What connector type is used by the DWDM-XFP10G-1548-51?

The module uses a duplex LC connector for low-loss fiber coupling and compact port density.

Is the DWDM-XFP10G-1548-51 hot-swappable?

Yes, the XFP form-factor design allows hot-plug insertion and removal without powering down the host system.

What is the power consumption of this XFP DWDM transceiver?

It operates under 4.5 W total power consumption, adhering to the XFP MSA power envelope.

What operating temperature range does the module support?

It supports a commercial operating range of 0 °C to 70 °C ambient temperature for standard deployment environments.

Does the transceiver include digital diagnostics monitoring (DDM)?

Yes, it offers real-time DDM for optical output power, input power, temperature, laser bias current, and supply voltage.

How do I install the DWDM-XFP10G-1548-51 in my network device?

Align the module with the XFP slot, insert until it latches, and verify link status via the host interface; no additional tools or configuration changes are required.

Is the DWDM-XFP10G-1548-51 RoHS and Telcordia compliant?

Yes, it meets RoHS 6/6 for hazardous substances and Telcordia GR-468 environmental and reliability standards.

What applications is this DWDM transceiver best suited for?

It is ideal for metro, regional, and long-haul DWDM links, data center interconnects, and carrier aggregation networks.

How can I ensure compatibility with my existing DWDM system?

Verify that your host supports XFP MSA modules, matches the 1548.51 nm channel, and uses 50 GHz ITU grid spacing on single-mode fiber.

What channel spacing does the DWDM-XFP10G-1548-51 follow?

It follows the ITU-T G.694.1 50 GHz channel spacing grid, specifically Channel 51 at 1548.51 nm.

What maintenance is required for the transceiver?

Routine fiber-endface cleaning and periodic DDM checks are recommended; no internal calibration or field repairs are necessary.

Can the module operate over dispersion-uncompensated fiber?

Yes, for distances up to 80 km it tolerates standard G.652 dispersion, but extended distances may require dispersion compensation modules.

FEATURED DEAL

Name:

DWDM-XFP10G-1548-51

Name: DWDM Optical Transceiver,XFP,10G,Single-mode Module(1548.51nm,80km,LC)
Brand: Huawei
SKU: DWDM-XFP10G-1548-51
Price: 2338.42 USD
Availability: InStock
Rating: 4.3 (6 reviews)

Description:: DWDM Optical Transceiver,XFP,10G,Single-mode Module(1548.51nm,80km,LC)
Rating:: 4.3(6)
Added to cart 28 times recently
Availability:: In stock - Ready to Ship
Brand:: Huawei
GTIN:: 6920702795667
Condition:
Warranty:: 3
List Price:: $5,314.60
Price:: $2,338.4256% off

Quantity:

Business price:

Enroll your business for free

3 Year Extended Warranty

Same-day Shipping

14-Day Money Back Guarantee

Shipping:

Payment:

dwdm-xfp10g-1548-51 dwdm optical transceiver,xfp,10g,single-mode module(1548.51nm,80km,lc)

3 Year Extended Warranty

Same-day Shipping

14-Day Money Back Guarantee

Need Additional Discount on Product?

Request a quote below - Get Exclusive Pricing and Support.

Shipping:

Payment:

DWDM-XFP10G-1548-51

DWDM Optical Transceiver,XFP,10G,Single-mode Module(1548.51n...

$5,314.60 $2,338.4256% off

11 in Global Warehouse Global

TRUSTED, TRIED, PROVEN

$5,000,000+

Inventory Delivered By

Officially Accredited

& Verified By

Next-Gen IT

Solutions Powered By

DWDM-XFP10G-1548-51 Overview

DWDM-XFP10G-1548-51 is a DWDM transceiver that conforms to the XFP standard, delivering a 10G data rate with LC connector interfaces. It is designed to support long-range transmission and operates over single-mode fiber, making it ideal for dense wavelength division multiplexing applications with Ethernet and Fibre Channel protocols.

DWDM-XFP10G-1548-51 features a compact form factor with precise physical dimensions that allow efficient integration into data centers, enterprise networks, and telecom infrastructures. Its engineered performance and reliable compatibility with leading networking vendors underscore its suitability for high-speed, long-distance communications.

DWDM-XFP10G-1548-51 price is $2,338.42, a 56% saving from the Huawei list price of $5,314.60. DWDM-XFP10G-1548-51 is in stock and available for next-day dispatch. (terms applied)

Request bulk order quote for DWDM-XFP10G-1548-51 for additional pricing. Browse the full Huawei Transceivers series or explore all Huawei products.

DWDM-XFP10G-1548-51 Specifications

Product Type: Transceiver
Form Factor: XFP
Data Rate: 10G
Connector Type: LC
Wavelength: 1548nm
Transmission Distance: Long-Range
Fiber Type: Single-mode
Max Distance: 80 km
Supported Protocols: Ethernet, Fibre Channel
Network Interface: Fiber
Power Consumption: 3.5W
Operating Temperature: 0 to 70°C
Storage Temperature: -40 to 85°C
Input Voltage: 3.3V
Compatibility: Cisco, Juniper, Huawei, Arista
Product Name: DWDM-XFP10G-1548-51
Height: 0.50 inches
Width: 2.20 inches
Depth: 1.50 inches
Weight: 0.20 lbs

Quality Certifications

To get the detailed certification, please go to the Compliance Center.

Product Comparison Table

	DWDM-XFP10G-1548-51	QSFP-40G-iSM4	OGSC10DD0	SS-OP-D-LC-M-1	OSX070005
Product Type	Transceiver	Transceiver	Transceiver	Transceiver	Transceiver
Form Factor	XFP	QSFP	SFP+	SFP+	SFP+
Data Rate	10G	40G	10G	10G	10G
Connector Type	LC	LC	LC	LC	LC
Wavelength	1548nm	850 nm	1310 nm	850 nm	850 nm
Transmission Distance	Long-Range	Short-Range	Long-Range	Short-Range	Short-Range
Fiber Type	Single-mode	Multi-mode	Single-mode	Multi-mode	Multi-mode
Max Distance	80 km	150 m	10 km	300 meters	300 meters
Supported Protocols	Ethernet, Fibre Channel	Ethernet	Ethernet	Ethernet, Fibre Channel	Ethernet
Network Interface	Fiber	Ethernet	Ethernet	Fiber	Ethernet
Power Consumption	3.5W	N/A	3.5W	2.5W	3.5W
Operating Temperature	0 to 70°C	0 to 70°C	0 to 70°C	0 to 70°C	0 to 70°C
Storage Temperature	-40 to 85°C	-40 to 85°C	-40 to 85°C	-40 to 85°C	-40 to 85°C
Input Voltage	3.3V	3.3V	3.3V	3.3V	3.3V
Compatibility	Cisco, Juniper, Huawei, Arista	Cisco / Juniper / Huawei / Arista	Cisco / Juniper / Huawei / Arista	Cisco, Juniper, Huawei, Arista	Cisco / Juniper / Huawei / Arista
Product Name	DWDM-XFP10G-1548-51	QSFP-40G-iSM4	OGSC10DD0 10Gbps Long-Range SFP+ Optical Transceiver	SS-OP-D-LC-M-1 Optical Transceiver	OSX070005 10G SFP+ Transceiver
Height	0.50 inches	N/A	0.3 inches	0.25 inches	0.8 inches
Width	2.20 inches	N/A	0.55 inches	0.60 inches	1.0 inches
Depth	1.50 inches	N/A	1.2 inches	0.30 inches	1.5 inches
Weight	0.20 lbs	N/A	0.2 lbs	0.05 lbs	0.06 lbs

Reviews & Ratings

Matthew Harding

Reliable DWDM XFP delivering stable 10G links.

Daniel Cooper

Accurate wavelength with clean output.

James Wilcox

Easy deployment in DWDM networks.

Paul Edwards

Consistent performance under load.

Christopher Lane

No signal drift detected.

Oliver Bennett

Dependable DWDM XFP module.

Questions & Answers

What is the DWDM-XFP10G-1548-51 optical transceiver?

The DWDM-XFP10G-1548-51 is an XFP MSA–compliant 10 Gb/s dense wavelength division multiplexing (DWDM) transceiver for single-mode fiber at 1548.51 nm supporting up to 80 km reach with an LC duplex interface.

Which network protocols does the DWDM-XFP10G-1548-51 support?

It supports 10 Gb/s Ethernet (10GBASE-ER), 10 Gb FC, 10 Gb/s SONET/SDH, and OTN protocols over single-mode fiber.

What is the maximum transmission distance of this transceiver?

With a DWDM link budget designed for single-mode fiber, it reliably transmits up to 80 km under standard ITU-T G.652 conditions.

At which ITU wavelength does the module operate?

It operates precisely at the ITU grid wavelength of 1548.51 nm (Channel 51) with 50 GHz channel spacing.
