P07598-B21

Specification Of P07598-B21

General
Type	Server
Product Form Factor	Rack-mountable - 2U
Built-in Devices	LED panel
Server Scalability	2-way
Hot-Swap Bays Qty	8
Localization	Region: Worldwide
Processor / Chipset
CPU	AMD EPYC 7402 / 2.8 GHz
Max Turbo Speed	3.35 GHz
Number of Cores	24-core
CPU Qty	1
Max CPU Qty	2
CPU Upgradability	Upgradable
Cache Memory
Installed Size	L3 cache - 128 MB
Cache Per Processor	128 MB
RAM
Installed Size	32 GB / 1 TB (max)
Technology	DDR4 SDRAM - ECC
Effective Memory Speed	2666 MHz
Rated Memory Speed	2666 MHz
Memory Specification Compliance	PC4-20800
Form Factor	DIMM 288-pin
Slots	32 (total) / 30 (empty)
Features	Registered, HPE SmartMemory
Configuration Features	2 x 16 GB
RAM Supported	PC4-20800 - 1 TB registered ¦ PC4-20800 - 4 TB Load-Reduced
Hard Drive
Type	No HDD
Storage Controller
Type	1 x RAID - PCIe 3.0 x8
Controller Interface Type	SATA 6Gb/s / SAS 12Gb/s
Storage Controller Name	HPE Smart Array P408i-a SR Gen10
Channel Qty	8
RAID Level	RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, RAID 50, RAID 60, 1ADM, 10ADM
Buffer Size	2 GB
Optical Storage
Type	No optical drive
Card Reader
Type	Card reader
Supported Flash Memory Cards	microSD
Monitor
Monitor Type	None.
Graphics Controller
Video Memory	16 MB
Video Interfaces	VGA
Networking
Interface (Bus) Type	PCI Express 2.0 x4
Ethernet Ports	4 x Gigabit Ethernet, 2 x 25 Gigabit Ethernet
Ethernet Controller	HPE 331i, HPE 631FLR
Data Link Protocol	Ethernet, Fast Ethernet, Gigabit Ethernet
Remote Management Protocol	SNMP 3, IPMI 2.0, SMASH CLP
Remote Management Controller	Integrated Lights-Out 5
Features	Wake on LAN (WoL), ACPI support, PXE support
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1as, IEEE 802.3az
Expansion / Connectivity
Bays	1 (total) / 1 (free) x external ¦ 16 (total) / 16 (free) x hot-swap NVMe
Slots	1 (total) / 0 (free) x FlexibleLOM ¦ 2 (total) / 2 (free) x PCIe 3.0 x16 - half-length, full-height ¦ 4 (total) / 4 (free) x PCIe 3.0 x8 - half-length, full-height ¦ 1 (total) / 1 (free) x microSD Card (internal)
Interfaces	1 x HPE iLO - Type A (1 in front) ¦ 5 x USB 3.0 (1 front, 2 rear, 2 internal) ¦ 4 x LAN (Gigabit Ethernet) - RJ-45 (4 rear) ¦ 2 x LAN (25Gigabit Ethernet) (SFP28) ¦ 1 x HPE iLO - RJ-45 (1 rear) ¦ 1 x VGA (1 rear)
Miscellaneous
Included Accessories	Cable management arm, HPE Easy Install Rails, 6 performance fans
Compliant Standards	AES, FIPS 140-2, IPv6 Ready, TLS v1.2, ASHRAE Class A4, ASHRAE Class A3, WEEE 2002/95/EC, ACPI 6.1
Power
Device Type	Power supply - hot-plug
Power Redundancy	Optional
Power Redundancy Scheme	1+1 (with optional power supply)
Installed Qty	2
Max Supported Qty	2
Nominal Voltage	AC 120/230 V (50/60 Hz)
Power Provided	800 Watt
80 PLUS Certification	80 PLUS Platinum
Efficiency	94%
Operating System / Software
Software	HPE Server UEFI, HPE iLO Standard with Intelligent Provisioning, HPE OneView Standard (free download)
Environmental Standards
ENERGY STAR Certified	Yes
ENERGY STAR Version	2.1
Manufacturer Warranty
Service & Support	Limited warranty - parts and labor - 3 years - on-site - response time: next business day
Dimensions & Weight
Width	17.5 in
Depth	26.7 in
Height	3.4 in
Weight	32.85 lbs
Environmental Parameters
Min Operating Temperature	50 °F
Max Operating Temperature	95 °F
Humidity Range Operating	8 - 90% (non-condensing)
Sound Emission	31 dBA
