Which fiber type and connector does it require?

This transceiver requires single-mode fiber (OS1/OS2) and uses a duplex LC connector for transmit and receive.

What is the transmitter optical power range?

The transmitter output power ranges from –8.2 dBm (minimum) to 0.5 dBm (maximum), ensuring reliable 10 km links.

What is the receiver sensitivity of this module?

Receiver sensitivity is specified at –14.4 dBm, meeting 10GBASE-LR sensitivity requirements.

Is the SFP+10GE-LH10-SM1310 hot-swappable?

Yes. It supports hot-plug insertion and removal without powering down the host device.

Does it support Digital Diagnostic Monitoring (DDM)?

Yes. It complies with SFF-8472, offering real-time monitoring of optical power, temperature, voltage, and laser bias.

What power supply does this module require?

It is powered by a single 3.3 V DC rail per SFP+ MSA and typically consumes less than 1 W during operation.

Which standards and certifications does it meet?

The transceiver meets IEEE 802.3ae 10GBASE-LR, SFF-8431, SFF-8432, RoHS-6, and Telcordia GR-468-CORE requirements.

What environments is the SFP+10GE-LH10-SM1310 designed for?

It is built for data centers, enterprise switches, routers, and metro-access networks requiring 10 Gb/s links up to 10 km.

How do I install the SFP+10GE-LH10-SM1310 in my switch or router?

Align the module with the SFP+ cage, slide it in until the latch clicks, then connect duplex LC fiber patch cords.

Is the transceiver compatible with major switch and router brands?

Yes. It’s interoperable with all SFP+-compliant equipment from Cisco, Juniper, Arista, Huawei, Dell, HPE and others.

What applications is the SFP+10GE-LH10-SM1310 best suited for?

Ideal for 10 GbE LAN, SAN, metro-access, and high-speed backbone links requiring long-reach single-mode connectivity.

FEATURED DEAL

Name:

SFP+10GE-LH10-SM1310

Name: Optical transceiver,SFP+,1310nm,10.3125Gb/s,-8.2~0.5dBm,-14.4dBm,LC,SM,10km
Brand: Huawei
SKU: SFP+10GE-LH10-SM1310
Price: 815.64 USD
Availability: InStock
Rating: 4.3 (6 reviews)

Description:: Optical transceiver,SFP+,1310nm,10.3125Gb/s,-8.2~0.5dBm,-14.4dBm,LC,SM,10km
Rating:: 4.3(6)
Added to cart 28 times recently
Availability:: In stock - Ready to Ship
Brand:: Huawei
GTIN:: 886598026543
Condition:
Warranty:: 3
List Price:: $1,896.84
Price:: $815.6457% off

Quantity:

Business price:

Enroll your business for free

3 Year Extended Warranty

Same-day Shipping

14-Day Money Back Guarantee

Shipping:

Payment:

sfp+10ge-lh10-sm1310 optical transceiver,sfp+,1310nm,10.3125gb/s,-8.2~0.5dbm,-14.4dbm,lc,sm,10km

3 Year Extended Warranty

Same-day Shipping

14-Day Money Back Guarantee

Need Additional Discount on Product?

Request a quote below - Get Exclusive Pricing and Support.

Shipping:

Payment:

SFP+10GE-LH10-SM1310

Optical transceiver,SFP+,1310nm,10.3125Gb/s,-8.2~0.5dBm,-14....

$1,896.84 $815.6457% off

11 in Global Warehouse Global

TRUSTED, TRIED, PROVEN

$5,000,000+

Inventory Delivered By

Officially Accredited

& Verified By

Next-Gen IT

Solutions Powered By

SFP+10GE-LH10-SM1310 Overview

SFP+10GE-LH10-SM1310 is a high-performance SFP+ transceiver designed for 10G Ethernet applications over single-mode fiber. It features an LC connector and utilizes a 1310 nm wavelength laser, delivering long-range transmission capabilities with a maximum distance of up to 10 km. This compact module is ideal for data center interconnects, enterprise network uplinks, and telecom environments that demand reliable, long-haul connectivity.

Engineered to meet rigorous industry standards, the SFP+10GE-LH10-SM1310 module combines a small form factor with efficient operation for fiber-based Ethernet links. Its design ensures compatibility with a wide range of network equipment, making it a robust choice for high-speed data transmission in diverse, mission-critical network infrastructures.

SFP+10GE-LH10-SM1310 price is $815.64, a 57% saving from the Huawei list price of $1,896.84. SFP+10GE-LH10-SM1310 is in stock and available for next-day dispatch. (terms applied)

Request bulk order quote for SFP+10GE-LH10-SM1310 for additional pricing. Browse the full Huawei Transceivers series or explore all Huawei products.

SFP+10GE-LH10-SM1310 Specifications

Product Type: Transceiver
Form Factor: SFP+
Data Rate: 10G
Connector Type: LC
Wavelength: 1310 nm
Transmission Distance: Long-Range
Fiber Type: Single-mode
Max Distance: 10 km
Supported Protocols: Ethernet
Network Interface: Fiber
Power Consumption: N/A
Operating Temperature: 0 to 70°C
Storage Temperature: -40 to 85°C
Input Voltage: 3.3V
Compatibility: Cisco / Juniper / Huawei / Arista
Product Name: SFP+10GE-LH10-SM1310
Height: N/A
Width: N/A
Depth: N/A
Weight: N/A

Quality Certifications

To get the detailed certification, please go to the Compliance Center.

Product Comparison Table

	SFP+10GE-LH10-SM1310	OSX080N06	QSFP28-50G-BIDI-10km-SM-1	DWDM-SFPGE-1546-92	FCXPD0200
Product Type	Transceiver	Transceiver	Transceiver	Transceiver	Transceiver
Form Factor	SFP+	SFP+	QSFP28	SFP	SFP+
Data Rate	10G	10G	50G	1G	10G
Connector Type	LC	LC	LC	LC	LC
Wavelength	1310 nm	1310 nm	1310nm	1546.92 nm	850 nm
Transmission Distance	Long-Range	Extended-Range	Long-Range	Long-Range	Short-Range
Fiber Type	Single-mode	Single-mode	Single-mode	Single-mode	Multi-mode
Max Distance	10 km	80 km	10km	80 km	300 meters
Supported Protocols	Ethernet	Ethernet, Fibre Channel	Ethernet	Ethernet	Ethernet, Fibre Channel
Network Interface	Fiber	Fiber	Fiber	Fiber	Fiber
Power Consumption	N/A	3.8W	N/A	2.5W	3.5 W
Operating Temperature	0 to 70°C	0 to 70°C	0 to 70°C	0 to 70°C	0 to 70°C
Storage Temperature	-40 to 85°C	-40 to 85°C	-40 to 85°C	-40 to 85°C	-40 to 85°C
Input Voltage	3.3V	3.3V	3.3V	3.3V	3.3V
Compatibility	Cisco / Juniper / Huawei / Arista	Cisco, Juniper, Huawei, Arista	N/A	Cisco, Juniper, Huawei, Arista	Cisco, Juniper, Huawei, Arista
Product Name	SFP+10GE-LH10-SM1310	OSX080N06	QSFP28-50G-BIDI-10km-SM-1	DWDM-SFPGE-1546-92	FCXPD0200 High-Performance SFP+ Transceiver
Height	N/A	0.4 inches	N/A	0.125 inches	1.65 inches
Width	N/A	0.9 inches	N/A	0.55 inches	0.55 inches
Depth	N/A	0.7 inches	N/A	1.00 inches	1.0 inches
Weight	N/A	0.05 lbs	N/A	0.05 lbs	0.2 lbs

Reviews & Ratings

Gareth Wilson

Stable 10G single mode connectivity.

Ahsan Raza

Good performance for metro links.

Leo Patterson

No signal issues detected.

Martin Olesen

Quick installation and reliable uptime.

Sohail Akram

Meets enterprise expectations.

Oliver Reed

Dependable 10G LH optic.

Questions & Answers

What is the SFP+10GE-LH10-SM1310 optical transceiver?

The SFP+10GE-LH10-SM1310 is a hot-pluggable 10GBASE-LR SFP+ optical transceiver operating at 1310 nm, designed for single-mode fiber links up to 10 km.

What data rate does the SFP+10GE-LH10-SM1310 support?

This module supports data rates up to 10.3125 Gb/s, fully compliant with 10G Ethernet standards (IEEE 802.3ae).

Which wavelength does this transceiver use?

It operates at a nominal wavelength of 1310 nm, optimized for low-loss transmission over single-mode fiber.

What is the maximum reach of the SFP+10GE-LH10-SM1310?

It supports link lengths up to 10 km over standard single-mode fiber (OS1/OS2) at 10 Gb/s.
