Name: Huawei AR3260,Service and Router Unit 200E,4 SIC,2 WSIC,4 XSIC,350W AC Power
Brand: Huawei
SKU: Huawei AR3260 with SRU200E, AC Power (AR3260-200E-AC)
Availability: OutOfStock

Question 1

What is the Huawei AR3260-SRU200E-AC router?

Accepted Answer

The Huawei AR3260-SRU200E-AC is a high-performance branch router featuring a Service and Router Unit 200E, 4 SIC slots, 2 WSIC slots, 4 XSIC slots, and a 350W AC power supply.

Question 2

What performance can I expect from the AR3260-SRU200E-AC?

Accepted Answer

The AR3260-SRU200E-AC delivers up to 1 Gbps forwarding throughput, hardware-accelerated security, and low-latency packet processing for demanding branch deployments.

Question 3

Which interface cards are supported on the AR3260?

Accepted Answer

The AR3260 supports up to 4 SIC, 2 WSIC, and 4 XSIC modules, enabling flexible combinations of GE, 10GE, T1/E1, VDSL2, and GPON interfaces.

Question 4

How much power does the AR3260-SRU200E-AC consume?

Accepted Answer

The AC-powered SRU200E unit consumes up to 350W under full load and supports efficient power management for branch environments.

Question 5

Does the AR3260 support power supply redundancy?

Accepted Answer

Yes, the AR3260 chassis can host dual AC power modules for N+1 redundancy, ensuring uninterrupted operation in the event of a power-unit failure.

Question 6

What security features are built into the AR3260?

Accepted Answer

The router includes hardware-accelerated IPSec VPN, firewall, NAT, DoS/DDoS protection, and intrusion prevention to secure branch traffic.

Question 7

Which network management protocols does the AR3260 support?

Accepted Answer

The AR3260 supports SNMPv2/v3, NetStream, NetConf, Huawei eSight, and Web/CLI management interfaces for centralized monitoring and configuration.

Question 8

Is the AR3260 compatible with Huawei’s SD-WAN solution?

Accepted Answer

Yes, the AR3260 integrates with Huawei Agile Controller and CloudWAN, delivering intelligent path selection, application QoS, and centralized orchestration.

Question 9

What deployment scenarios suit the AR3260?

Accepted Answer

Ideal for large enterprise branches, retail chains, and government sites requiring high throughput, multi-service integration, and robust security.

Question 10

What warranty and support options are available?

Accepted Answer

Huawei offers a standard one-year hardware warranty, extendable up to five years, with optional service packages for 24×7 support and advanced replacement.

Question 11

How do I install an XSIC module in the AR3260?

Accepted Answer

Power off the chassis, unlock the front bezel, insert the XSIC into an available slot until it clicks, secure the retention clip, then power on and configure via CLI or Web UI.

Question 12

Which routing protocols are supported?

Accepted Answer

The AR3260 supports OSPF, BGP, IS-IS, RIP, VRRP, and Policy-Based Routing, enabling dynamic, resilient, and policy-driven traffic forwarding.

Question 13

Can the AR3260 handle IPv6 traffic?

Accepted Answer

Yes, it offers full IPv6 routing, dual-stack deployment, MPLS IPv6 VPN, and IPv6-enhanced security for future-proof connectivity.

Question 14

What environmental specifications apply to the AR3260?

Accepted Answer

The router operates between 0°C and 45°C, tolerates 5%–95% non-condensing humidity, and meets ETSI noise and vibration standards.

Question 15

How scalable is the AR3260-SRU200E-AC?

Accepted Answer

With 12 expansion slots, modular power, and service-unit flexibility, the AR3260 scales from small branches to large multi-service sites without forklift upgrades.

Question 16

What SLAs can the AR3260 support for carrier-grade services?

Accepted Answer

It supports five-class QoS, hierarchical scheduling, traffic policing, and bandwidth reservation to meet stringent carrier SLA requirements.

	Huawei AR3260 with SRU200E, AC Power (AR3260-200E-AC)	Huawei AR3260 with SRU100E, AC Power (AR3260-100E-AC)	Huawei AR3260 with SRU400, AC Power (AR32-400-AC)	Huawei AR3260 with 2SRU100E, 2AC Power (AR3260-2X100E-AC)	AR3260
5G Support	No	No	No	No	No
Architecture	Modular	Modular	Modular	Modular	Modular
Broadband	N/A	N/A	N/A	N/A	Fiber Optic
Built-in Security Features	Firewall / Intrusion Prevention / Malware Protection	Firewall / Intrusion Prevention	Firewall / Intrusion Prevention / Malware Protection	Firewall, Intrusion Prevention, Malware Protection	Firewall / Intrusion Prevention / Malware Protection
Compliance Standards	N/A	CE / FCC	CE / FCC	CE, FCC	FCC / CE / RoHS
Connectivity Type	Wired	Wired / Ethernet	Wired	Wired	Wired
Depth	N/A	N/A	N/A	N/A	12 inches
Device Type	Router	Router	Router	Router	Router
EMC	N/A	N/A	N/A	N/A	FCC Part 15 / EN 55032
Ethernet Technology	10/100/1000	10/100/1000	10/100/1000	10/100/1000	10/100/1000
Expansion Slots	NIM / SFP+	N/A	SFP+	SRU100E	NIM / SFP+
Features	VPN / Firewall / IPv6 Compatible / Modular	VPN / IPv6 Compatible / Firewall / MPLS	VPN / IPv6 Compatible / Firewall / MPLS	Modular, VPN, IPv6 Compatible, Firewall, Redundancy	VPN / VoIP / IPv6 Compatible / Firewall
Firewall Features	Yes	Yes	Yes	Yes	Yes
Flash Memory	512 MB	256 MB	256 MB	512 MB	512 MB
Form Factor	Rack-mount	Rack-mount	Rack-mount	Rack-mount	Rack-mount
Height	N/A	N/A	N/A	N/A	2.2 inches
High Availability Support	Supported	Supported	Supported	Supported	Supported
Integrated Services	Voice / Video / WAN Optimization	Voice / Video / WAN Optimization	Voice / Video / WAN Optimization	Voice, Video, WAN Optimization	Voice / Video
Interface Ports	RJ-45 / SFP	RJ-45, SFP	RJ-45 / SFP	RJ-45, SFP	RJ-45 / SFP
LAN Ports	4 LAN Ports	4 LAN Ports	4 LAN Ports	4 LAN Ports	4 LAN Ports
Management	Managed	Managed	Managed	Managed	Managed
Memory	2 GB	1 GB	1 GB	4 GB	4 GB
Modular Slots Available	3+ Slots	1 Slot	N/A	2 Slots	2 Slots
Network Protocols	IPv4 / IPv6 / MPLS	IPv4 / IPv6	IPv4 / IPv6	IPv4, IPv6	IPv4 / IPv6
Power	N/A	AC Power (100-240V)	60W	N/A	250W
Power Source	AC Power Supply	AC Power Supply	AC Power Supply	AC Power Supply, Redundant	AC Power Supply / Redundant
Product Name	Huawei AR3260 with SRU200E, AC Power (AR3260-200E-AC)	Huawei AR3260 with SRU100E, AC Power (AR3260-100E-AC)	Huawei AR3260 with SRU400, AC Power (AR32-400-AC)	Huawei AR3260 with 2SRU100E, 2AC Power (AR3260-2X100E-AC)	AR3260 Enterprise Modular Router
Product Type	Enterprise Router	Enterprise Router	Enterprise Router	Enterprise Router	Enterprise Router
QoS Features	Supported	Supported	Supported	Supported	Supported
Remote Management	SSH / Telnet / SNMP	SSH / HTTPS / SNMP	SNMP / Telnet / HTTPS / SSH	SSH, Telnet, Web UI	Telnet / SSH / SNMP
Routing Protocols	OSPF / BGP / RIP / Static Routing	OSPF / BGP / RIP / Static Routing	OSPF / BGP / Static Routing	OSPF / BGP / RIP / Static Routing	OSPF / BGP / EIGRP / RIP / Static Routing
Safety	N/A	N/A	N/A	N/A	UL / CE
Speed/Capacity	Gigabit	Gigabit	Gigabit	Gigabit	Gigabit
Stacking Capability	Yes	Yes	Yes	Yes	Yes
Telecom	N/A	N/A	N/A	N/A	ITU-T / ANSI
Throughput Capacity	2 Gbps	1 Gbps	4 Gbps	N/A	2 Gbps
Use Case	Enterprise	Enterprise	Enterprise	Enterprise	Enterprise
VPN Support	IPSec / SSL VPN	IPSec / SSL VPN	IPSec / SSL VPN / GRE / N/A	IPSec / SSL VPN	IPSec / SSL VPN
WAN Configuration	Dual WAN	Dual WAN	Dual WAN	Dual WAN	Dual WAN
WAN Ports	2 WAN Ports	2 WAN	2 WAN	2 WAN Ports	2 WAN
Weight	N/A	N/A	N/A	N/A	15 lbs
Wi-Fi Standard	N/A	N/A	N/A	N/A	N/A
Width	N/A	N/A	N/A	N/A	17 inches
Wireless Support	No	No	No	No	No
