Name: Optical Transceiver(XFP,1550nm,9.95Gb/s to 11.1Gb/s,-1dBm~2dBm,-15dBm,LC,Singlemode,40km)
Brand: Huawei
SKU: OSX040N09
Price: 1557.00 USD
Availability: InStock
Rating: 4.3 (6 reviews)

Question 1

What is the data rate supported by the OSX040N09 XFP transceiver?

Accepted Answer

The OSX040N09 supports 9.95 Gb/s to 11.1 Gb/s line rates, ensuring reliable 10 Gigabit Ethernet performance.

Question 2

Which wavelength does the OSX040N09 operate on?

Accepted Answer

This XFP transceiver operates at a central wavelength of 1550 nm, ideal for long-distance singlemode transmission.

Question 3

How far can the OSX040N09 transmit data?

Accepted Answer

It supports up to 40 km reach over singlemode fiber with standard LC connectors.

Question 4

What are the optical output power and receiver sensitivity?

Accepted Answer

Transmit power ranges from –1 dBm to +2 dBm, and receiver sensitivity is –15 dBm, ensuring robust link margins.

Question 5

Which fiber type and connector does it use?

Accepted Answer

The module uses singlemode fiber with an LC duplex connector for easy mating with standard cabling.

Question 6

Is the OSX040N09 transceiver hot-swappable?

Accepted Answer

Yes, the XFP module is hot-swappable, allowing plug-and-play installation without powering down your device.

Question 7

Which applications is the OSX040N09 best suited for?

Accepted Answer

It is ideal for 10 Gigabit Ethernet, WAN, SONET/SDH, and high-speed fiber-optic links in campus and data center networks.

Question 8

Is the OSX040N09 compliant with industry standards?

Accepted Answer

Yes, it is fully XFP MSA compliant and meets IEEE 802.3ae and ITU-T G.691 specifications.

Question 9

What operating temperature range does the module support?

Accepted Answer

The transceiver operates between 0 °C and 70 °C (commercial range) for reliable performance in standard environments.

Question 10

How do I install the OSX040N09 in my switch or router?

Accepted Answer

Simply insert the XFP transceiver into an XFP port until it clicks, then connect your LC duplex fiber cable.

Question 11

Which vendor equipment is the OSX040N09 compatible with?

Accepted Answer

It is compatible with most major brands, including Cisco, Juniper, Arista, Huawei, and HP that support XFP modules.

Question 12

Does this module support Digital Optical Monitoring (DOM)?

Accepted Answer

Yes, built-in DOM allows real-time monitoring of optical power, temperature, voltage, and laser bias current.

Question 13

What is the power consumption of the OSX040N09?

Accepted Answer

Typical power consumption is below 3.5 W, meeting standard XFP power budgets for data center applications.

Question 14

What warranty does the OSX040N09 include?

Accepted Answer

The transceiver comes with a 1-year manufacturer’s warranty covering defects and performance issues.

Question 15

How can I troubleshoot link loss with this transceiver?

Accepted Answer

Verify proper LC connector seating, check optical power levels via DOM, and ensure fiber polarity and cleanliness.

Question 16

Where can I purchase the OSX040N09 optical transceiver?

Accepted Answer

You can buy model OSX040N09 from authorized distributors, online marketplaces, or directly from the manufacturer’s website.

	OSX040N09	OSXD50N00	QSFP-40G-CU3M	DWDM-XFP10G-1551-72	DWDM-XFP10G-1553-33
Product Type	Transceiver	Transceiver	Transceiver	Transceiver	Transceiver
Form Factor	QSFP+	QSFP	QSFP	XFP	XFP
Data Rate	40G	100G	40G	10G	10G
Connector Type	LC	LC	N/A	LC	LC
Wavelength	1310nm	1310 nm	N/A	1551 nm	1553 nm
Transmission Distance	Long-Range	Long-Range	Short-Range	Long-Range	Long-Range
Fiber Type	Single-mode	Single-mode	N/A	Single-mode	Single-mode
Max Distance	10 km	80 km	3m	80 km	80 km
Supported Protocols	Ethernet, Fiber Channel	Ethernet	Ethernet	Ethernet, Fibre Channel	Ethernet
Network Interface	Fiber	Fiber	Ethernet	Fiber	Fiber
Power Consumption	3.8W	12.5W	N/A	3.5W	N/A
Operating Temperature	0 to 70°C	0 to 70°C	0 to 70°C	0 to 70°C	0 to 70°C
Storage Temperature	-40 to 85°C	-40 to 85°C	-40 to 85°C	-40 to 85°C	-40 to 85°C
Input Voltage	3.3V	3.3V	N/A	3.3V	3.3V
Compatibility	Cisco, Juniper, Huawei, Arista	Cisco / Juniper / Huawei / Arista	Cisco / Juniper / Huawei / Arista	Cisco, Juniper, Huawei, Arista	N/A
Product Name	OSX040N09 40G QSFP+ Long-Range Transceiver	OSXD50N00 100G QSFP Long-Reach Transceiver	QSFP-40G-CU3M	DWDM-XFP10G-1551-72	DWDM-XFP10G-1553-33
Height	0.37 inches	1.0 inches	N/A	N/A	N/A
Width	0.78 inches	0.5 inches	N/A	N/A	N/A
Depth	1.0 inches	1.3 inches	N/A	N/A	N/A
Weight	0.05 lbs	0.2 lbs	N/A	N/A	N/A
