Basic analog turret with consistent IR and stable output. Good for quick retrofit installs.
DS-2CE56C0T-IRMF
C0T_TVI_720p: 4-in-1 (TVI, CVI, AHD & CVBS), IP66 protection...
FEATURED DEAL
Name:
DS-2CE56C0T-IRMF
- Description:
- C0T_TVI_720p: 4-in-1 (TVI, CVI, AHD & CVBS), IP66 protection, 2.8/3.6/6mm Lens, ICR + 20m IR Distance, 12 VDC power supply
- Rating:
Added to cart 28 times recently
- Availability:
In stock - Ready to Ship
- Brand:
- Hikvision
- Condition:
3 Year Extended Warranty
Same-day Shipping
14-Day Money Back Guarantee
Shipping:
Payment:
3 Year Extended Warranty
Same-day Shipping
14-Day Money Back Guarantee
Need Additional Discount on Product?
Request a quote below - Get Exclusive Pricing and Support.
Shipping:
Payment:
TRUSTED, TRIED, PROVEN
Officially Accredited
& Verified By
Next-Gen IT
Solutions Powered By
DS-2CE56C0T-IRMF Overview
DS-2CE56C0T-IRMF is an analog turret security camera offering 1080p resolution with a motorized lens and a 1/3" CMOS sensor. It delivers clear video imagery using H.264 compression and features infrared night vision with an effective range of 20m via EXIR technology.
Engineered for indoor retail environments, perimeter defense, license plate recognition, and warehouse surveillance, this camera connects over coaxial cabling and is built to endure harsh conditions with an IP66 weather rating. It provides essential surveillance functionality without audio support and is not ONVIF compliant, making it ideally suited for dedicated analog system deployments.
DS-2CE56C0T-IRMF price is is available on request. Get immediate quote.
Request bulk order quote for DS-2CE56C0T-IRMF for additional pricing. Browse the full category range or explore all Hikvision products.
DS-2CE56C0T-IRMF Specifications
- Product Type
- Security Camera
- Camera Type
- Turret
- Technology
- Analog HD
- Resolution
- 1080p
- Lens Type
- Motorized
- Smart Features
- N/A
- Mounting Type
- Wall
- Color
- Black
- Use Case
- Retail
- Focal Length
- 4mm
- Image Sensor
- 1/3" CMOS
- Frame Rate
- 30 FPS
- Infrared Night Vision
- 20m
- Low Light Technology
- EXIR
- Day/Night Mode
- True Day/Night (ICR)
- Video Compression
- H.264
- Audio Support
- No Audio
- Storage Option
- None
- Max Storage Capacity
- N/A
- Power Type
- 12V DC
- Weather Rating
- IP66
- Vandal Resistance
- N/A
- ONVIF Compliant
- No
- Product Name
- DS-2CE56C0T-IRMF
- Height
- 6.1 inches
- Width
- 2.8 inches
- Depth
- 3.2 inches
- Weight
- 1.3 lbs
Quality Certifications
To get the detailed certification, please go to the Compliance Center.
Product Comparison Table
 DS-2CE56C0T-IRMF |  DS-2CE11D8T-PIRLO |  DS-2CE57H0T-VPITF(C) |  DS-2CE56D0T-VFIRE |  DS-2CE56D8T-AITZF | |
|---|---|---|---|---|---|
| Product Type | Security Camera | Security Camera | Security Camera | Security Camera | Security Camera |
| Camera Type | Turret | Bullet | Bullet | Bullet | Turret |
| Technology | Analog HD | Analog HD | Analog HD | Analog HD | Analog HD |
| Resolution | 1080p | 1080p | 2MP | 1080p | 1080p |
| Lens Type | Motorized | Fixed | Fixed | Fixed | Fixed |
| Smart Features | N/A | Motion Detection | N/A | N/A | N/A |
| Mounting Type | Wall | Wall | Wall | Wall | Wall |
| Color | Black | Black | Black | Black | Black |
| Use Case | Retail | Indoor / Retail / Perimeter Protection / Warehouse | Retail | Perimeter Protection | Retail / Perimeter Protection / Parking Lots / Warehouse |
| Focal Length | 4mm | 3.6mm | 2.8mm | 3.6mm | 3.6mm |
| Image Sensor | 1/3" CMOS | 1/3" CMOS | 1/3" CMOS | 1/3" CMOS | 1/3" CMOS |
| Frame Rate | 30 FPS | 30 FPS | 30 FPS | 30 FPS | 30 FPS |
| Infrared Night Vision | 20m | 20m | 30m | 30m | 30m |
| Low Light Technology | EXIR | EXIR | EXIR | EXIR | EXIR |
| Day/Night Mode | True Day/Night (ICR) | True Day/Night (ICR) | True Day/Night (ICR) | True Day/Night (ICR) | True Day/Night (ICR) |
| Video Compression | H.264 | H.264 | H.264 | H.264 | H.264 |
| Audio Support | No Audio | No Audio | No Audio | No Audio | No Audio |
| Storage Option | None | NVR | NVR | NVR | None |
| Max Storage Capacity | N/A | N/A | N/A | N/A | N/A |
| Power Type | 12V DC | 12V DC | 12V DC | 12V DC | 12V DC |
| Weather Rating | IP66 | IP66 | IP66 | IP66 | IP67 |
| Vandal Resistance | N/A | N/A | None | N/A | None |
| ONVIF Compliant | No | No | No | No | No |
| Product Name | DS-2CE56C0T-IRMF | DS-2CE11D8T-PIRLO | DS-2CE57H0T-VPITF(C) | DS-2CE56D0T-VFIRE | DS-2CE56D8T-AITZF |
| Height | 6.1 inches | 6 inches | 2.8 inches | 2.8 inches | 2.8 inches |
| Width | 2.8 inches | 3.5 inches | 3.9 inches | 2.8 inches | 2.4 inches |
| Depth | 3.2 inches | 3.5 inches | 2.9 inches | 3.0 inches | 2.4 inches |
| Weight | 1.3 lbs | 1.5 lbs | 1.3 lbs | 1.1 lbs | 1.65 lbs |
Reviews & Ratings
M
Mitchell Barnes
4
Easy to deploy and reliable for standard indoor coverage.
V
Vernon Clarke
5
Good value for legacy systems. Image is clear enough for general monitoring.
D
Douglas Kent
3
Stable performance and simple configuration. Works well for offices and corridors.
P
Percy Williams
4
Dependable camera for cost sensitive projects. IR coverage is consistent.
Questions & Answers
What video formats does the DS-2CE56C0T-IRMF support?
The DS-2CE56C0T-IRMF supports TVI, CVI, AHD and CVBS video formats, allowing seamless integration with most analog CCTV DVRs.
What resolution does this 4-in-1 camera deliver?
This camera delivers 720p HD resolution at 25/30 fps, ensuring clear, detailed video for both live monitoring and recording.
Which lens options are available for this model?
Choose from three fixed-focus lenses—2.8 mm, 3.6 mm or 6 mm—to customize your field of view from wide-angle to standard perspective.
How far can the IR LEDs illuminate in low-light conditions?
The DS-2CE56C0T-IRMF features up to 20 meters of infrared illumination, providing clear black-and-white night vision in complete darkness.
