exclusive Pricing and Support.
Shipping:
Payment:
DS-2TD2166T-15
Thermographic Network Bullet Camera
TRUSTED, TRIED, PROVEN
Inventory Delivered By
& Verified By
Solutions Powered By
DS-2TD2166T-15 is an IP bullet camera engineered for robust surveillance, featuring a 2MP resolution thermal sensor paired with a fixed lens. It delivers H.265 video compression, supports IR night vision up to a 20m range, and provides essential connectivity through PoE for reliable power and data transmission in outdoor environments.
Optimized for indoor retail, perimeter defense, license plate recognition, and warehouse surveillance, this camera is ONVIF compliant and offers flexible storage options including MicroSD card, NVR, and cloud support. Its weather-resistant design with an IP67 rating ensures dependable performance under challenging conditions.
DS-2TD2166T-15 price is is available on request. Get immediate quote.
Request bulk order quote for DS-2TD2166T-15 for additional pricing. Browse the full Hikvision Thermography Thermal Cameras series or explore all Hikvision products.
To get the detailed certification, please go to the Compliance Center.
 DS-2TD2166T-15 |  DS-2TD4166T-25 |  DS-2TD2637B-10/P |  DS-2TD2636B-15/P |  DS-2TD2466T-25X | |
|---|---|---|---|---|---|
| Product Type | Security Camera | Security Camera | Security Camera | Security Camera | Security Camera |
| Camera Type | Bullet | Bullet | Bullet | Bullet | Bullet |
| Technology | IP Camera | IP Camera | IP Camera | IP Camera | IP Camera |
| Resolution | 2MP | 2MP | 2MP | 2MP | 4MP |
| Lens Type | Fixed | Fixed | Fixed | Fixed | Fixed |
| Smart Features | Motion Detection | N/A | Motion Detection | ANPR | Motion Detection |
| Mounting Type | Wall | Wall | Wall | Wall | Wall |
| Color | Black | Black | Black | Black | Black |
| Use Case | Retail | Perimeter Protection | Perimeter Protection | Indoor / Retail / Perimeter Protection / Warehouse | Perimeter Protection |
| Focal Length | 2.8mm | 4mm | 4mm | 6mm | 4mm |
| Image Sensor | Thermal | Thermal | Thermal | Thermal | 1/2.8" CMOS |
| Frame Rate | 30 FPS | 30 FPS | 30 FPS | 30 FPS | 30 FPS |
| Infrared Night Vision | 20m | 30m | 50m | N/A | 30m |
| Low Light Technology | IR | N/A | N/A | N/A | EXIR |
| Day/Night Mode | True Day/Night (ICR) | N/A | True Day/Night (ICR) | N/A | True Day/Night (ICR) |
| Video Compression | H.265 | H.265+ | H.265 | H.265+ | H.265 |
| Audio Support | No Audio | No Audio | No Audio | No Audio | Built-in Mic |
| Storage Option | MicroSD Slot | MicroSD Slot | MicroSD Slot | MicroSD Slot | MicroSD Slot |
| Max Storage Capacity | 64 GB | 128 GB | 128 GB | 128 GB | 128 GB |
| Power Type | PoE | PoE | PoE | PoE | PoE |
| Weather Rating | IP67 | IP67 | IP67 | IP66 | IP67 |
| Vandal Resistance | None | N/A | N/A | N/A | N/A |
| ONVIF Compliant | Yes | Yes | Yes | Yes | Yes |
| Product Name | DS-2TD2166T-15 Thermal Bullet Network Camera | DS-2TD4166T-25 Thermal Bullet Camera | DS-2TD2637B-10/P | Hikvision DS-2TD2636B-15/P Thermal Bullet Network Camera | DS-2TD2466T-25X |
| Height | 4.5 inches | 4.7 inches | 4 inches | 4.3 inches | 4.5 inches |
| Width | 3.2 inches | 3.9 inches | 3 inches | 3.1 inches | 2.5 inches |
| Depth | 3.2 inches | 3.9 inches | 2 inches | 2.2 inches | 2.7 inches |
| Weight | 3.5 lbs | 2.3 lbs | 2.5 lbs | 3.5 lbs | 2.0 lbs |
Compact thermal solution for focused monitoring.
Reliable thermal detection in controlled areas.
Clear imaging with stable operation.
Works well for smaller perimeter zones.
Consistent performance with minimal maintenance.
The DS-2TD2166T-15 delivers a 160×120 thermal sensor with NETD ≤50 mK @25 °C, ensuring crisp thermal imaging and stable temperature detection.
It supports a radiometric range from –40 °C to 550 °C with an accuracy of ±2 °C or ±2% (whichever is greater), ideal for early fire detection and industrial monitoring.
With its 15 mm thermal lens, the camera can detect a human (1.8 × 0.5 m) at up to 1,800 m and recognize features at 700 m, enabling reliable perimeter security.
It supports up to 1080p (1920×1080) at 25/30 fps and multi-stream output in H.265+, H.265, H.264+, H.264 and MJPEG for efficient bandwidth use.
