Name: Huawei NE20E-X 6 Chassis 2*MPUE 2*DC Power without Software Charge and Document (CR2P06BASD11)
Brand: Huawei
SKU: Huawei NE20E-X6 with 2*MPUE, 2*DC Power (CR2P06BASD11)
Availability: OutOfStock
Rating: 4.3 (6 reviews)

Question 1

What is the Huawei NE20E-X6 chassis (CR2P06BASD11)?

Accepted Answer

The Huawei NE20E-X6 chassis (CR2P06BASD11) is a 6-slot service routing aggregation platform with two Modular Packet-Processing Unit Engines (MPUE) and two DC power modules, delivered without preloaded software or documentation.

Question 2

Which power supply modules are included?

Accepted Answer

This SKU includes two Huawei DC power modules rated at –48V, providing redundant power for high availability in carrier and enterprise network environments.

Question 3

What is an MPUE and how many are supported?

Accepted Answer

An MPUE (Modular Packet-Processing Unit Engine) accelerates packet forwarding and routing; the NE20E-X6 supports up to two MPUEs for scalable performance.

Question 4

What forwarding performance does the NE20E-X6 deliver?

Accepted Answer

With two MPUEs installed, the NE20E-X6 delivers high-performance forwarding of up to 160 Gbit/s per interface slot, supporting large-scale data aggregation and backbone routing.

Question 5

Which interface line cards are compatible?

Accepted Answer

The NE20E-X6 chassis supports a range of Huawei line cards including 1/2.5/10GE, 25GE, 40GE, and 100GE interfaces for flexible deployment in diverse network scenarios.

Question 6

Is software licensing included?

Accepted Answer

No. This product is sold without software licenses; you must purchase Huawei’s Versatile Routing Platform (VRP) or feature licenses separately to enable routing and service functions.

Question 7

How do I install the Huawei NE20E-X6 in a rack?

Accepted Answer

Mount the 19-inch NE20E-X6 chassis using the supplied rack-mount ears, secure all screws, connect DC input cables to –48V busbars, and install line cards and MPUEs per the installation guide.

Question 8

What management interfaces are available?

Accepted Answer

The NE20E-X6 offers out-of-band management via a console port, an RJ45 Ethernet management port, and supports VRP CLI, Telnet, SSH, SNMP, and eSight network management integration.

Question 9

What environmental conditions does it support?

Accepted Answer

Operating temperature ranges from 0°C to 45°C, storage temperature from –40°C to 70°C, relative humidity 5%–95% (non-condensing), ensuring reliability in varied data-center environments.

Question 10

How is cooling handled in the chassis?

Accepted Answer

The NE20E-X6 uses hot-swappable front-to-back fans with intelligent thermal detection to maintain optimal operating temperatures under full load.

Question 11

What safety and compliance standards does it meet?

Accepted Answer

This chassis complies with CE, FCC, RoHS, and UL safety standards, ensuring electromagnetic compatibility and environmentally responsible design.

Question 12

What is the mean time between failures (MTBF)?

Accepted Answer

Huawei publishes an MTBF of over 200,000 hours for the NE20E-X6 chassis, reflecting its carrier-grade reliability for core network deployments.

Question 13

Which use cases is the NE20E-X6 designed for?

Accepted Answer

The NE20E-X6 is ideal for ISP edge aggregation, enterprise WAN gateways, carrier metro networks, and data-center interconnects requiring high density and scalability.

Question 14

What are the physical dimensions and weight?

Accepted Answer

The NE20E-X6 chassis measures 446 mm (W) x 700 mm (D) x 88.1 mm (H) and weighs approximately 18 kg empty, facilitating standard 1U rack installation.

Question 15

What is the typical power consumption?

Accepted Answer

With two MPUEs and two DC power modules installed, the typical power consumption is around 450W, depending on line-card configuration and traffic load.

Question 16

What warranty and support options are available?

Accepted Answer

Huawei offers a one-year limited hardware warranty for the NE20E-X6 chassis, with optional extended service packages including 24×7 on-site support and accelerated replacement.

	Huawei NE20E-X6 with 2MPUE, 2DC Power (CR2P06BASD11)	Huawei NE20E-X6 with 1MPUE, 2AC Power (CR2P06BASA10)	Huawei NE20E-X6 with 1MPUE, 2DC Power (CR2P06BASD10)	Huawei NE20E-X6 with 2MPUE, 2AC Power (CR2P06BASA11)
5G Support	No	No	No	No
Architecture	Modular Chassis	Modular	Modular	Modular
Broadband	N/A	N/A	N/A	N/A
Built-in Security Features	Firewall / Intrusion Prevention	Firewall / Intrusion Prevention	Firewall, Intrusion Prevention, Malware Protection	Firewall, Intrusion Prevention, Malware Protection
Compliance Standards	N/A	CE / FCC	CE, FCC, RoHS	CE, FCC
Connectivity Type	Wired	Wired	Wired	Wired
Depth	N/A	N/A	N/A	N/A
Device Type	Router	Router	Router	Router
EMC	N/A	N/A	N/A	N/A
Ethernet Technology	10/100/1000	10/100/1000	10/100/1000	10/100/1000
Expansion Slots	MPUE Slots (2 x)	NIM / SM-X	NIM, SFP+	SFP
Features	VPN, Redundancy, Modular Design, High Performance	VPN / Firewall / Redundancy	VPN, IPv6 Compatible, Firewall, MPLS, QoS	VPN, Firewall, IPv6 Compatible
Firewall Features	Yes	Yes	Yes	Yes
Flash Memory	N/A	512 MB	512 MB	N/A
Form Factor	Chassis	Rack-mount	Chassis	Rack-mount / Chassis
Height	N/A	N/A	N/A	N/A
High Availability Support	Supported	Supported	Supported	Supported
Integrated Services	Data / Voice / Video	Voice / Video	Voice, Video, WAN Optimization	VoIP, WAN Optimization
Interface Ports	SFP / RJ-45	RJ-45 / SFP	RJ-45, SFP+	RJ-45, SFP
LAN Ports	N/A	Modular LAN	Modular LAN	Modular LAN
Management	Managed	Managed	Managed	Managed
Memory	N/A	4 GB	4 GB	N/A
Modular Slots Available	2 Slots	3+ Slots	3+ Slots	N/A
Network Protocols	IPv4 / IPv6	IPv4 / IPv6	IPv4, IPv6, MPLS	IPv4 / IPv6
Power	CR2P06BASD11	N/A	400W	N/A
Power Source	2 x DC Power Supply (CR2P06BASD11, Redundant)	2*AC Power Supply (CR2P06BASA10)	DC Power Supply / Redundant	AC Power Supply / Redundant
Product Name	Huawei NE20E-X6 with 2MPUE, 2DC Power (CR2P06BASD11)	Huawei NE20E-X6 with 1MPUE, 2AC Power (CR2P06BASA10)	Huawei NE20E-X6 with 1MPUE, 2DC Power (CR2P06BASD10)	Huawei NE20E-X6 with 2MPUE, 2AC Power (CR2P06BASA11)
Product Type	Carrier Ethernet Router	Enterprise Router	Enterprise Router	Enterprise Router
QoS Features	Supported	Supported	Supported	Supported
Remote Management	Telnet / SSH / SNMP	SNMP / CLI / WEB	SSH, Telnet, SNMP, HTTPS	SSH, Telnet, SNMP, HTTPS
Routing Protocols	OSPF / BGP / RIP / Static Routing	OSPF / BGP / RIP / Static Routing	OSPF / BGP / MPLS / Static Routing	OSPF / BGP / RIP / Static Routing
Safety	N/A	N/A	N/A	N/A
Speed/Capacity	Gigabit Ethernet	Gigabit	10GbE	Gigabit
Stacking Capability	Yes	Yes	Yes	No
Telecom	N/A	N/A	N/A	N/A
Throughput Capacity	N/A	80 Gbps	80 Gbps	N/A
Use Case	Enterprise / Carrier	Enterprise	Enterprise	Enterprise
VPN Support	IPSec / GRE	IPSec VPN	IPSec / SSL VPN / GRE	IPSec
WAN Configuration	Multiple WAN Ports	Dual WAN	Dual WAN	Dual WAN
WAN Ports	8 x SFP Ports	Modular WAN	Modular WAN	Modular WAN
Weight	N/A	N/A	N/A	N/A
Wi-Fi Standard	N/A	N/A	N/A	N/A
Width	N/A	N/A	N/A	N/A
Wireless Support	No	No	No	No

Huawei NE20E-X6 with 2MPUE, 2DC Power (CR2P06BASD11)

$5,000,000+
