What RAID levels are available on the ThinkSystem RAID 930-16i?

It supports RAID 0, 1, 5, 6, 10, 50, and 60, plus Single Disk and JBOD modes for flexible array configurations.

How does the flash-backed cache improve performance?

The flash-backed cache captures write operations in DRAM and commits them to flash on power loss, delivering consistent low-latency performance and data integrity.

What is the maximum throughput of the RAID 930-16i card?

It delivers up to 12 Gb/s per SAS lane and saturates a PCIe 3.0 x8 host interface for aggregate throughput up to 7.88 GB/s.

Which operating systems does the RAID 930-16i support?

It is supported on Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware ESXi, and other major enterprise OSes with Lenovo-provided drivers.

How do I install the RAID 930-16i adapter?

Power down the server, insert the card into an available PCIe 3.0 x8 or higher slot, secure the bracket, and install Lenovo’s RAID management drivers and utilities.

What management tools are available for this RAID adapter?

You can manage arrays using Lenovo XClarity Controller, MegaRAID Storage Manager, and command-line utilities for monitoring, configuration, and firmware updates.

Can I update the firmware on the RAID 930-16i?

Yes, firmware can be updated via Lenovo XClarity, UEFI diagnostics, or the MegaRAID CLI to ensure security and feature updates.

What are the key benefits of using RAID 930-16i in a data center?

It delivers high I/O throughput, advanced RAID protection, nonvolatile write cache, and enterprise-class reliability in a single low-profile PCIe form factor.

Does the RAID 930-16i support SSD caching or tiering?

Yes, the adapter supports SSD caching and automated tiering when paired with Lenovo’s storage software solutions to optimize hot- and cold-data placement.

What is the typical power consumption of the RAID 930-16i?

Under typical load, the adapter consumes approximately 7.5 W, with peak power draw around 10 W, depending on workload and cache activity.

What warranty covers the Lenovo ThinkSystem RAID 930-16i?

The RAID 930-16i is covered by Lenovo’s 3-year limited warranty with optional extension and Premier Support upgrades for on-site service.

Are replacement parts or upgrade kits available for this adapter?

Lenovo offers spare parts kits including cache backup batteries and replacement adapters via the Lenovo Parts Store using the SKU: 7Y37A01085.

FEATURED DEAL

Name:

Lenovo 7Y37A01085 RAID 930-16i

Name: Lenovo ThinkSystem RAID 930-16i 4GB Flash PCIe 12Gb Adapter
Brand: Lenovo
SKU: Lenovo 7Y37A01085 RAID 930-16i
Rating: 4.2 (5 reviews)

Description:: Lenovo ThinkSystem RAID 930-16i 4GB Flash PCIe 12Gb Adapter
Rating:: 4.2(5)
Added to cart 28 times recently
Availability:: In stock - Ready to Ship
Brand:: Lenovo
GTIN:: 7436346433487
Condition:

Get a Quote

3 Year Extended Warranty

Same-day Shipping

14-Day Money Back Guarantee

Shipping:

Payment:

lenovo 7y37a01085 raid 930-16i lenovo thinksystem raid 930-16i 4gb flash pcie 12gb adapter

3 Year Extended Warranty

Same-day Shipping

14-Day Money Back Guarantee

Need Additional Discount on Product?

Request a quote below - Get Exclusive Pricing and Support.

Shipping:

Payment:

Lenovo 7Y37A01085 RAID 930-16i

Lenovo ThinkSystem RAID 930-16i 4GB Flash PCIe 12Gb Adapter

TRUSTED, TRIED, PROVEN

$5,000,000+

Inventory Delivered By

Officially Accredited

& Verified By

Next-Gen IT

Solutions Powered By

Lenovo 7Y37A01085 RAID 930-16i Overview

Lenovo 7Y37A01085 RAID 930-16i is a high-performance RAID controller designed for enterprise storage solutions. Built as an internal PCIe card, this SAS RAID controller delivers reliable data management for servers while ensuring robust compatibility with leading operating systems such as Windows, Linux, and VMware.

Lenovo 7Y37A01085 RAID 930-16i features a PCIe connection interface and supports SAS protocols to provide optimized storage performance and data integrity. Its compact form factor makes it ideal for data centers and high-availability environments where seamless integration and efficient RAID levels (0, 1, 5, 10) are required.

Lenovo 7Y37A01085 RAID 930-16i price is is available on request. Get immediate quote.

Request bulk order quote for Lenovo 7Y37A01085 RAID 930-16i for additional pricing. Browse the full Lenovo Server Network Adapters series or explore all Lenovo products.

Lenovo 7Y37A01085 RAID 930-16i Specifications

Product Type: RAID Controller
Adapter Type: SAS RAID Controller
Data Rate: N/A
Connection Interface: PCIe
Supported Protocols: SAS
Form Factor: Internal PCIe Card
Operating Temperature: 0 to 70°C
Storage Temperature: N/A
Input Voltage: N/A
Compatibility: Windows / Linux / VMware
Max Speed: N/A
Supported Features: RAID 0, RAID 1, RAID 5, RAID 10
Power Consumption: N/A
Connector Type: SAS/SATA
Maximum Range: N/A
Bus Type: PCIe x8
Product Name: Lenovo 7Y37A01085 RAID 930-16i
Height: N/A
Width: N/A
Depth: N/A
Weight: N/A

Quality Certifications

To get the detailed certification, please go to the Compliance Center.

Product Comparison Table

	Lenovo 7Y37A01085 RAID 930-16i	Lenovo 7Y37A01083 RAID 730-8i	Lenovo 7Y37A01088 RAID 430-8i	Lenovo 7Y37A01084 RAID 930-8i	Lenovo 7Y37A01090 RAID 430-8e
Product Type	RAID Controller	RAID Controller	RAID Controller	RAID Controller	RAID Controller
Adapter Type	SAS RAID Controller	RAID Controller	Internal RAID Adapter	SAS RAID Controller	RAID
Data Rate	N/A	6Gbps	SAS 12Gb/s	6Gbps	6Gbps per port
Connection Interface	PCIe	PCIe 2.0 x8	PCIe	PCIe 2.0 x8	PCIe x8
Supported Protocols	SAS	SATA / SAS	RAID 0 / RAID 1 / RAID 5 / RAID 10	SAS, SATA	SATA, SAS
Form Factor	Internal PCIe Card	Internal PCIe Card	Internal PCIe Card	Internal PCIe Card	Internal PCIe Card
Operating Temperature	0 to 70°C	0 to 70°C	0 to 70°C	0 to 70°C	0 to 70°C
Storage Temperature	N/A	-40 to 85°C	-40 to 85°C	-40 to 85°C	-40 to 85°C
Input Voltage	N/A	3.3V	3.3V	3.3V/5V	12V
Compatibility	Windows / Linux / VMware	Windows / Linux / VMware / Hyper-V	Windows / Linux / VMware / Hyper-V	Windows, Linux	Windows, Linux, VMware
Max Speed	N/A	6Gb/s per port	N/A	6Gbps per port	6Gbps per port
Supported Features	RAID 0, RAID 1, RAID 5, RAID 10	RAID 0, RAID 1, RAID 10, RAID 5, RAID 50, Hot Spare, Advanced Data Protection	Hot-swap, Cache Management, Multi-Bus Interface	RAID 0, 1, 5, 10; Hot Spare; Online Capacity Expansion; Advanced Data Protection	RAID 0, RAID 1, RAID 10, RAID 5, RAID 50, auto-rebuild, hot spare
Power Consumption	N/A	N/A	N/A	N/A	10W
Connector Type	SAS/SATA	SAS	SAS/SATA	SFF-8088	Mini-SAS HD (SFF-8643)
Maximum Range	N/A	N/A	N/A	N/A	N/A
Bus Type	PCIe x8	PCIe x8	PCIe x8	PCIe x8	PCIe
Product Name	Lenovo 7Y37A01085 RAID 930-16i	Lenovo 7Y37A01083 RAID 730-8i	Lenovo 7Y37A01088 RAID 430-8i	Lenovo 7Y37A01084 RAID 930-8i	Lenovo 7Y37A01090 RAID 430-8e
Height	N/A	N/A	N/A	N/A	N/A
Width	N/A	N/A	N/A	N/A	N/A
Depth	N/A	N/A	N/A	N/A	N/A
Weight	N/A	N/A	N/A	N/A	N/A

Reviews & Ratings

Dylan Armstrong

High performance RAID card handled large arrays efficiently.

Sadia Malik

Excellent controller for demanding storage workloads.

George Nolan

Improved RAID performance significantly.

Usaid Mehmood

Stable under heavy I O usage.

Trevor Scott

Enterprise grade RAID solution.

Questions & Answers

What is the Lenovo ThinkSystem RAID 930-16i (SKU: 7Y37A01085)?

The Lenovo ThinkSystem RAID 930-16i (SKU:7Y37A01085) is a 12 Gb/s PCIe SAS RAID adapter with 16 internal ports and 4 GB of flash-backed write cache, designed for enterprise storage performance and reliability.

Which servers are compatible with the RAID 930-16i adapter?

The RAID 930-16i is validated for Lenovo ThinkSystem SR, ST, and SD series servers and selected ThinkSystem blade enclosures supporting PCIe 3.0 slots.

What types of drives does the RAID 930-16i support?

It supports SAS and SATA HDDs/SSDs up to 12 Gb/s and NVMe drives via host-initiated passthrough when used with Lenovo NVMe-ready bays.

How much cache memory does the adapter include?

It includes 4 GB of flash-backed cache (FBWC) to safeguard write data in case of power loss and accelerate random writes.
