DS-2DY9236X-A Overview
DS-2DY9236X-A is an advanced bullet IP camera offering 1080p resolution with a motorized lens design that ensures precise zoom and focus adjustments. Equipped with a high-performance 1/2.8" CMOS sensor, the camera captures clear, detailed video while utilizing H.265 compression and True Day/Night (ICR) mode for reliable performance in varying lighting conditions. It also supports 2-Way Audio and features PoE connectivity for streamlined installation and integration.
Designed for diverse security needs—including indoor retail, perimeter defense, license plate recognition, and warehouse surveillance—DS-2DY9236X-A delivers robust IR night vision up to a 30m range. Its weather-resistant IP66 rating and ONVIF compliance guarantee dependable operation in challenging outdoor environments and critical security applications.
DS-2DY9236X-A price is is available on request. Get immediate quote.
Request bulk order quote for DS-2DY9236X-A for additional pricing. Browse the full Hikvision Special Series Ptz series or explore all Hikvision products.
DS-2DY9236X-A Specifications
- Product Type
- Security Camera
- Camera Type
- Bullet
- Technology
- IP Camera
- Resolution
- 1080p
- Lens Type
- Motorized
- Smart Features
- ANPR
- Mounting Type
- Wall
- Color
- Black
- Use Case
- Perimeter Protection
- Focal Length
- 2.7–13.5mm
- Image Sensor
- 1/2.8" CMOS
- Frame Rate
- 30 FPS
- Infrared Night Vision
- 30m
- Low Light Technology
- Starlight
- Day/Night Mode
- True Day/Night (ICR)
- Video Compression
- H.265
- Audio Support
- 2-Way Audio
- Storage Option
- MicroSD Slot
- Max Storage Capacity
- 128 GB
- Power Type
- PoE
- Weather Rating
- IP66
- Vandal Resistance
- IK10
- ONVIF Compliant
- Yes
- Product Name
- DS-2DY9236X-A HD Outdoor Bullet Camera
- Height
- 4.3 inches
- Width
- 3.5 inches
- Depth
- 3 inches
- Weight
- 2.2 lbs
Quality Certifications
To get the detailed certification, please go to the Compliance Center.
Product Comparison Table
| DS-2DY9236X-A |  DS-2DY9250X-A |  DS-2DY7236IW |  DS-2DY9236IX-A |  DS-2DY9236I8X-A | |
|---|---|---|---|---|---|
| Product Type | Security Camera | Security Camera | Security Camera | Security Camera | Security Camera |
| Camera Type | Bullet | Turret | Turret | Bullet | Bullet |
| Technology | IP Camera | IP Camera | IP Camera | IP Camera | IP Camera |
| Resolution | 1080p | 1080p | 4MP | 4MP | 4MP |
| Lens Type | Motorized | Varifocal | Varifocal | Fixed | Varifocal |
| Smart Features | ANPR | N/A | Motion Detection | Motion Detection | Motion Detection / ANPR |
| Mounting Type | Wall | N/A | Ceiling | Wall | Wall |
| Color | Black | N/A | Black | Black | Black |
| Use Case | Perimeter Protection | Retail | Indoor / Retail / Perimeter Protection / Warehouse | Retail | Retail |
| Focal Length | 2.7–13.5mm | 2.7–13.5mm | 2.7–13.5mm | 4mm | 2.7–13.5mm |
| Image Sensor | 1/2.8" CMOS | 1/2.8" CMOS | 1/2.8" CMOS | 1/2.8" CMOS | 1/2.8" CMOS |
| Frame Rate | 30 FPS | 30 FPS | 30 FPS | 30 FPS | 30 FPS |
| Infrared Night Vision | 30m | 30m | 30m | 30m | 30m |
| Low Light Technology | Starlight | EXIR | Starlight | EXIR | EXIR |
| Day/Night Mode | True Day/Night (ICR) | True Day/Night (ICR) | True Day/Night (ICR) | True Day/Night (ICR) | True Day/Night (ICR) |
| Video Compression | H.265 | H.265+ | H.265 | H.265 | H.265+ |
| Audio Support | 2-Way Audio | 2-Way Audio | 2-Way Audio | 2-Way Audio | Audio Input |
| Storage Option | MicroSD Slot | MicroSD Slot | MicroSD Slot | MicroSD Slot | MicroSD Slot |
| Max Storage Capacity | 128 GB | 256 GB | 128 GB | 128 GB | 128 GB |
| Power Type | PoE | PoE | PoE | PoE | PoE |
| Weather Rating | IP66 | IP67 | IP67 | IP67 | IP67 |
| Vandal Resistance | IK10 | None | N/A | None | N/A |
| ONVIF Compliant | Yes | Yes | Yes | Yes | Yes |
| Product Name | DS-2DY9236X-A HD Outdoor Bullet Camera | DS-2DY9250X-A | DS-2DY7236IW | DS-2DY9236IX-A | DS-2DY9236I8X-A |
| Height | 4.3 inches | 4.5 inches | 3.5 inches | 3.5 inches | 4.5 inches |
| Width | 3.5 inches | 3.0 inches | 2.8 inches | 2.8 inches | 3.1 inches |
| Depth | 3 inches | 3.5 inches | 2.6 inches | 2.5 inches | 3.1 inches |
| Weight | 2.2 lbs | 1.2 lbs | 1.9 lbs | 1.2 lbs | 1.3 lbs |
Reviews & Ratings
N
Naveed Akhtar
5
Smooth PTZ movement and reliable night mode.
O
Olivier Martin
5
Consistent performance for outdoor monitoring.
P
Parvez Alam
4
Handles wide coverage areas well.
Q
Quinton Hayes
5
Professional-grade positioning system.
Questions & Answers
What is the video resolution and sensor type of the DS-2DY9236X-A?
The DS-2DY9236X-A features a 2 MP progressive scan CMOS sensor, delivering 1920 × 1080 HD video at real-time frame rates.
What are the optical and digital zoom capabilities of this network positioning system?
It offers 36× optical zoom and up to 16× digital zoom for detailed long-distance monitoring and identification.
How does DarkFighter technology enhance low-light performance?
DarkFighter ensures full-color imaging down to 0.001 lux, black-and-white imaging to 0.0001 lux, and up to 200 m of IR illumination.
Which video compression formats are supported to optimize bandwidth?
It supports H.265, H.264, and MJPEG codecs, reducing bandwidth and storage requirements by up to 50% without compromising image quality.
Does the DS-2DY9236X-A support smart auto-tracking?
Yes. Built-in Smart Tracking 3.0 automatically locks onto moving targets and maintains focus even at high zoom levels.
What network protocols and third-party integrations are available?
It is ONVIF Profile S/G compliant and supports RTSP, HTTP, TCP/IP, and Hikvision SDK for seamless integration with VMS platforms.
What is the size and resolution of the integrated display?
The system includes a 9-inch touchscreen display with 1280 × 720 resolution for local monitoring and on-site configuration.
What are the environmental and ingress protection ratings?
Rated IP66 for dust/water resistance and IK10 for impact protection, it operates reliably from –40 °C to +60 °C.
How is the DS-2DY9236X-A powered?
Power options include DC 24 V ± 25% and PoE+ (802.3at), with a maximum power consumption of 30 W.
How many presets and patrol patterns can be configured?
It supports up to 300 presets, 8 auto cruises, 4 pattern scans, and 4 tour sequences for comprehensive area coverage.
What are the pan and tilt speed specifications?
Pan speed ranges from 0.1° to 100°/s and tilt from 0.1° to 60°/s, enabling precise and rapid repositioning.
Does this system offer wide dynamic range (WDR)?
Yes. It features 120 dB true WDR to balance light and dark areas, ensuring clear images in high-contrast scenes.
What local storage options are supported?
It accepts a microSD/SDHC/SDXC card up to 256 GB for onboard recording without requiring an external NVR.
What applications are ideal for the DS-2DY9236X-A?
Ideal for outdoor surveillance in airports, ports, highways, critical infrastructure, public venues, and border/security checkpoints.
How can I mount and install the DS-2DY9236X-A?
It supports ceiling, wall, and pole mounting with standard brackets and features an adjustable gimbal for flexible orientation.
