WS-C3560X-24T-E Overview
WS-C3560X-24T-E is a high-performance, fixed-configuration Cisco Catalyst switch built with a robust Layer 2/Layer 3 architecture. It offers 24 dedicated 10/100/1000 Ethernet ports along with 4 1G SFP uplink ports, delivering reliable connectivity and seamless integration into enterprise networks.
The switch is equipped with an efficient AC power supply and supports FlexStack-Plus stacking, which enhances scalability and network resiliency. Designed for demanding access layer deployments, WS-C3560X-24T-E is ideally suited for branch offices, campus aggregations, and data center edge applications where performance and future growth are critical.
WS-C3560X-24T-E price is is available on request. Get immediate quote.
Request bulk order quote for WS-C3560X-24T-E for additional pricing. Browse the full Catalyst 3560-X series or explore all Cisco products.
WS-C3560X-24T-E Specifications
- Product Type
- Switch
- Power Source
- AC Power Supply
- Layer Supported
- Layer 2 / Layer 3
- Form Factor
- Rack-mount
- Manageable
- Managed
- Ethernet Technology
- 10/100/1000
- Media Type Supported
- Twisted Pair
- Redundant Power Supply Supported
- No
- Uplink Configuration
- 1G
- IOS
- LAN Base
- POE Support
- Non POE
- SFP Ports
- 4 SFP Ports
- Memory
- 256 MB
- Rack Units
- 1 RU
- Interface Ports
- 10/100/1000
- Switching Capacity with Stacking
- 160 Gbps
- Height
- 1.73 inches
- Number of Ethernet Ports
- 12–24 Ports
- Flash Memory
- 128 MB
- Switching Capacity
- 128 Gbps
- Power Consumption
- 110W
- Number of Downlink Ports
- N/A
- Manufacturer Part Number
- WS-C3560X-24T-E
- Port/Expansion Slot Details
- 24 Ethernet 10/100/1000 ports and 4 1G SFP uplink ports
- Product Name
- Cisco Catalyst 3560X-24T-E
- Width
- 17.06 inches
- Depth
- 12.28 inches
- Weight
- 16.5 lbs
WS-C3560X-24T-E Use Case
Secure Enterprise Campus Access with WS-C3560X-24T-E 24-Port Data IP Services
In a global corporate campus deploying hundreds of wired endpoints, IT teams use the Catalyst 3560X WS-C3560X-24T-E to enforce 802.1X identity-based authentication and dynamic VLAN assignment across all 24 GbE ports. This setup delivers granular user-level access control, reduces unauthorized access incidents by 85%, and simplifies compliance with data security regulations.
High-Availability Branch Office Aggregation and Layer 3 Routing
A distributed retail chain consolidates voice, point-of-sale, and back-office traffic at each branch using the Catalyst 3560X 24-port WS-C3560X-24T-E. Leveraging IP Services-level OSPF/EIGRP routing, HSRP redundancy, and optional RPS support, the solution maintains sub-second failover and 99.99% uptime. The outcome is uninterrupted transactions, centralized management, and a 40% reduction in branch IT support calls.
Converged Video and Data Delivery with Advanced QoS
In a higher-education campus, network architects deploy WS-C3560X-24T-E switches in building distribution closets to support high-definition lecture capture, VoIP phones, and student workstations. Using IP Services QoS, multicast routing, and IGMP snooping on all 24 ports, the solution guarantees jitter-free video streaming and voice clarity, improving end-user experience and boosting classroom engagement by 30%.
Quality Certifications
To get the detailed certification, please go to the Compliance Center.
Product Comparison Table
| WS-C3560X-24T-E |  WS-C3560X-24U-L |  WS-C3560X-24T-S |  WS-C3560X-24U-S |  WS-C3560X-24P-L | |
|---|---|---|---|---|---|
| Depth | 12.28 inches | 11.02 inches | 11.5 inches | 11.2 inches | 11.1 inches |
| Ethernet Technology | 10/100/1000 | 10/100/1000 | 10/100/1000 | 10/100/1000 | 10/100/1000 |
| Flash Memory | 128 MB | 64 MB | 256 MB | 64 MB | 64 MB |
| Form Factor | Rack-mount | Rack-mount | Rack-mount | Rack-mount | Rack-mount |
| Height | 1.73 inches | 1.73 inches | 1.73 inches | 1.73 inches | 1.73 inches |
| IOS | LAN Base | LAN Base | LAN Base | LAN Base | LAN Base |
| Interface Ports | 10/100/1000 | 10/100/1000 | 10/100/1000 | 10/100/1000 | 10/100/1000 |
| Layer Supported | Layer 2 / Layer 3 | Layer 2 | Layer 2 / Layer 3 | Layer 2 / Layer 3 | Layer 3 |
| Manageable | Managed | Managed | Managed | Managed | Managed |
| Manufacturer Part Number | WS-C3560X-24T-E | WS-C3560X-24U-L | WS-C3560X-24T-S | WS-C3560X-24U-S | WS-C3560X-24P-L |
| Media Type Supported | Twisted Pair | Twisted Pair / Fiber | Twisted Pair | Twisted Pair | Twisted Pair / Fiber / Combo |
| Memory | 256 MB | 256 MB | 512 MB | 256 MB | 256 MB |
| Number of Downlink Ports | N/A | 24 Ports | 24 Ports | 24 Ports | 24 Ports |
| Number of Ethernet Ports | 12–24 Ports | 12–24 Ports | 12–24 Ports | 24–48 Ports | 12–24 Ports |
| POE Support | Non POE | Non POE | Non POE | Non POE | POE+ |
| Port/Expansion Slot Details | 24 Ethernet 10/100/1000 ports and 4 1G SFP uplink ports | 24 Ethernet ports and 4 fixed 1G SFP uplink ports | 24 10/100/1000 ports and 4 1G SFP uplink ports | 24 x 10/100/1000 Ethernet ports, 4 x 1G SFP uplink ports | 24 x 10/100/1000 PoE ports, 4 x 1G SFP uplink ports |
| Power Consumption | 110W | N/A | 215 W | 355W | 370 W |
| Power Source | AC Power Supply | AC Power Supply | AC Power Supply | AC Power Supply | AC Power Supply |
| Product Name | Cisco Catalyst 3560X-24T-E | Cisco Catalyst 3560-X 24 Port Switch (WS-C3560X-24U-L) | Cisco Catalyst 3560-X 24-Port Stackable Layer 3 Switch | Cisco Catalyst WS-C3560X-24U-S | Cisco Catalyst 3560-X 24 Port PoE Switch with LAN Base |
| Product Type | Switch | Switch | Switch | Switch | Switch |
| Rack Units | 1 RU | 1 RU | 1 RU | 1 RU | 1 RU |
| Redundant Power Supply Supported | No | No | No | No | No |
| SFP Ports | 4 SFP Ports | 4 SFP Ports | 4 SFP Ports | 4 SFP Ports | 4 SFP Ports |
| Switching Capacity | 128 Gbps | 128 Gbps | 128 Gbps | 160 Gbps | 128 Gbps |
| Switching Capacity with Stacking | 160 Gbps | 256 Gbps | 160 Gbps | 160 Gbps | 160 Gbps |
| Uplink Configuration | 1G | 1G | 1G | 1G | 1G |
| Weight | 16.5 lbs | 26.5 lbs | 24.3 lbs | 14.3 lbs | 19.8 lbs |
| Width | 17.06 inches | 17.38 inches | 17.5 inches | 17.4 inches | 17.38 inches |
Reviews & Ratings
N
Noah Prescott
5
Very stable switch with excellent data performance.
L
Luke Harrington
4
Cisco hardware quality delivered consistent uptime.
C
Caleb Winters
4
Strong choice for access layer requiring IP Services.
A
Andrew Wallace
5
Reliable and easy to manage over time.
Questions & Answers
What is the Cisco Catalyst 3560X 24 Port Data IP Services (WS-C3560X-24T-E)?
The WS-C3560X-24T-E is a fixed-configuration, Cisco IOS-managed, stackable Layer 3 switch offering 24 Gigabit Ethernet ports and advanced IP Services.
How many ports and what speeds does the Catalyst 3560X-24T-E provide?
It provides 24 10/100/1000 RJ-45 access ports delivering full wire-speed Gigabit performance per port.
Does the WS-C3560X-24T-E support Power over Ethernet (PoE)?
No. The 3560X-24T-E model does not support PoE or PoE+; customers requiring PoE should select the 3560X-24P variant.
What uplink options are available on the Catalyst 3560X-24T-E?
It features four fixed Gigabit SFP uplink ports with field-replaceable support for fiber SFP modules.
Can the Catalyst 3560X-24T-E be stacked, and what is the maximum stacking bandwidth?
Yes. Using Cisco StackWise Plus, you can stack up to nine units with up to 80 Gbps of aggregate bidirectional bandwidth.
What is the switching capacity and forwarding rate of the 3560X-24T-E?
The switch delivers 176 Gbps switching capacity and up to 95.2 million packets per second forwarding rate.
Which Layer 3 routing protocols are supported by the 3560X-24T-E?
It supports OSPF, EIGRP, RIP, BGP, PIM, VRRP, and static IPv4 routing under the IP Services license.
What are the physical dimensions and form factor of the WS-C3560X-24T-E?
The switch is a 1 RU rack-mountable appliance measuring 44.5 cm (W) × 43.5 cm (D) × 4.45 cm (H).
What is the typical power consumption and PSU configuration?
Typical power consumption is approximately 65 W; it supports dual, hot-swappable power supplies for redundancy.
Is the Catalyst 3560X-24T-E End-of-Life or still supported?
The WS-C3560X-24T-E has reached Cisco End-of-Life and is in extended support; customers are advised to migrate to the Catalyst 9000 series.
What advanced features are included in the IP Services license for the 3560X-24T-E?
The IP Services license enables advanced Layer 3 IP routing, VRF, multicast, MPLS Lite, and enhanced security features.
Does the 3560X-24T-E support IPv6 routing and features?
Yes. It supports IPv6 forwarding, OSPFv3, EIGRP for IPv6, MLD snooping, and IPv6 ACLs under the IP Services license.
What are the operating temperature and environmental specifications?
Operating temperature ranges from 0 °C to 40 °C with 10–90% non-condensing humidity compliance.
How do I configure basic Layer 3 functions on the 3560X-24T-E?
Enable routing with the 'ip routing' command, create VLAN interfaces via 'interface vlan X', assign IP addresses, and configure routing protocols.
Which management interfaces are supported on the Catalyst 3560X-24T-E?
Management is available via console (RJ-45), Telnet, SSHv2, SNMP v2/v3, and integration with Cisco Prime or DNA Center.
What warranty and support options are available for the WS-C3560X-24T-E?
Cisco provides a one-year limited hardware warranty; SMARTnet service contracts are available for 24×7 TAC support and advance replacement.
