Is the OSX001002 single-mode or multi-mode?

This transceiver is designed for single-mode fiber (SMF) to achieve long-reach connectivity.

What is the maximum link distance?

The module supports distances up to 10 km over single-mode fiber at 1310 nm.

What is the transmitter output power range?

Transmitter optical output power ranges from –8.2 dBm (minimum) to +0.5 dBm (maximum).

What is the receiver sensitivity of the OSX001002?

The receiver sensitivity is –12.6 dBm, ensuring reliable signal detection at full 10 km reach.

How do I calculate the optical power budget?

Subtract the receiver sensitivity (–12.6 dBm) from the minimum transmitter output (–8.2 dBm) for a 4.4 dB link budget.

Which network devices are compatible with this SFP+ module?

It is compatible with any SFP+ slot from major vendors (Cisco, Juniper, HP, Dell, Arista) that supports 10 Gb/s, 1310 nm modules.

Is the OSX001002 hot-pluggable?

Yes. It supports hot-swap installation without powering down the host equipment.

Does this transceiver support digital diagnostics monitoring?

Yes. It complies with SFF-8472 for real-time monitoring of optical output power, temperature, and voltage.

What is the operating temperature range?

The module operates reliably from 0 °C to 70 °C (commercial temperature range).

Is the OSX001002 RoHS compliant?

Yes. It meets RoHS standards for restricted use of hazardous substances in electronic equipment.

What applications are ideal for this 10 Gb/s SFP+ transceiver?

It is ideal for 10 Gigabit Ethernet, 10 G Fibre Channel, data center uplinks, and enterprise campus backbone links.

How do I install the OSX001002 in my network switch?

Align the module with the SFP+ cage, gently slide it in until the latch clicks, then connect the LC duplex fiber cable.

FEATURED DEAL

Name:

OSX001002

Name: Optical Transceiver(SFP+,1310nm,10Gb/s,-8.2~0.5dBm,-12.6dBm,LC,SM,10km)
Brand: Huawei
SKU: OSX001002
Price: 67.00 USD
Availability: InStock
Rating: 4.3 (6 reviews)

Description:: Optical Transceiver(SFP+,1310nm,10Gb/s,-8.2~0.5dBm,-12.6dBm,LC,SM,10km)
Rating:: 4.3(6)
Added to cart 28 times recently
Availability:: In stock - Ready to Ship
Brand:: Huawei
GTIN:: 6920702795667
Condition:
Warranty:: 3
List Price:: $2,571.00
Price:: $67.0097.4% off

Quantity:

Business price:

Enroll your business for free

3 Year Extended Warranty

Same-day Shipping

14-Day Money Back Guarantee

Shipping:

Payment:

osx001002 optical transceiver(sfp+,1310nm,10gb/s,-8.2~0.5dbm,-12.6dbm,lc,sm,10km)

3 Year Extended Warranty

Same-day Shipping

14-Day Money Back Guarantee

Need Additional Discount on Product?

Request a quote below - Get Exclusive Pricing and Support.

Shipping:

Payment:

OSX001002

Optical Transceiver(SFP+,1310nm,10Gb/s,-8.2~0.5dBm,-12.6dBm,...

$2,571.00 $67.0097.4% off

11 in Global Warehouse Global

TRUSTED, TRIED, PROVEN

$5,000,000+

Inventory Delivered By

Officially Accredited

& Verified By

Next-Gen IT

Solutions Powered By

OSX001002 Overview

OSX001002 is a 10G SFP+ transceiver developed for high-performance data center and enterprise network applications. It features an LC connector, supports short-range transmission over multi-mode fiber, and is optimized for both Ethernet and Fibre Channel protocols.

With its standardized SFP+ form factor and compact physical dimensions, OSX001002 is ideal for telecom deployments and other high-speed network environments. Designed to integrate seamlessly with major vendor platforms, it provides the reliable and efficient performance essential for modern communication infrastructures.

OSX001002 price is $67.00, a 97.4% saving from the Huawei list price of $2,571.00. OSX001002 is in stock and available for next-day dispatch. (terms applied)

Request bulk order quote for OSX001002 for additional pricing. Browse the full Huawei Transceivers series or explore all Huawei products.

OSX001002 Specifications

Product Type: Transceiver
Form Factor: SFP+
Data Rate: 10G
Connector Type: LC
Wavelength: 850nm
Transmission Distance: Short-Range
Fiber Type: Multi-mode
Max Distance: 300 meters
Supported Protocols: Ethernet, Fibre Channel
Network Interface: Fiber
Power Consumption: 3.5W
Operating Temperature: 0 to 70°C
Storage Temperature: -40 to 85°C
Input Voltage: 3.3V
Compatibility: Cisco, Juniper, Huawei, Arista
Product Name: OSX001002 10G SFP+ Transceiver
Height: 0.14 inches
Width: 0.55 inches
Depth: 0.90 inches
Weight: 0.03 lbs

Quality Certifications

To get the detailed certification, please go to the Compliance Center.

Product Comparison Table

	OSX001002	SFP-FC2G-LW	CWDM-XFP10G-1511	Huawei QSFP-40G-LR4	FSFL00701
Product Type	Transceiver	Transceiver	Transceiver	Transceiver	Transceiver
Form Factor	SFP+	SFP	XFP	QSFP	SFP+
Data Rate	10G	2G	10G	40G	10G
Connector Type	LC	LC	LC	LC	LC
Wavelength	850nm	1310 nm	1511 nm	1310 nm	850 nm
Transmission Distance	Short-Range	Long-Range	Long-Range	Long-Range	Short-Range
Fiber Type	Multi-mode	Single-mode	Single-mode	Single-mode	Multi-mode
Max Distance	300 meters	10 km	80 km	10 km	300 meters
Supported Protocols	Ethernet, Fibre Channel	Fibre Channel	Ethernet	Ethernet	10G Ethernet
Network Interface	Fiber	Fiber	Fiber	Ethernet	Ethernet
Power Consumption	3.5W	N/A	N/A	N/A	3.5W
Operating Temperature	0 to 70°C	0 to 70°C	0 to 70°C	0 to 70°C	0 to 70°C
Storage Temperature	-40 to 85°C	-40 to 85°C	-40 to 85°C	-40 to 85°C	-40 to 85°C
Input Voltage	3.3V	3.3V	3.3V	3.3V	3.3V
Compatibility	Cisco, Juniper, Huawei, Arista	Cisco / Juniper / Huawei / Arista	Cisco, Juniper, Huawei	Huawei	Cisco / Juniper / Huawei / Arista
Product Name	OSX001002 10G SFP+ Transceiver	SFP-FC2G-LW	CWDM-XFP10G-1511	Huawei QSFP-40G-LR4	FSFL00701 10G SFP+ Transceiver Module
Height	0.14 inches	N/A	0.6 inches	N/A	0.5 inches
Width	0.55 inches	N/A	0.5 inches	N/A	1.0 inches
Depth	0.90 inches	N/A	2.0 inches	N/A	0.4 inches
Weight	0.03 lbs	N/A	0.1 lbs	N/A	0.1 lbs

Reviews & Ratings

Andrew Collins

Stable 10G single mode optic for access deployments.

Daniel Brooks

Quick link up and reliable performance.

James Morgan

Good compatibility with switches.

Paul Harrison

Consistent optical levels.

Stephen Carter

No issues in production use.

Oliver Hart

Solid SFP plus transceiver.

Questions & Answers

What is the OSX001002 optical transceiver?

The OSX001002 is an SFP+ optical transceiver module supporting 10 Gb/s data rate, 1310 nm wavelength, LC duplex connectors over single-mode fiber for links up to 10 km.

Which wavelength does the OSX001002 support?

It operates at a nominal wavelength of 1310 nm, optimized for single-mode fiber transmission.

What maximum data rate does this SFP+ transceiver support?

The module supports a maximum line rate of 10 Gb/s, ideal for 10 Gigabit Ethernet and Fibre Channel applications.

What connector type is used on the OSX001002?

It features standard LC duplex connectors for easy plug-and-play optical link deployment.
