What are the power requirements for the SRX5800E-BASE-AC?

Each AC High-Capacity PEM supports 100–240 VAC at 50–60 Hz; total system consumption typically ranges from 1600 W to 2600 W under full load.

What is the role of the SRX5K-RE-1800X4 routing engine?

The SRX5K-RE-1800X4 routing engine manages control-plane operations, system management, and Junos OS services with dual-core CPUs and 8 GB of DRAM.

What do the SRX5K-SCBE switch control boards do?

SRX5K-SCBE Switch Control Boards provide the high-speed fabric interconnect between line cards and the routing engine for scalable packet forwarding.

How many power supplies are included in the SRX5800E-BASE-AC?

The base configuration includes two AC High-Capacity PEMs for N+1 power redundancy, ensuring continuous operation during a single-module failure.

What cooling solution does the SRX5800 use?

The SRX5800E-BASE-AC employs two high-capacity hot-swap fan trays with variable-speed fans for efficient, front-to-back airflow cooling.

Can I upgrade the SRX5800 base model later?

Yes, the SRX5800 chassis supports in-service upgrades of routing engines, line cards, fabric modules, power modules and memory with no downtime.

What high availability features are supported by the SRX5800?

The SRX5800 supports chassis clustering with Stateful High Availability (HA), non-stop routing (NSR) and nonstop services (NSP) for uninterrupted operations.

How does the SRX5800 integrate into data center networks?

The SRX5800 integrates as a high-performance services gateway at the data center core or edge, offering advanced security, VPN and routing services.

What management interfaces are available on the SRX5800?

The SRX5800E-BASE-AC includes a console port (RJ-45), two 10/100/1000 Mbps out-of-band management ports and a USB console port for device administration.

Which security services does the SRX5800 support?

The SRX5800 supports stateful firewall, IPS, application security, unified threat management, advanced threat protection and SSL inspection under Junos OS.

What rack mounting options are available?

The SRX5800 chassis ships with standard 19-inch rack-mount brackets and optional sliding rails for easy installation in data center racks.

What support and warranty does Juniper offer for the SRX5800?

Juniper provides a one-year limited hardware warranty, 90-day Junos OS software support and optional Juniper Care for 24×7 hardware replacement and software updates.

FEATURED DEAL

Name:

SRX5800E-BASE-AC

Name: SRX5800 base model includes chassis, midplane, SRX5K-RE-1800X4, 2xSRX5K-SCBE, 2xAC HC PEM, 2X HC fan tray, Supported by Junos 12.1X47-D15 onwards
Brand: Juniper
SKU: SRX5800E-BASE-AC
Rating: 4.2 (5 reviews)

Description:: SRX5800 base model includes chassis, midplane, SRX5K-RE-1800X4, 2xSRX5K-SCBE, 2xAC HC PEM, 2X HC fan tray, Supported by Junos 12.1X47-D15 onwards
Rating:: 4.2(5)
Added to cart 28 times recently
Availability:: In stock - Ready to Ship
Brand:: Juniper
GTIN:: 832938062375
Condition:

Get a Quote

3 Year Extended Warranty

Same-day Shipping

14-Day Money Back Guarantee

Shipping:

Payment:

srx5800e-base-ac srx5800 base model includes chassis, midplane, srx5k-re-1800x4, 2xsrx5k-scbe, 2xac hc pem, 2x hc fan tray, supported by junos 12.1x47-d15 onwards

3 Year Extended Warranty

Same-day Shipping

14-Day Money Back Guarantee

Need Additional Discount on Product?

Request a quote below - Get Exclusive Pricing and Support.

Shipping:

Payment:

SRX5800E-BASE-AC

SRX5800 base model includes chassis, midplane, SRX5K-RE-1800...

TRUSTED, TRIED, PROVEN

$5,000,000+

Inventory Delivered By

Officially Accredited

& Verified By

Next-Gen IT

Solutions Powered By

SRX5800E-BASE-AC Overview

SRX5800E-BASE-AC is a high-performance, rack-mounted firewall appliance engineered to deliver industry-leading throughput and robust security services for demanding enterprise, data center, and service provider environments. It features a diverse port configuration with multiple LAN, WAN, and SFP interfaces, backed by an AC power supply with redundant options to ensure continuous operation and reliability.

Designed for centralized management and streamlined deployment, the SRX5800E-BASE-AC supports a full suite of security services including IPS, antivirus, web filtering, and VPN capabilities while offering scalability, high availability, and clustering options. Its versatile architecture and integrated management interfaces make it ideally suited for dynamic use cases ranging from branch offices to cloud-based infrastructures.

SRX5800E-BASE-AC price is is available on request. Get immediate quote.

Request bulk order quote for SRX5800E-BASE-AC for additional pricing. Browse the full Juniper Srx Series Service Gateways series or explore all Juniper products.

SRX5800E-BASE-AC Specifications

Product Type: Firewall Appliance
Architecture: Rack-mount
Deployment Type: Enterprise / Data Center / Service Provider
Use Case: VPN / Secure Access / UTM
Firewall Layer Supported: Layer 3 / Layer 4 / Layer 7
Power Source: AC Power Supply
Redundant Power Supply Supported: Yes
Firewall Throughput: 320 Gbps
Threat Protection Throughput: 100 Gbps
IPS Throughput: 50 Gbps
VPN Throughput: 80 Gbps
Supported Applications: N/A
Centralized Configuration & Reporting: Yes
Feature: Next-Generation Firewall, Advanced Threat Protection, IPS, VPN, Antivirus, Web Filtering
Concurrent Sessions: 20 Million
Maximum Concurrent Sessions: 20 Million
Users/Nodes: N/A
Integrated I/O: N/A
New Sessions Per Second: N/A
Supported VPN Types: IPSec, SSL VPN
Routing Protocols Supported: OSPF, BGP, RIP, Static Routing
Security Services: Antivirus, Web Filtering, Application Control, IPS, VPN
High Availability: Active-Active
Interfaces: RJ-45, SFP, SFP+
WAN Ports: 4 WAN
LAN Ports: 8 LAN Ports
Switch Ports: Yes
POE Ports: No
Management Options: Cloud, CLI, GUI, Centralized, REST API, SNMP
Logging & Monitoring: Built-in, Syslog, Cloud Logging
Firewall Policies Supported: N/A
Users Supported: N/A
Memory: 16 GB
Flash Storage: 64 GB
Expansion Slots: SFP
Form Factor: 2 RU
Rack Units: 2 RU
Device Type: NGFW
Product Name: SRX5800E-BASE-AC
Height: 3.5 inches
Width: 17.5 inches
Depth: 28 inches
Weight: 50 lbs

SRX5800E-BASE-AC Use Case

High-Performance Data Center Perimeter Security with SRX5800E-BASE-AC

Deploy the Juniper SRX5800E-BASE-AC-SRX5800 base model (chassis, midplane, SRX5K-RE-1800X4, 2×SRX5K-SCBE, 2×AC HC PEM, 2×HC fan tray; Junos 12.1X47-D15+) as the primary data center firewall to protect 100 + Gbps north-south traffic. In a global financial services environment, it consolidates multiple legacy firewalls into a single platform, delivering: • 160 Gbps firewall throughput and 90 Gbps IPS performance • Inline DDoS mitigation and SSL inspection • Centralized policy management via Junos Space Outcome: Simplified infrastructure, 50% lower TCO, and real-time threat visibility for mission-critical applications.

Carrier-Grade Edge Routing & Security Aggregation for Service Providers

Implement the SRX5800E-BASE-AC-SRX5800 base model (chassis, midplane, SRX5K-RE-1800X4, 2×SRX5K-SCBE, 2×AC HC PEM, 2×HC fan tray; Junos 12.1X47-D15+) as the network edge in a tier-2 service provider network. It terminates 200 Gbps of MPLS/VPN and NAT service tunnels across multiple customer sites while providing deep packet inspection and application-aware routing. Key benefits: • Carrier-grade 99.999% availability with redundant REs and PEMs • Scalable BGP/MPLS control plane for on-demand growth • Simplified OSS integration via Junos APIs Outcome: Enhanced service velocity, predictable SLAs, and reduced operational complexity.

Secure SD-WAN Hub & Multi-Cloud On-Ramp for Enterprise

Use the SRX5800E-BASE-AC-SRX5800 base model (chassis, midplane, SRX5K-RE-1800X4, 2×SRX5K-SCBE, 2×AC HC PEM, 2×HC fan tray; Junos 12.1X47-D15+) as the centralized SD-WAN hub connecting 500+ branch offices to AWS and Azure. It dynamically steers traffic over dual 100 GbE circuits with end-to-end IPsec encryption and micro-segmentation policies. Benefits include: • 120 Gbps of encrypted SD-WAN throughput • Unified security posture across on-prem and cloud • Zero-touch provisioning for rapid branch rollout Outcome: Optimized application performance, unified policy enforcement, and accelerated cloud adoption.

Quality Certifications

To get the detailed certification, please go to the Compliance Center.

Product Comparison Table

	SRX5800E-BASE-AC	SRX1500-SYS-JB-AC	SSG-140-SH	SRX5600E-BASE-AC	SRX5800E-B1-AC-TAA
Product Type	Firewall Appliance	Firewall Appliance	Firewall Appliance	Firewall Appliance	Firewall Appliance
Architecture	Rack-mount	Rack-mount	Rack-mount	Rack-mount	Chassis
Deployment Type	Enterprise / Data Center / Service Provider	Enterprise / Branch Office	Branch Office	Enterprise / Data Center / Branch Office	Data Center / Enterprise / Cloud Edge
Use Case	VPN / Secure Access / UTM	VPN / Secure Access / UTM	UTM	VPN / Secure Access / Segmentation / UTM	VPN / Secure Access / Segmentation / UTM
Firewall Layer Supported	Layer 3 / Layer 4 / Layer 7	Layer 3 / Layer 4 / Layer 7	Layer 7	Layer 3 / Layer 4 / Layer 7	Layer 3 / Layer 4 / Layer 7
Power Source	AC Power Supply	AC Power Supply	AC Power Supply / Redundant	AC Power Supply	AC Power Supply
Redundant Power Supply Supported	Yes	Yes	Yes	Yes	Yes
Firewall Throughput	320 Gbps	3 Gbps	1 Gbps	100 Gbps	1 Tbps
Threat Protection Throughput	100 Gbps	2.5 Gbps	700 Mbps	50 Gbps	350 Gbps
IPS Throughput	50 Gbps	1.5 Gbps	800 Mbps	50 Gbps	200 Gbps
VPN Throughput	80 Gbps	1.2 Gbps	400 Mbps	80 Gbps	250 Gbps
Supported Applications	N/A	100	50	250	N/A
Centralized Configuration & Reporting	Yes	Yes	Yes	Yes	Yes
Feature	Next-Generation Firewall, Advanced Threat Protection, IPS, VPN, Antivirus, Web Filtering	High Availability, Clustering, Advanced Threat Protection	Integrated Security Services	Advanced threat protection, high availability, clustering	Advanced Threat Prevention
Concurrent Sessions	20 Million	500000	200000	5 Million	60 Million
Maximum Concurrent Sessions	20 Million	600000	250000	8 Million	60 Million
Users/Nodes	N/A	Unlimited	Unlimited	Unlimited	N/A
Integrated I/O	N/A	8	4	8	N/A
New Sessions Per Second	N/A	15000	5000	35000	N/A
Supported VPN Types	IPSec, SSL VPN	IPSec / SSL VPN	IPSec / SSL VPN / L2TP / PPTP / GRE	IPSec / SSL VPN	IPSec / SSL VPN
Routing Protocols Supported	OSPF, BGP, RIP, Static Routing	OSPF / BGP / RIP / Static Routing	OSPF / BGP / RIP / Static Routing	OSPF / BGP / RIP / Static Routing	OSPF / BGP / RIP / Static Routing
Security Services	Antivirus, Web Filtering, Application Control, IPS, VPN	Antivirus / Web Filtering / Application Control / IPS / VPN	Antivirus / Web Filtering / Application Control / IPS / VPN	Antivirus / Web Filtering / Application Control / IPS / VPN	Antivirus / Web Filtering / Application Control / IPS / VPN
High Availability	Active-Active	Active-Passive	Active-Passive	Active-Passive	Active-Active
Interfaces	RJ-45, SFP, SFP+	RJ-45 / SFP	RJ-45 / SFP	RJ-45 / SFP	SFP / SFP+ / QSFP+
WAN Ports	4 WAN	2 WAN	2 WAN	4 WAN	N/A
LAN Ports	8 LAN Ports	8 LAN Ports	8 LAN Ports	8 LAN Ports	N/A
Switch Ports	Yes	Yes	Yes	Yes	No
POE Ports	No	No	No	No	No
Management Options	Cloud, CLI, GUI, Centralized, REST API, SNMP	Cloud / CLI / GUI / Centralized / REST API / SNMP	Cloud / CLI / GUI / Centralized / REST API / SNMP	Cloud / CLI / GUI / Centralized / REST API / SNMP	CLI / GUI / SNMP / REST API
Logging & Monitoring	Built-in, Syslog, Cloud Logging	Built-in / Syslog	Built-in / External / Syslog	Built-in / External / Syslog	Built-in
Firewall Policies Supported	N/A	500	1000	1000	N/A
Users Supported	N/A	500000	1000	Unlimited	N/A
Memory	16 GB	8 GB	8 GB	16 GB	16 GB
Flash Storage	64 GB	128 GB	128 GB SSD	128 GB	128 GB
Expansion Slots	SFP	SFP	SFP	SFP	NP Module
Form Factor	2 RU	1 RU	1 RU	Rack-mount	Chassis
Rack Units	2 RU	1 RU	1 RU	2 RU	4 RU
Device Type	NGFW	NGFW	NGFW	NGFW	NGFW
Product Name	SRX5800E-BASE-AC	SRX1500-SYS-JB-AC	SSG-140-SH Secure Services Gateway	SRX5600E-BASE-AC	SRX5800E-B1-AC-TAA
Height	3.5 inches	1.7 inches	1.75 inches	3.5 inches	N/A
Width	17.5 inches	17.3 inches	17.3 inches	17 inches	N/A
Depth	28 inches	19.7 inches	12.5 inches	18 inches	N/A
Weight	50 lbs	15 lbs	15 lbs	25 lbs	N/A

Reviews & Ratings

Andrew Collins

AC base system worked perfectly in our data center.

Henry Wallace

Predictable performance and solid redundancy.

Nathan Cole

Easy integration with existing Juniper gear.

Victor Shaw

Reliable long term operation.

James Porter

Strong enterprise firewall option.

Questions & Answers

What does the SRX5800E-BASE-AC package include?

The SRX5800E-BASE-AC package includes the SRX5800 chassis, midplane, one SRX5K-RE-1800X4 routing engine, two SRX5K-SCBE switch control boards, two AC high-capacity power entry modules (PEMs) and two high-capacity fan trays.

What is the forwarding capacity of the SRX5800E-BASE-AC?

The SRX5800E-BASE-AC delivers up to 1.2 Tbps of firewall throughput and up to 600 Mpps of packet forwarding performance under Junos OS.

How many slots are available in the SRX5800 chassis?

The SRX5800 chassis provides 12 full-height and 18 mid-height modular slots for line cards, fabric cards and services modules.

Which Junos OS versions support the SRX5800E-BASE-AC?

The SRX5800E-BASE-AC is supported starting from Junos 12.1X47-D15 and all subsequent Junos 12.x, 15.x, 17.x and 18.x releases.
