TL-EDLA75-100

TE30-1080P-10B Specification

Standards and Protocols

ITU-T H.323, IETF SIP, ITU-T H.239, and BFCP

Video Standards and Protocols

H.263, H.263+, H.264 BP, H.264 HP, H.264 SVC, RTV

People Video Resolution

1080p30 from 512 kbit/s (optional)
720p50/60 from 512 kbit/s (optional)
720p25/30 from 384 kbit/s
4SIF/4CIF from 128 kbit/s
SIF/CIF/QSIF/QCIF/SQSIF/SQCIF from 64 kbit/s

Dual Stream

1080p30 + 1080p5 (optional); dual 720p30

Video Inputs

1 x VGA, 1 x built-in camera

Video Outputs

1 x VGA/YPbPr, 1 x HDMI

Audio Inputs

1 x 3.5 mm line-in jack, 1 x HD-AI (stereo, connects to a microphone array)

Audio Outputs

1 x 3.5 mm line-out jack, 1 x HDMI

Other Ports

IP: 10/100 Base-T, 1 x RJ45

Wireless: built-in Wi-Fi

Bandwidth

IP: 64 kbit/s to 8 Mbit/s

Pack Weight(kg)

4.7

Pack Volume(m^3)

0.019306

Pack Dimension(D*W*H mm)

402*232*237

Net Dimension(D*W*H mm)

235*163*157

Typic Power(W)

34
