05-25699-00 Overview
05-25699-00-9305-24i - PCIe - PCIe - Mini-SAS - Low-profile - PCIe 3.0 - SATA - Aluminium - Black - Green is a high-performance storage controller expansion card designed for enterprise storage expansion and robust server enhancement. With a PCIe 3.0 interface and Mini-SAS SATA connectivity, this card delivers reliable data transfer rates and compatibility with high-demand storage systems while featuring a low-profile bracket that is ideally suited for compact workstation and server chassis.
Engineered with durability in mind, the aluminium chassis offers long-term stability and effective thermal management through passive cooling. This card is tailored for scenarios where storage expansion is critical, making it a competitive solution for modern data centers and network storage applications, while its streamlined design ensures easy integration into systems with limited space requirements.
What is the price of 05-25699-00?
Pricing for 05-25699-00 is available on request. Get immediate quote or for exclusive discounts, opt for bulk quotation for 05-25699-00.
Explore more options from Server Expansion Cards or explore other Broadcom products.
05-25699-00 Specifications
| Product Type | Expansion Card |
| Card Type | Storage Controller |
| Interface | PCIe x8 |
| PCIe Version | PCIe 3.0 |
| Chipset / Controller | N/A |
| Supported Ports | N/A |
| Port Count | N/A |
| Max Data Rate | N/A |
| RAID Levels Supported | N/A |
| Capture Resolution | N/A |
| Capture Frame Rate | N/A |
| Low Profile Bracket | Yes |
| Full Height Bracket | No |
| Cooling | Passive |
| Operating System Compatibility | N/A |
| Bus Width | 64-bit |
| Power Requirements | 3.3V |
| Use Case | Storage Expansion |
| Product Name | 05-25699-00-9305-24i - PCIe - PCIe - Mini-SAS - Low-profile - PCIe 3.0 - SATA - Aluminium - Black - Green |
| Height | N/A |
| Width | N/A |
| Depth | N/A |
| Weight | N/A |
Quality Certifications
To get the detailed certification, please go to the Compliance Center.
Product Comparison Table
|
|
|
|
|
|
|---|---|---|---|---|---|
| Bus Width | 64-bit | 64-bit | 64-bit | 64-bit | 64-bit |
| Capture Frame Rate | N/A | N/A | N/A | N/A | N/A |
| Capture Resolution | N/A | N/A | N/A | N/A | N/A |
| Card Type | Storage Controller | Storage Controller | Storage Controller | Storage Controller | RAID Controller |
| Chipset / Controller | MegaRAID CacheCade Pro 2.0 | SAS 9300-8i | N/A | N/A | LSI MegaRAID 9560-8i |
| Cooling | Passive | Passive | Passive | Passive | Passive |
| Depth | N/A | N/A | N/A | N/A | N/A |
| Full Height Bracket | Yes | Yes | No | No | Yes |
| Height | N/A | N/A | N/A | N/A | N/A |
| Interface | PCIe x8 | PCIe x8 | PCIe x8 | PCIe x4 | PCIe x8 |
| Low Profile Bracket | Yes | No | Yes | Yes | No |
| Max Data Rate | N/A | 10Gbps | N/A | N/A | N/A |
| Operating System Compatibility | Windows / Linux / VMware ESXi | Windows / Linux / VMware ESXi | N/A | Windows | Windows / Linux / VMware ESXi |
| PCIe Version | PCIe 3.0 | PCIe 3.0 | PCIe 3.0 | PCIe 3.0 | N/A |
| Port Count | N/A | 2 | N/A | N/A | 8 |
| Power Requirements | 3.3V | 3.3V | 3.3V | 3.3V | 3.3V |
| Product Name | L5-25188-04-MegaRAID CacheCade Pro 2.0 | H5-25573-00-SAS 9300-8i - PCIe - SAS,SATA - 2 x Mini SAS HD SFF8643 - Green - Grey - 2800000 h - EMC: Class B-US (CFR 47 - P15B); ICES-00; V-3/02.04; EN55022/EN55024; AS/NZS 3548; N-B… | 05-25699-00-9305-24i - PCIe - PCIe - Mini-SAS - Low-profile - PCIe 3.0 - SATA - Aluminium - Black - Green | 05-25704-00-9305-16e - PCIe - PCIe - SAS - Mini-SAS - Low-profile - PCIe 3.0 - SATA - Aluminium - Black - Green | 05-50077-01-MegaRAID 9560-8i - SAS - Serial ATA III - PCI Express x8 - 0,1,5,10,50,60,JBOD - 12 Gbit/s - DDR3 - EN55022 - EN55024 - EN60950 - EN 61000-3-2 - EN 61000-3-3; FCC Class A - Class B; UL1950; UL; CSA |
| Product Type | Expansion Card | Expansion Card | Expansion Card | Expansion Card | Expansion Card |
| RAID Levels Supported | N/A | N/A | N/A | N/A | RAID 0 / RAID 1 / RAID 5 / RAID 10 / RAID 50 / RAID 60 / JBOD |
| Supported Ports | N/A | N/A | N/A | N/A | N/A |
| Use Case | Storage Expansion | Storage Expansion | Storage Expansion | Storage Expansion | Storage Expansion |
| Weight | N/A | N/A | N/A | N/A | N/A |
| Width | N/A | N/A | N/A | N/A | N/A |
