United States
Name:
05-25420-08
- Description:
- MegaRAID SAS 9361-8i - SAS - Serial ATA - PCI Express x8 - 12 Gbit/s - 1024 MB - DDR3 - 1866 MHz
- Rating:
-
(0)
Added to cart 33 times recently
- Availability:
-
In stock - Ready to Ship
- Brand:
- Broadcom
- Condition:
- Warranty:
-
3 - List Price:
-
- Price:
-
3 Year Extended Warranty
Same-day Shipping
14-Day Money Back Guarantee
Need Additional Discount on Product?
Request a quote below - Get Exclusive Pricing and Support.
Exclusive Bulk Discounts tailored to your order size
Priority Processing with a dedicated account manager
Fast Response: Get your custom quote within 5-10 minutes during business hours (Mon-Fri, 6:00 AM – 6:00 PM PST)
Holiday Bonus: Submissions on holidays receive priority handling the next business day
Shipping:
Payment:
Shipping as per your need
Same-day Shipping
Express Delivery Across the USA
Need it fast? Choose Express Shipping and receive your order within 1–3 business days.
Free Ground Shipping Available
Standard ground delivery across the U.S. takes 2–6 days, depending on your location — no extra charge.
International Shipments Made Simple
For all international orders, we ship via your UPS, FedEx, or DHL account — or to your U.S.-based freight forwarder.
Delivery Timelines
Under 100 KG? Ships Express.
Smaller shipments go via DHL or FedEx Express — delivered worldwide in approximately 3 business days.
Over 100 KG? Ships via Freight.
Larger orders are dispatched through freight forwarding partners. Delivery takes 7–10 business days, globally.
Always Delivered to Your Door
Every shipment is delivered directly to your address — regardless of country or carrier.
Our best-in-class warranties
3-Year Extended Warranty
Extended protection, enterprise-grade.
All enterprise hardware is backed by a 3-year warranty — triple the industry standard — covering defects under normal use.
Professional repairs & replacements.
If a hardware issue is confirmed, we’ll repair or replace the unit. Replacement parts carry either original or 3-month coverage.
RMA process, simplified.
Once an RMA is approved, return the defective unit within 10 days. We handle the rest — no service gaps.
Service Boundaries & Exclusions
What’s covered — and what’s best avoided.
Your warranty covers defects under normal use. For continued protection, avoid accidental damage, unauthorized repairs, third-party parts, or extreme environments.
Know your location’s service type.
In some regions, return-to-factory or remote service may apply. On-site service depends on infrastructure availability.
Minimal documentation required.
To initiate service, just submit the invoice and warranty card — no red tape, no waiting.
14-Day Money Back Guarantee
Free 14-Day Returns
Tested it, but it’s not a fit?
Return any product within 14 days of delivery if it doesn’t meet your technical or operational needs.
Initiate returns with ease.
Our RMA process is streamlined — just raise a request, follow the packaging guidelines, and we’ll handle the rest.
Refund or restock, your call.
Changed your mind? Get a refund (restocking fees may apply) or swap with another product.
30-Day Hardware Replacement
Covered for any early faults.
All equipment includes a 30-day replacement warranty. If something goes wrong, we’ll repair or swap it — fast.
Replacements shipped in 10 days or less.
Once your return is inspected and approved, we dispatch the replacement promptly to keep your operations moving.
RMA protocol keeps it smooth.
Just ensure all accessories and original packaging are intact — we’ll take care of the technical validation.
TRUSTED, TRIED, PROVEN
05-25420-08 Overview
05-25420-08-MegaRAID SAS 9361-8i - SAS - Serial ATA - PCI Express x8 - 12 Gbit/s - 1024 MB - DDR3 - 1866 MHz delivers enterprise-grade storage control and reliability in a robust expansion card. This storage controller features a PCI Express x8 interface built on PCIe 3.0 technology and utilizes the LSI SAS3108 chipset to manage both SAS and Serial ATA devices, providing high throughput and 12 Gbit/s port speeds with a 1024 MB DDR3 cache clocked at 1866 MHz.
Designed for storage expansion and server enhancement in demanding data center environments, the MegaRAID SAS 9361-8i supports a wide range of RAID levels including RAID 0, 1, 5, 6, 10, 50, 60, and JBOD for flexible configurations. It comes equipped with a full height bracket and a passive cooling solution, ensuring compatibility with operating systems such as Windows, Linux, and VMware ESXi for seamless integration and reliable performance.
What is the price of 05-25420-08?
Pricing for 05-25420-08 is available on request. Get immediate quote or for exclusive discounts, opt for bulk quotation for 05-25420-08.
Explore more options from Server Expansion Cards or explore other Broadcom products.
05-25420-08 Specifications
| Product Type | Expansion Card |
| Card Type | Storage Controller |
| Interface | PCIe x8 |
| PCIe Version | PCIe 3.0 |
| Chipset / Controller | LSI SAS3108 |
| Supported Ports | N/A |
| Port Count | 8 |
| Max Data Rate | N/A |
| RAID Levels Supported | RAID 0 / RAID 1 / RAID 5 / RAID 6 / RAID 10 / RAID 50 / RAID 60 / JBOD |
| Capture Resolution | N/A |
| Capture Frame Rate | N/A |
| Low Profile Bracket | No |
| Full Height Bracket | Yes |
| Cooling | Passive |
| Operating System Compatibility | Windows / Linux / VMware ESXi |
| Bus Width | 64-bit |
| Power Requirements | 3.3V |
| Use Case | Storage Expansion |
| Product Name | 05-25420-08-MegaRAID SAS 9361-8i - SAS - Serial ATA - PCI Express x8 - 12 Gbit/s - 1024 MB - DDR3 - 1866 MHz |
| Height | 1.73 inches |
| Width | 9.5 inches |
| Depth | 7.1 inches |
| Weight | 1.3 lbs |
Quality Certifications
To get the detailed certification, please go to the Compliance Center.
Product Comparison Table
|
|
|
|
|
|
|---|---|---|---|---|---|
| Bus Width | N/A | 64-bit | N/A | 64-bit | 64-bit |
| Capture Frame Rate | N/A | N/A | N/A | N/A | N/A |
| Capture Resolution | N/A | N/A | N/A | N/A | N/A |
| Card Type | Storage Controller | Storage Controller | RAID Controller | RAID Controller | RAID Controller |
| Chipset / Controller | N/A | LSI SAS3108 | LSI SAS 3108 | MegaRAID SAS 9380 | LSI MegaRAID 9560-8i |
| Cooling | Passive | Passive | Passive | Passive | Passive |
| Depth | N/A | 7.1 inches | N/A | N/A | N/A |
| Full Height Bracket | No | Yes | Yes | Yes | Yes |
| Height | N/A | 1.73 inches | N/A | N/A | N/A |
| Interface | PCIe x16 | PCIe x8 | PCIe x8 | PCIe x8 | PCIe x8 |
| Low Profile Bracket | Yes | No | No | No | No |
| Max Data Rate | N/A | N/A | N/A | N/A | N/A |
| Operating System Compatibility | N/A | Windows / Linux / VMware ESXi | Windows / Linux / VMware ESXi | Windows / Linux / VMware ESXi | Windows / Linux / VMware ESXi |
| PCIe Version | PCIe 3.0 | PCIe 3.0 | PCIe 3.0 | PCIe 3.0 | N/A |
| Port Count | N/A | 8 | 8 | 8 | 8 |
| Power Requirements | N/A | 3.3V | 3.3V | 3.3V | 3.3V |
| Product Name | 05-50044-00-9405W-16e - PCIe - SAS,SATA - Low-profile - PCIe 3.1 - Passive - 4500000 h | 05-25420-08-MegaRAID SAS 9361-8i - SAS - Serial ATA - PCI Express x8 - 12 Gbit/s - 1024 MB - DDR3 - 1866 MHz | 05-25420-17-MegaRAID SAS 9361-8i (2G) - SAS - Serial ATA - PCI Express x8 - 12 Gbit/s - 2048 MB - DDR3 - 1866 MHz | 05-25528-04-MegaRAID SAS 9380-8e SGL 8-Port Int, 12Gb/s SATA+SAS - Serial Attached SCSI (SAS) | 05-50077-01-MegaRAID 9560-8i - SAS - Serial ATA III - PCI Express x8 - 0,1,5,10,50,60,JBOD - 12 Gbit/s - DDR3 - EN55022 - EN55024 - EN60950 - EN 61000-3-2 - EN 61000-3-3; FCC Class A - Class B; UL1950; UL; CSA |
| Product Type | Expansion Card | Expansion Card | Expansion Card | Expansion Card | Expansion Card |
| RAID Levels Supported | N/A | RAID 0 / RAID 1 / RAID 5 / RAID 6 / RAID 10 / RAID 50 / RAID 60 / JBOD | RAID 0 / RAID 1 / RAID 5 / RAID 6 / RAID 10 / RAID 50 / RAID 60 / JBOD | RAID 0 / RAID 1 / RAID 5 / RAID 6 / RAID 10 / RAID 50 / RAID 60 / JBOD | RAID 0 / RAID 1 / RAID 5 / RAID 10 / RAID 50 / RAID 60 / JBOD |
| Supported Ports | N/A | N/A | N/A | N/A | N/A |
| Use Case | Storage Expansion | Storage Expansion | Storage Expansion | Storage Expansion | Storage Expansion |
| Weight | N/A | 1.3 lbs | N/A | N/A | N/A |
| Width | N/A | 9.5 inches | N/A | N/A | N/A |
Showing - of 0 Results
Questions & Answers
Q
What is the MegaRAID SAS 9361-8i (SKU: 05-25420-08)?
A
The MegaRAID SAS 9361-8i is a high-performance RAID controller card featuring eight internal SAS/SATA ports, PCIe 3.0 x8 connectivity and 1 GB DDR3 cache for enterprise storage acceleration.
Q
Which RAID levels does the MegaRAID SAS 9361-8i support?
A
It supports RAID 0, 1, 5, 6, 10, 50 and 60, enabling flexible data protection and performance optimization for mixed workloads.
Q
What host interface does the 9361-8i use?
A
The controller uses a PCI Express 3.0 x8 interface to deliver up to 6.4 GB/s of host bandwidth.
Q
Which drive types are compatible with this RAID controller?
A
It is compatible with 12 Gbit/s SAS drives and 6 Gbit/s SATA drives, including HDDs and SSDs.
Q
How much cache memory does the MegaRAID SAS 9361-8i have?
A
It features 1 GB of DDR3-1866 cache memory to accelerate read/write operations and improve I/O performance.
Q
Does the 9361-8i support battery or flash backup?
A
It supports the optional CacheVault flash module, which secures cached data without a battery and ensures data integrity during power loss.
Q
Can I connect external drive enclosures to this controller?
A
No, the 9361-8i provides only internal mini-SAS SFF-8643 connectors; external expansion requires a different MegaRAID model with external ports.
Q
Which operating systems are supported?
A
It is supported on Windows Server, Linux, VMware ESXi, VMware vSAN, and various Unix distributions with drivers from Broadcom.
Q
Is hot-plug drive support available?
A
Yes. The controller fully supports hot-plugging of SAS and SATA drives when used with a compatible backplane or chassis.
Q
How do I install and configure the MegaRAID SAS 9361-8i?
A
Insert the card into a free PCIe x8 slot, connect your drive cables, power on, then configure arrays using the MegaRAID BIOS Configuration Utility or MegaRAID Storage Manager.
Q
What peak throughput can this RAID controller deliver?
A
With 12 Gbit/s per port and PCIe 3.0 x8 host I/O, it can deliver up to 6.4 GB/s aggregate throughput under optimal conditions.
Q
Does the 9361-8i support JBOD (pass-through) mode?
A
Yes. It offers IT (passthrough) firmware for direct drive access when used as a host bus adapter (HBA) rather than RAID.
Q
Can I update firmware on this system?
A
Yes. Firmware and driver updates are provided by Broadcom and can be applied via MegaRAID Storage Manager or command-line tools.
Q
What management tools are available?
A
Use MegaRAID Storage Manager for GUI-based monitoring, MegaCLI or storcli for command-line control, and SNMP for integration with enterprise monitoring systems.
Q
What are the common use cases for the MegaRAID SAS 9361-8i?
A
Ideal for database acceleration, virtualization hosts, high-performance file servers and mixed read/write enterprise workloads requiring robust RAID protection.
Q
What warranty and support options are offered?
A
Broadcom offers a five-year limited warranty with optional advanced replacement and 24/7 phone and online technical support.
