Q
What is an HPE Server M.2 & PCIe hard drive?
A
An HPE Server M.2 & PCIe hard drive is a high-performance solid-state storage device designed for HPE ProLiant servers, offering NVMe or SATA interfaces in M.2 or PCIe form factors for improved I/O throughput.
Q
Which HPE server models support M.2 & PCIe hard drives?
A
HPE ProLiant Gen10 and Gen11 servers support M.2 & PCIe NVMe drives through onboard connectors or optional NVMe adapters, as detailed in each model’s QuickSpecs.
Q
How do I install an HPE M.2 NVMe drive in my server?
A
Power down the server, open the chassis, insert the M.2 NVMe SSD into the onboard M.2 slot at a 30° angle, secure it with the mounting screw, close the chassis, and power up.
Q
What performance benefits do PCIe NVMe drives offer versus SATA?
A
PCIe NVMe drives deliver up to 6× higher bandwidth and 5× lower latency than SATA SSDs, accelerating databases, virtualization, and mission-critical workloads.
Q
What capacity options are available for HPE Server M.2 & PCIe SSDs?
A
HPE offers M.2 and PCIe NVMe SSDs in capacities ranging from 240 GB up to 7.68 TB to suit boot, caching, and high-density data applications.
Q
Do HPE M.2 & PCIe drives support hardware-based encryption?
A
Yes, HPE NVMe SSDs support AES-256 self-encrypting drive (SED) technology and TCG Opal 2.0 for secure data-at-rest protection.
Q
Can I hot-swap an HPE PCIe NVMe drive?
A
Hot-swap support depends on your server’s drive cage or NVMe backplane; refer to your ProLiant server’s service guide for hot-plug capabilities.
Q
What warranty and MTBF do HPE M.2 & PCIe SSDs have?
A
HPE NVMe SSDs carry a three-year limited warranty with a mean time between failures (MTBF) of up to 2 million hours.
Q
How do I update firmware on an HPE PCIe NVMe drive?
A
Use HPE Smart Update Manager or HPE Service Pack for ProLiant (SPP) to detect and apply validated firmware updates to PCIe NVMe SSDs.
Q
Are HPE Server M.2 & PCIe drives compatible with RAID controllers?
A
HPE PCIe NVMe SSDs are supported in NVMe-direct attach configurations and select HPE Smart Array controllers with NVMe passthrough mode.
Q
What operating temperature range do these SSDs support?
A
HPE M.2 and PCIe NVMe drives operate reliably between 0 °C and 70 °C ambient temperature in server environments.
Q
How do I troubleshoot an unrecognized M.2 drive?
A
Verify BIOS NVMe support is enabled, reseat the drive, update system firmware, and confirm the M.2 slot is not reserved for RAID only.
Q
Can I use an M.2 NVMe drive as a boot volume on HPE servers?
A
Yes, you can configure an M.2 NVMe SSD as a boot device by enabling NVMe boot support in the system BIOS and installing your OS on the drive.
Q
What power requirements do PCIe NVMe SSDs have?
A
HPE PCIe NVMe SSDs draw up to 25 W peak; ensure your server’s power supplies and backplane meet NVMe power-budget specifications.
Q
How do I optimize these drives for data-intensive applications?
A
Enable NVMe multisession queues, use HPE Persistent Memory if available, update to the latest firmware, and configure OS-level write caching for peak I/O.
Q
Are HPE M.2 & PCIe SSDs covered by ProLiant support?
A
Yes, HPE Server M.2 and PCIe NVMe SSDs are integrated into ProLiant support contracts and covered under HPE’s global hardware warranty and service offerings.
