DS-2CE57D3T-VPITF Overview
DS-2CE57D3T-VPITF is an analog bullet security camera offering 1080p resolution with a fixed lens, equipped with a 1/3" CMOS sensor and delivering H.264 video compression. Its infrared night vision extends up to 30m, providing clear surveillance in low-light conditions while supporting robust NVR-based storage.
Engineered for use in indoor retail, perimeter defense, license plate recognition, and warehouse surveillance, the camera connects via coaxial cabling and meets ONVIF compliance standards. With an IP66 weather rating and a design optimized for wall mounting, DS-2CE57D3T-VPITF delivers reliable performance in harsh outdoor conditions without audio support.
What is the price of DS-2CE57D3T-VPITF?
Pricing for DS-2CE57D3T-VPITF is available on request. Get immediate quote or for exclusive discounts, opt for bulk quotation for DS-2CE57D3T-VPITF.
Explore more options from Hd Cameras or explore other Hikvision products.
DS-2CE57D3T-VPITF Specifications
| Product Type | Security Camera |
| Camera Type | Bullet |
| Technology | Analog HD |
| Resolution | 1080p |
| Lens Type | Fixed |
| Smart Features | N/A |
| Mounting Type | Wall |
| Color | Black |
| Use Case | Retail |
| Focal Length | 2.8mm |
| Image Sensor | 1/3" CMOS |
| Frame Rate | 30 FPS |
| Infrared Night Vision | 30m |
| Low Light Technology | IR |
| Day/Night Mode | True Day/Night (ICR) |
| Video Compression | H.264 |
| Audio Support | No Audio |
| Storage Option | NVR |
| Max Storage Capacity | N/A |
| Power Type | 12V DC |
| Weather Rating | IP66 |
| Vandal Resistance | N/A |
| ONVIF Compliant | No |
| Product Name | DS-2CE57D3T-VPITF |
| Height | 2.0 inches |
| Width | 2.0 inches |
| Depth | 2.4 inches |
| Weight | 0.9 lbs |
Quality Certifications
To get the detailed certification, please go to the Compliance Center.
Product Comparison Table
|
|
|
|
|
|
|---|---|---|---|---|---|
| Audio Support | 2-Way Audio | No Audio | No Audio | No Audio | No Audio |
| Camera Type | Bullet | Turret | Bullet | Bullet | Turret |
| Color | Black | Black | Black | Black | White |
| Day/Night Mode | True Day/Night (ICR) | True Day/Night (ICR) | True Day/Night (ICR) | True Day/Night (ICR) | True Day/Night (ICR) |
| Depth | 3.0 inches | 2.3 inches | 2.2 inches | 2.4 inches | 2.5 inches |
| Focal Length | 4mm | 4mm | 3.6mm | 2.8mm | 2.7–13.5mm |
| Frame Rate | 30 FPS | 30 FPS | 30 FPS | 30 FPS | 30 FPS |
| Height | 3.0 inches | 4.7 inches | 2.8 inches | 2.0 inches | 3.3 inches |
| Image Sensor | 1/2.8" CMOS | 1/3" CMOS | 1/3" CMOS | 1/3" CMOS | 1/2.8" CMOS |
| Infrared Night Vision | 30m | 30m | 30m | 30m | 30m |
| Lens Type | Fixed | Fixed | Fixed | Fixed | Varifocal |
| Low Light Technology | IR | EXIR | EXIR | IR | EXIR |
| Max Storage Capacity | 256 GB | N/A | N/A | N/A | N/A |
| Mounting Type | Wall | Wall | Wall | Wall | Wall |
| ONVIF Compliant | Yes | No | No | No | No |
| Power Type | PoE | 12V DC | 12V DC | 12V DC | 12V DC |
| Product Name | DS-2CC52D9T-AVPIT3ZE | DS-2CE56D8T-IT3ZF | DS-2CE16C0T-IT1 | DS-2CE57D3T-VPITF | DS-2CE56D8T-ITME |
| Product Type | Security Camera | Security Camera | Security Camera | Security Camera | Security Camera |
| Resolution | 1080p | 8MP | 2MP | 1080p | 8MP |
| Smart Features | Motion Detection | N/A | N/A | N/A | N/A |
| Storage Option | NVR | NVR | NVR | NVR | NVR |
| Technology | IP Camera | Analog HD | Analog HD | Analog HD | Analog HD |
| Use Case | Indoor / Retail / Perimeter Protection / Warehouse | Perimeter Protection | Indoor, Retail, Perimeter Protection, Warehouse | Retail | Indoor / Retail / Perimeter Protection / Warehouse |
| Vandal Resistance | N/A | N/A | N/A | N/A | N/A |
| Video Compression | H.265 | H.265 | H.264 | H.264 | H.265 |
| Weather Rating | IP67 | IP67 | IP67 | IP66 | IP66 |
| Weight | 1.2 lbs | 1.65 lbs | 1.1 lbs | 0.9 lbs | 1.65 lbs |
| Width | 3.5 inches | 2.3 inches | 2.2 inches | 2.0 inches | 3.3 inches |
Showing - of 0 Results
Questions & Answers
Q
What video formats does the DS-2CE57D3T-VPITF support?
A
The DS-2CE57D3T-VPITF delivers 4-in-1 analog HD video with support for TVI, CVI, AHD and CVBS formats for flexible compatibility with most DVRs.
Q
What resolution does the DS-2CE57D3T-VPITF camera provide?
A
It captures high-definition 1080p video at up to 25/30 frames per second to ensure smooth, detailed surveillance footage.
Q
What lens options are available for the DS-2CE57D3T-VPITF?
A
The camera is available with fixed 2.8 mm, 3.6 mm or 6 mm lenses to suit wide-angle or narrow field-of-view requirements.
Q
How far can the infrared illumination reach?
A
Two EXIR LEDs deliver up to 30 meters of infrared illumination for clear nighttime imaging.
Q
What are 3D DNR and 120 dB WDR, and how do they improve image quality?
A
3D Digital Noise Reduction minimizes image noise in low-light conditions while 120 dB Wide Dynamic Range balances bright and dark areas for clearer detail in high-contrast scenes.
Q
What does “up-the-coax” functionality mean?
A
“Up-the-coax” (UTC) allows remote camera configuration, menu control, and firmware updates via the existing coaxial cable without extra wiring.
Q
What power supply does the camera require?
A
The camera operates on a standard 12 V DC power supply (±25 %), providing reliable power delivery for continuous operation.
Q
Is the DS-2CE57D3T-VPITF suitable for outdoor installation?
A
Yes, with an IP67-rated housing it is fully dust-tight and waterproof, making it ideal for harsh outdoor environments.
Q
How durable is the camera against physical impact?
A
The camera meets IK10 vandal-resistant standards, protecting it from strong impacts and tampering attempts.
Q
Which DVRs are compatible with this camera?
A
It is compatible with HD-TVI, HD-CVI, AHD and CVBS DVRs, allowing seamless integration with most existing analogue surveillance systems.
Q
What is the maximum cable length for maintaining 1080p resolution?
A
When using RG59 coaxial cable, it can transmit 1080p video signals up to approximately 500 meters without significant loss.
Q
What operating temperature range does the camera support?
A
The camera operates reliably between –40 °C and 60 °C (–40 °F to 140 °F), making it suitable for extreme climates.
Q
What mounting options are available?
A
It features a standard dome form factor with a ½″-14 NPS mount interface compatible with most indoor and outdoor camera brackets.
Q
What field of view does each lens provide?
A
The 2.8 mm lens offers ~102° horizontal, the 3.6 mm lens ~88°, and the 6 mm lens ~53° for different surveillance coverage needs.
Q
What are common applications for the DS-2CE57D3T-VPITF?
A
Typical use cases include retail stores, office buildings, parking lots and industrial sites where high-resolution, weatherproof surveillance is required.
