What are the transmit and receive wavelengths of the OSX010B11?

The transceiver transmits at 1330 nm and receives at 1270 nm on a single fiber.

What connector type does the OSX010B11 use?

It uses a standard LC duplex connector for single-fiber bidirectional links.

What is the optical transmit power range?

The optical output power ranges from –8.2 dBm (min) to 0.5 dBm (max).

What is the receiver sensitivity of this module?

The receiver sensitivity is –14.4 dBm, ensuring reliable signal detection at 10 km.

Is the OSX010B11 hot-pluggable?

Yes. It adheres to the SFP+ MSA for hot-swappable installation and removal.

Does this transceiver support digital diagnostics monitoring (DDM)?

Yes. It provides real-time DDM functions including optical power, temperature, and voltage.

Which industry standards does the OSX010B11 comply with?

It meets SFF-8431, SFF-8432, IEEE 802.3ae and RoHS for environmental safety.

What is the operating temperature range?

The module operates reliably from 0 °C to 70 °C (commercial range).

What is the typical power consumption?

The transceiver consumes less than 1 W of power during normal operation.

Which applications is the OSX010B11 ideal for?

It is ideal for 10G Ethernet, SAN, P2P, metro and access network deployments.

How do I install the OSX010B11 in my network device?

Remove dust caps, insert the module into an SFP+ slot until the latch clicks, then connect the LC fiber.

Is the OSX010B11 compatible with major switch and router vendors?

Yes. It is interoperable with Cisco, Juniper, Arista, HP and other SFP+-compliant devices.

What warranty and support options are available?

The module includes a one-year warranty and lifetime technical support for all customers.

FEATURED DEAL

Name:

OSX010B11

Name: BiDi Transceiver,SFP+,1330nm(Tx)/1270nm(Rx),2.5~11.3Gb/s,-8.2dBm,0.5dBm,-14.4dBm,LC,SM,10km
Brand: Huawei
SKU: OSX010B11
Rating: 4.3 (6 reviews)

Description:: BiDi Transceiver,SFP+,1330nm(Tx)/1270nm(Rx),2.5~11.3Gb/s,-8.2dBm,0.5dBm,-14.4dBm,LC,SM,10km
Rating:: 4.3(6)
Added to cart 28 times recently
Availability:: In stock - Ready to Ship
Brand:: Huawei
GTIN:: 886598026543
Condition:

Get a Quote

3 Year Extended Warranty

Same-day Shipping

14-Day Money Back Guarantee

Shipping:

Payment:

osx010b11 bidi transceiver,sfp+,1330nm(tx)/1270nm(rx),2.5~11.3gb/s,-8.2dbm,0.5dbm,-14.4dbm,lc,sm,10km

3 Year Extended Warranty

Same-day Shipping

14-Day Money Back Guarantee

Need Additional Discount on Product?

Request a quote below - Get Exclusive Pricing and Support.

Shipping:

Payment:

OSX010B11

BiDi Transceiver,SFP+,1330nm(Tx)/1270nm(Rx),2.5~11.3Gb/s,-8....

TRUSTED, TRIED, PROVEN

$5,000,000+

Inventory Delivered By

Officially Accredited

& Verified By

Next-Gen IT

Solutions Powered By

OSX010B11 Overview

OSX010B11 is a SFP+ transceiver module engineered for high-speed 10G data transmission over Ethernet networks. It features an LC connector and is optimized for short-range applications, making it ideal for data centers, enterprise networks, and telecom environments.

OSX010B11 offers a compact form factor with precise physical dimensions that facilitate high-density port configurations. It supports protocols such as Ethernet and Fibre Channel, ensuring reliable performance while meeting the demands of modern network infrastructures.

OSX010B11 price is is available on request. Get immediate quote.

Request bulk order quote for OSX010B11 for additional pricing. Browse the full Huawei Transceivers series or explore all Huawei products.

OSX010B11 Specifications

Product Type: Transceiver
Form Factor: SFP+
Data Rate: 10G
Connector Type: LC
Wavelength: 850nm
Transmission Distance: Short-Range
Fiber Type: Multi-mode
Max Distance: 300 meters
Supported Protocols: Ethernet, Fibre Channel
Network Interface: Ethernet
Power Consumption: 3.5W
Operating Temperature: 0 to 70°C
Storage Temperature: -40 to 85°C
Input Voltage: 3.3V
Compatibility: Cisco, Juniper, Huawei, Arista
Product Name: OSX010B11 10G SFP+ Transceiver Module
Height: 0.33 inches
Width: 0.88 inches
Depth: 1.38 inches
Weight: 0.1 lbs

Quality Certifications

To get the detailed certification, please go to the Compliance Center.

Product Comparison Table

	OSX010B11	DWDM-SFPGE-1540-56	DWDM-SFPGE-1553-33	SFP-FC8G-LW	SFP-FC8G-SW
Product Type	Transceiver	Transceiver	Transceiver	Transceiver	Transceiver
Form Factor	SFP+	SFP	SFP	SFP	SFP
Data Rate	10G	1G	1G	8G	8G
Connector Type	LC	LC	LC	LC	LC
Wavelength	850nm	1540 nm	1553 nm	1310 nm	850 nm
Transmission Distance	Short-Range	Long-Range	Long-Range	Long-Range	Short-Range
Fiber Type	Multi-mode	Single-mode	Single-mode	Single-mode	Multi-mode
Max Distance	300 meters	N/A	80 km	10 km	300 meters
Supported Protocols	Ethernet, Fibre Channel	Ethernet	Ethernet	Fibre Channel	Fibre Channel
Network Interface	Ethernet	Fiber	Fiber	Fiber	Fiber
Power Consumption	3.5W	N/A	N/A	2.0W	2.5W
Operating Temperature	0 to 70°C	0 to 70°C	0 to 70°C	0 to 70°C	0 to 70°C
Storage Temperature	-40 to 85°C	-40 to 85°C	-40 to 85°C	-40 to 85°C	-40 to 85°C
Input Voltage	3.3V	3.3V	3.3V	3.3V	3.3V
Compatibility	Cisco, Juniper, Huawei, Arista	Cisco / Juniper / Huawei / Arista	Cisco / Juniper / Huawei / Arista	Cisco	Cisco, Juniper, Huawei, Arista
Product Name	OSX010B11 10G SFP+ Transceiver Module	DWDM-SFPGE-1540-56	DWDM-SFPGE-1553-33	SFP-FC8G-LW	SFP-FC8G-SW
Height	0.33 inches	N/A	0.22 inches	N/A	N/A
Width	0.88 inches	N/A	2.0 inches	N/A	N/A
Depth	1.38 inches	N/A	0.65 inches	N/A	N/A
Weight	0.1 lbs	N/A	0.2 lbs	N/A	N/A

Reviews & Ratings

Liam Patterson

BiDi SFP plus delivers stable 10km links.

Faraz Khan

Good optical balance and reliability.

Jon Keller

No issues in production.

Marcus Hill

Quick plug and play setup.

Zubair Shah

Works smoothly with Huawei switches.

Oliver Drake

Solid BiDi SFP plus.

Questions & Answers

What is the OSX010B11 BiDi SFP+ Transceiver designed for?

The OSX010B11 is a bidirectional SFP+ transceiver that enables single-fiber 10 km links at data rates from 2.5 to 11.3 Gb/s.

Which fiber type does the OSX010B11 support?

It supports single-mode fiber (SMF) with a 9/125 µm core.

What maximum link distance can the OSX010B11 achieve?

It supports link lengths of up to 10 km over single-mode fiber.

Which data rates are compatible with this transceiver?

The module operates over a data rate range of 2.5 to 11.3 Gb/s, including 10 GbE.
