05-25190-02 Overview
05-25190-02-MegaRAID SAS 9380-4i4e - SAS - Serial ATA - PCI Express x8 - 12 Gbit/s - 1024 MB - DDR3 - 1866 MHz is a high-performance RAID controller designed for server and storage expansion environments. This expansion card is engineered to support both SAS and Serial ATA drives through a PCI Express x8 interface, offering a robust solution for high-speed data transfers and reliable hardware RAID performance with its 1024 MB DDR3 cache memory operating at 1866 MHz.
Built with the trusted MegaRAID SAS 9380 controller, the card is optimized for efficient storage management and enterprise server enhancement. Its design caters to critical use cases such as storage expansion and server reliability, and it is compatible with popular operating systems including Windows, Linux, VMware ESXi, and FreeBSD. The card’s integrated passive cooling and full-height bracket configuration further ensure seamless installation and long-term performance in demanding server environments.
What is the price of 05-25190-02?
Pricing for 05-25190-02 is available on request. Get immediate quote or for exclusive discounts, opt for bulk quotation for 05-25190-02.
Explore more options from Server Expansion Cards or explore other Broadcom products.
05-25190-02 Specifications
| Product Type | Expansion Card |
| Card Type | RAID Controller |
| Interface | PCIe x8 |
| PCIe Version | N/A |
| Chipset / Controller | MegaRAID SAS 9380 |
| Supported Ports | N/A |
| Port Count | 8 |
| Max Data Rate | N/A |
| RAID Levels Supported | RAID 0 / RAID 1 / RAID 5 / RAID 6 / RAID 10 / RAID 50 / RAID 60 |
| Capture Resolution | N/A |
| Capture Frame Rate | N/A |
| Low Profile Bracket | No |
| Full Height Bracket | Yes |
| Cooling | Passive |
| Operating System Compatibility | Windows / Linux / VMware ESXi / FreeBSD |
| Bus Width | 64-bit |
| Power Requirements | 3.3V |
| Use Case | Storage Expansion |
| Product Name | 05-25190-02-MegaRAID SAS 9380-4i4e - SAS - Serial ATA - PCI Express x8 - 12 Gbit/s - 1024 MB - DDR3 - 1866 MHz |
| Height | N/A |
| Width | N/A |
| Depth | N/A |
| Weight | N/A |
Quality Certifications
To get the detailed certification, please go to the Compliance Center.
Product Comparison Table
|
|
|
|
|
|
|---|---|---|---|---|---|
| Bus Width | 64-bit | 64-bit | 64-bit | 64-bit | 64-bit |
| Capture Frame Rate | N/A | N/A | N/A | N/A | N/A |
| Capture Resolution | N/A | N/A | N/A | N/A | N/A |
| Card Type | RAID Controller | RAID Controller | Storage Controller | RAID Controller | Storage Controller |
| Chipset / Controller | LSI SAS 3008 | MegaRAID SAS 9361 | N/A | MegaRAID SAS 9380 | N/A |
| Cooling | Passive | Passive | Passive | Passive | Passive |
| Depth | N/A | N/A | N/A | N/A | N/A |
| Full Height Bracket | Yes | Yes | No | Yes | No |
| Height | N/A | N/A | N/A | N/A | N/A |
| Interface | PCIe x8 | PCIe x8 | PCIe x8 | PCIe x8 | PCIe x4 |
| Low Profile Bracket | No | No | Yes | No | Yes |
| Max Data Rate | N/A | N/A | N/A | N/A | N/A |
| Operating System Compatibility | Windows / Linux / VMware ESXi | Windows / Linux / VMware ESXi / FreeBSD | N/A | Windows / Linux / VMware ESXi / FreeBSD | Windows |
| PCIe Version | PCIe 3.0 | PCIe 3.0 | PCIe 3.0 | N/A | PCIe 3.0 |
| Port Count | 4 | 4 | N/A | 8 | N/A |
| Power Requirements | 3.3V | 3.3V | 3.3V | 3.3V | 3.3V |
| Product Name | 05-26105-00-MegaRAID SAS 9341-4i - SAS,Serial ATA - PCI Express x8 - 12 Gbit/s - 2800000 h - EN55022 - EN55024 - EN60950 - EN 61000-3-2 - EN 61000-3-3; FCC Class A - Class B; UL1950; UL; CSA... - 3.3 - 12 V | 05-25420-10-MegaRAID SAS 9361-4i - SAS,Serial ATA - PCI Express x8 - 12 Gbit/s - 1024 MB - DDR3 - 1866 MHz | 05-25699-00-9305-24i - PCIe - PCIe - Mini-SAS - Low-profile - PCIe 3.0 - SATA - Aluminium - Black - Green | 05-25190-02-MegaRAID SAS 9380-4i4e - SAS - Serial ATA - PCI Express x8 - 12 Gbit/s - 1024 MB - DDR3 - 1866 MHz | 05-25704-00-9305-16e - PCIe - PCIe - SAS - Mini-SAS - Low-profile - PCIe 3.0 - SATA - Aluminium - Black - Green |
| Product Type | Expansion Card | Expansion Card | Expansion Card | Expansion Card | Expansion Card |
| RAID Levels Supported | RAID 0 / RAID 1 / RAID 5 / RAID 6 / RAID 10 / RAID 50 / RAID 60 / JBOD | RAID 0 / RAID 1 / RAID 5 / RAID 6 / RAID 10 / RAID 50 / RAID 60 / JBOD | N/A | RAID 0 / RAID 1 / RAID 5 / RAID 6 / RAID 10 / RAID 50 / RAID 60 | N/A |
| Supported Ports | N/A | N/A | N/A | N/A | N/A |
| Use Case | Storage Expansion | Storage Expansion | Storage Expansion | Storage Expansion | Storage Expansion |
| Weight | N/A | N/A | N/A | N/A | N/A |
| Width | N/A | N/A | N/A | N/A | N/A |
Showing - of 0 Results
Questions & Answers
Q
What is the MegaRAID SAS 9380-4i4e?
A
The MegaRAID SAS 9380-4i4e is a high-performance LSI RAID controller card providing SAS and SATA connectivity over a PCI Express x8 interface.
Q
What interfaces does the MegaRAID SAS 9380-4i4e support?
A
It supports four internal and four external Mini-SAS HD ports for both SAS and SATA drives.
Q
What is the maximum data transfer rate of the MegaRAID SAS 9380-4i4e?
A
It delivers up to 12 Gbit/s per lane, offering high-speed data throughput across all SAS connections.
Q
How much cache memory does the MegaRAID SAS 9380-4i4e have?
A
It includes 1024 MB of onboard DDR3 cache to accelerate read and write operations.
Q
What memory type and speed does the MegaRAID SAS 9380-4i4e use?
A
The controller uses DDR3 cache memory running at 1866 MHz for low-latency buffering.
Q
What PCI Express form factor does the MegaRAID SAS 9380-4i4e require?
A
It occupies a standard PCIe x8 slot compatible with PCIe 3.0 motherboards.
Q
Can the MegaRAID SAS 9380-4i4e manage both SAS and SATA drives?
A
Yes, it supports enterprise SAS hard drives and SATA HDD/SSD in mixed-drive environments.
Q
How many drives can be connected to the MegaRAID SAS 9380-4i4e?
A
With external expanders, it can manage up to 128 SAS or SATA devices.
Q
Which RAID levels does the MegaRAID SAS 9380-4i4e support?
A
It supports RAID 0, 1, 5, 6, 10, 50 and 60 for flexible data protection strategies.
Q
Does the MegaRAID SAS 9380-4i4e offer cache protection?
A
Yes, it provides optional battery backup or supercapacitor support to safeguard write cache.
Q
What management tools are available for the MegaRAID SAS 9380-4i4e?
A
It includes the MegaRAID Storage Manager GUI and StorCLI command-line utility for full configuration and monitoring.
Q
Which operating systems are compatible with the MegaRAID SAS 9380-4i4e?
A
It is compatible with Windows Server, major Linux distributions, VMware ESXi and FreeBSD.
Q
What are the key benefits of using the MegaRAID SAS 9380-4i4e?
A
It delivers enterprise-class throughput, advanced RAID features and scalable storage management in a single card.
Q
What are the primary use cases for the MegaRAID SAS 9380-4i4e?
A
Ideal for data centers, virtualization, transactional databases and high-availability server deployments.
Q
How do I install the MegaRAID SAS 9380-4i4e in my server?
A
Power down the server, insert the card into a PCIe x8 slot, secure it, attach SAS/SATA cables and power up to configure.
Q
Where can I find firmware and driver updates for the MegaRAID SAS 9380-4i4e?
A
Visit the Broadcom support website and search for SKU 05-25190-02 to download the latest firmware and drivers.
