Name: Huawei AR3260,Service and Router Unit 100E,4 SIC,2 WSIC,4 XSIC,350W AC Power
Brand: Huawei
SKU: Huawei AR3260 with SRU100E, AC Power (AR3260-100E-AC)
Availability: OutOfStock

Question 1

What is the Huawei AR3260-100E-AC?

Accepted Answer

The Huawei AR3260-100E-AC is a next-generation branch router featuring the SRU100E Service and Router Unit, four SIC slots, two WSIC slots, four XSIC slots and a 350 W AC power supply for high-availability enterprise networks.

Question 2

What are the key hardware specifications of the AR3260-100E-AC?

Accepted Answer

It delivers up to 40 Gbps forwarding performance, supports four SIC slots, two WSIC slots, four XSIC slots, and is powered by a 350 W AC hot-swappable power module.

Question 3

Which expansion modules does the AR3260-100E-AC support?

Accepted Answer

The router supports up to four Service Interface Cards (SIC), two Wideband SICs (WSIC) and four Extended SICs (XSIC) for flexible interface provisioning.

Question 4

What power supply does the AR3260-100E-AC use?

Accepted Answer

It uses a 350 W AC hot-swappable power supply with built-in over-voltage, under-voltage, over-current and short-circuit protection.

Question 5

What is the maximum forwarding performance?

Accepted Answer

With the SRU100E, the AR3260-100E-AC delivers up to 40 Gbps of IPv4/IPv6 forwarding capacity and up to 6 million concurrent sessions.

Question 6

Which routing protocols are supported on the AR3260-100E-AC?

Accepted Answer

It supports full suites of BGP, OSPF, IS-IS, RIP, VRRP, VRF-Lite and static routing for flexible multi-protocol network deployments.

Question 7

What built-in security features does it offer?

Accepted Answer

The router integrates firewall, IPS, DoS defense, URL filtering, NAT, anti-DDoS and AAA for comprehensive branch-level security.

Question 8

Does the AR3260-100E-AC support Quality of Service (QoS)?

Accepted Answer

Yes, it provides multi-level QoS policies, traffic classification, shaping, policing and priority queuing to ensure service-level guarantees.

Question 9

What management and monitoring interfaces are available?

Accepted Answer

It offers CLI, Web GUI, SNMP, NetConf and Huawei eSight support alongside USB and console ports for local and remote management.

Question 10

Which VPN technologies are supported?

Accepted Answer

The AR3260-100E-AC supports IPsec, GRE, L2TP, DMVPN and SSL VPN for secure site-to-site and remote access connectivity.

Question 11

What redundancy and high-availability features are included?

Accepted Answer

It supports VRRP, BFD, bidirectional forwarding detection, dual-power backup and stateful switchover for mission-critical uptime.

Question 12

What environmental specifications apply to the AR3260-100E-AC?

Accepted Answer

The router operates from –40 °C to +65 °C (storage: –40 °C to +85 °C), 5%–95% non-condensing humidity and meets ETSI, FCC and RoHS standards.

Question 13

What warranty and service options are available?

Accepted Answer

Huawei offers a one-year limited hardware warranty with options to upgrade to 3- or 5-year maintenance plans including 24×7 support and on-site response.

Question 14

How do I install and configure the AR3260-100E-AC?

Accepted Answer

Mount the device in a 19″ rack, connect AC power and network links, then use the CLI wizard or Web GUI to complete initial configuration.

Question 15

What are the typical use cases for the AR3260-100E-AC?

Accepted Answer

It is ideal for large enterprise branch offices, small data centers and service provider aggregation with high-throughput and multi-service requirements.

Question 16

How can I request a quote or place an order for the AR3260-100E-AC?

Accepted Answer

Contact your authorized Huawei reseller or visit Huawei’s online store, provide model AR3260-100E-AC and required accessories, and request a formal quotation.

	Huawei AR3260 with SRU100E, AC Power (AR3260-100E-AC)	Huawei AR3260 with SRU200E, AC Power (AR3260-200E-AC)	Huawei AR3260 with SRU40, AC Power (AR0M0036SA00)	AR0MNTEH10501	AR3260E-S
5G Support	No	No	No	No	No
Architecture	Modular	Modular	Modular	Modular	Modular
Broadband	N/A	N/A	N/A	Fiber Optic	Fiber Optic / DSL
Built-in Security Features	Firewall / Intrusion Prevention	Firewall / Intrusion Prevention / Malware Protection	Firewall / Intrusion Prevention / Malware Protection	Firewall, Intrusion Prevention, Malware Protection	Firewall, Intrusion Prevention
Compliance Standards	CE / FCC	N/A	CE / FCC	FCC, CE, RoHS	FCC, CE, RoHS
Connectivity Type	Wired / Ethernet	Wired	Wired	Wired	Wired
Depth	N/A	N/A	N/A	15 inches	15 inches
Device Type	Router	Router	Router	Router	Router
EMC	N/A	N/A	N/A	N/A	N/A
Ethernet Technology	10/100/1000	10/100/1000	10/100/1000	10/100/1000	10/100/1000
Expansion Slots	N/A	NIM / SFP+	NIM / SFP+	NIM	NIM
Features	VPN / IPv6 Compatible / Firewall / MPLS	VPN / Firewall / IPv6 Compatible / Modular	VPN / Firewall / IPv6 Compatible	Mesh, VPN, IPv6 Compatible, Firewall, MPLS, Syslog	VPN, Firewall, IPv6 Compatible, Redundancy
Firewall Features	Yes	Yes	Yes	Yes	Yes
Flash Memory	256 MB	512 MB	256 MB	256 MB	512 MB
Form Factor	Rack-mount	Rack-mount	Rack-mount	Rack-mount	Rack-mount
Height	N/A	N/A	N/A	2.0 inches	1.75 inches
High Availability Support	Supported	Supported	Supported	Supported	Supported
Integrated Services	Voice / Video / WAN Optimization	Voice / Video / WAN Optimization	Voice / Video / WAN Optimization	Voice, Video, WAN Optimization	Voice, Video
Interface Ports	RJ-45, SFP	RJ-45 / SFP	RJ-45 / SFP	RJ-45, SFP	RJ-45, SFP
LAN Ports	4 LAN Ports	4 LAN Ports	8 LAN Ports	8 LAN Ports	4 LAN Ports
Management	Managed	Managed	Managed	Managed	Managed
Memory	1 GB	2 GB	1 GB	8 GB	4 GB
Modular Slots Available	1 Slot	3+ Slots	2 Slots	3+ Slots	2 Slots
Network Protocols	IPv4 / IPv6	IPv4 / IPv6 / MPLS	IPv4 / IPv6	TCP/IP, UDP, ICMP, SNMP	IPv4, IPv6
Power	AC Power (100-240V)	N/A	65W	200W	300 Watt
Power Source	AC Power Supply	AC Power Supply	AC Power Supply	AC Power Supply / Redundant	AC Power Supply / Redundant
Product Name	Huawei AR3260 with SRU100E, AC Power (AR3260-100E-AC)	Huawei AR3260 with SRU200E, AC Power (AR3260-200E-AC)	Huawei AR3260 with SRU40, AC Power (AR0M0036SA00)	AR0MNTEH10501 Modular Enterprise Router	AR3260E-S Enterprise Router
Product Type	Enterprise Router	Enterprise Router	Enterprise Router	Enterprise Router	Enterprise Router
QoS Features	Supported	Supported	Supported	Supported	Supported
Remote Management	SSH / HTTPS / SNMP	SSH / Telnet / SNMP	SSH / Telnet / SNMP	SSH, Telnet, HTTP/HTTPS	SSH, Telnet, SNMP, HTTPS
Routing Protocols	OSPF / BGP / RIP / Static Routing	OSPF / BGP / RIP / Static Routing	OSPF / BGP / RIP / Static Routing	OSPF / BGP / EIGRP / RIP / Static Routing	OSPF / BGP / EIGRP / Static Routing
Safety	N/A	N/A	N/A	N/A	N/A
Speed/Capacity	Gigabit	Gigabit	Gigabit	Gigabit	Gigabit
Stacking Capability	Yes	Yes	Yes	Yes	Yes
Telecom	N/A	N/A	N/A	N/A	N/A
Throughput Capacity	1 Gbps	2 Gbps	1 Gbps	10 Gbps	10 Gbps
Use Case	Enterprise	Enterprise	Enterprise	Enterprise	Enterprise
VPN Support	IPSec / SSL VPN	IPSec / SSL VPN	IPSec / SSL VPN	IPSec / SSL VPN / GRE / DMVPN / FlexVPN	IPSec / SSL VPN
WAN Configuration	Dual WAN	Dual WAN	Dual WAN	Dual WAN	Dual WAN
WAN Ports	2 WAN	2 WAN Ports	Modular WAN	2 WAN	2 WAN
Weight	N/A	N/A	N/A	25 lbs	15 lbs
Wi-Fi Standard	N/A	N/A	N/A	N/A	N/A
Width	N/A	N/A	N/A	19 inches	17.5 inches
Wireless Support	No	No	No	No	No
